虚拟水社会循环视域下的水资源承载力评价

doi:10.31497/zrzyxb.20210207

Abstract

Abstract:

The shortage and uneven distribution of water resources in China are very serious. The contradiction of water utilization has changed from insufficient supply to overload of Water Resources Carrying Capacity (WRCC). Based on the concept of sustainability, this study, combined with the society cycle process of virtual water, improves the evaluation method of WRCC and analyzes the WRCC of Northwest China. The method can be helpful to maintain the integrity of water ecology and the stability of water supply. The results show that: (1) The WRCC of Shaanxi is generally good. However, it has a downward trend in the past ten years, in which the environmental pressure is the largest. The WRCC of Gansu shows a downward trend on the whole, especially in terms of environmental and social pressure. The WRCC of Ningxia has been on the verge of overloading or slight overloading, and alleviated by virtual water trade. The WRCC of Xinjiang is greatly affected by virtual water outflow and has been on the verge of overloading or slight overloading. The WRCC of Qinghai is basically in a surplus state of carrying capacity. (2) Virtual water trade has a significant influence on the comprehensive pressure index of WRCC. The evaluation method of WRCC, combined with the society cycle process of virtual water, has a practical significance. (3) The regions of different endowments of water resources and the efficiency of using water can be appropriately different in development modes. We suggest that the regions with high and low use efficiency of water take the "radical development mode" and the "radical environmental protection mode", respectively.

Key words: Northwest China, water resources, virtual water, bearing capacity index

DING Chao, HU Yong-jiang, WANG Zhen-hua, ZHAO Na, DONG Wen-xiu, WANG Li-ming. Assessment of water resources carrying capacity from the perspective of virtual water social cycle[J].JOURNAL OF NATURAL RESOURCES, 2021, 36(2): 356-371.

Figures/Tables 11

Fig. 1

Fig. 2

Table 1

Estimation of eco-environmental water demand"

生态环境需水		计算办法	说明
城市生态需水Q_c	城市园林绿化需水	需水统计数据,来源为各省水资源公报
城市生态需水Q_c	城市人工水域需水	$Q c = A (E m - P m)$	A为水域面积（ $h m 2$ ）;E_m为平均蒸发量（mm）; $P m$ 为平均降水量（mm）
河道外生态环境需水Q_ro	植被需水	需水定额=150 $m 3 / h m 2$ ^[28]
	水土保持需水	需水定额=160 $m 3 / h m 2$ ^[28]
	人工水域（水库）需水	需水定额=304.25 $m 3 / h m 2$ ^[28]
河道内生态环境需水Q_ri	维持基本径流	$Q r = Mean Q i$	Q_i为第i年的平均径流量（亿m³）,采用蒙大拿法^[29]
河道内生态环境需水Q_ri	维持水沙平衡	$Q s = S t / C max$	S_t为多年平均输沙量（亿t）;C_max为平均多年最大月含沙量（亿t）

Table 1

Table 2

Measurement standards for water resources bearing capacity"

WRCC、 $I r$ 、 $I eco$ 、 $I pep$ 、 $I e$	<0	0~0.50	0.51~1.00	1.01~1.30	1.31~2.00	>2.00
承载力等级	F 严重超载严重恶化	E 重度超载资源匮乏	D 轻度超载资源短缺	C 濒临超载资源紧张	B 承载适宜资源协调	A 承载富余资源丰裕

Table 2

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Table 3

Table 4

Impact of integrating virtual water social cycle on WRCC of original entities"

省、自治区	年份	$I r entity$	$I r$	变化情况	$I e entity$	$I e$	变化情况	$I eco entity$	$I eco$	变化情况	$I pep entity$	$I pep$	变化情况	变化率/%
陕西	2007	A	A	不变	B	B	不变	A	A	不变	A	A	不变	16.67
	2012	A	B	降1档	B	B	不变	A	A	不变	A	A	不变
	2017	A	B	降1档	B	B	不变	A	A	不变	A	A	不变
甘肃	2007	D	D	不变	D	D	不变	D	D	不变	F	F	不变	33.33
	2012	D	E	降1档	D	D	不变	D	E	降1档	F	F	不变
	2017	D	E	降1档	D	D	不变	D	E	降1档	F	F	不变
青海	2007	A	A	不变	B	B	不变	A	A	不变	A	A	不变	0
	2012	A	A	不变	B	B	不变	A	A	不变	A	A	不变
	2017	A	A	不变	B	B	不变	A	A	不变	A	A	不变
宁夏	2007	D	C	提1档	D	C	提1档	D	C	提1档	E	B	提3档	50.00
	2012	D	D	不变	D	D	不变	D	D	不变	E	D	提1档
	2017	D	D	不变	D	D	不变	D	D	不变	E	D	提1档
新疆	2007	B	D	降2档	B	D	降2档	B	D	降2档	A	F	降5档	83.33
	2012	B	C	降1档	B	C	降1档	B	C	降1档	A	A	不变
	2017	B	D	降2档	B	C	降1档	B	C	降1档	A	A	不变

Table 4

Fig. 7

References 31

[1]	VELDKAMP T I E, WADA Y, AERTS J C J H, et al. Water scarcity hotspots travel downstream due to human interventions in the 20th and 21st century. Nature Communications, 2017,8:15697. doi: 10.1038/ncomms15697 pmid: 28643784
[2]	LU S, ZHANG X, BAO H, et al. Review of social water cycle research in a changing environment. Renewable and Sustainable Energy Reviews, 2016,63:132-140.
[3]	刘佳骏, 董锁成, 李泽红. 中国水资源承载力综合评价研究. 自然资源学报, 2011,26(2):258-269.
	[ LIU J J, DONG S C, LI Z H. Comprehensive evaluation of China's water resources carrying capacity. Journal of Natural Resources, 2011,26(2):258-269.]
[4]	王建华. 国家水资源承载力评价与战略配置. 中国环境管理, 2017,9(4):111-112.
	[ WANG J H. Evaluation and strategic allocation of national water resources carrying capacity. Chinese Journal of Environmental Management, 2017,9(4):111-112.]
[5]	赵敏娟, 刘霁瑶. 水资源多目标协同配置: 全价值基础上的框架研究. 中国环境管理, 2018,10(5):8-14.
	[ ZHAO M J, LIU J Y. Multi-objective collaborative allocation of water resources: A framework study based on full value. Chinese Journal of Environmental Management, 2018,10(5):8-14.]
[6]	DAILY G C, EHRLICH P R. Socioeconomic equity, sustainability, and earth' carrying capacity. Ecological Application, 1996,6(4):991-1001.
[7]	夏军, 朱一中. 水资源安全的度量: 水资源承载力的研究与挑战. 自然资源学报, 2002,17(3):262-269.
	[ XIA J, ZHU Y Z. Comprehensive evaluation of China's water resources carrying capacity. Journal of Natural Resources, 2002,17(3):262-269.]
[8]	闵庆文, 余卫东, 张建新. 区域水资源承载力的模糊综合评价分析方法及应用. 水土保持研究, 2004,11(3):14-16.
	[ MIN Q W, YU W D, ZHANG J X. Fuzzy-based evaluation of water resources carrying capacity and its application. Research of Soil and Water Conservation, 2004,11(3):14-16.]
[9]	阮本青, 沈晋. 区域水资源适度承载能力计算模型研究. 土壤侵蚀与水土保持学报, 1998,4(3):57-61.
	[ RUAN B Q, SHEN J. Calculating model for moderately bearing capacity of regional water resources. Journal of Soil and Water Conservation, 1998,4(3):57-61.]
[10]	鲍超, 方创琳. 水资源约束力的内涵、研究意义及战略框架. 自然资源学报, 2006,21(5):844-852.
	[ BAO C, FANG C L. On concept, significance and strategic framework for water resources constraint force. Journal of Natural Resources, 2006,21(5):844-852.]
[11]	龙腾锐, 姜文超, 何强. 水资源承载力内涵的新认识. 水利学报, 2004, (1):38-45.
	[ LONG T R, JIANG W C, HE Q. Water resources carrying capacity: New perspectives based on eco economic analysis and sustainable development. Journal of Hydraulic Engineering, 2004, (1):38-45.]
[12]	KANG H, SRIDHAR V, MILLS B F, et al. Economy-wide climate change impacts on green water droughts based on the hydrologic simulations. Agricultural Systems, 2019,171(C):76-88.
[13]	YANG D, YIN Y, MA X, et al. Environmental improvement of lead refining: A case study of water footprint assessment in Jiangxi province, China. The International Journal of Life Cycle Assessment, 2019,24(7):1533-1542.
[14]	熊娜娜, 谢世友. 成都市水资源生态足迹及承载力时空演变研究. 西南大学学报: 自然科学版, 2018,40(6):124-131.
	[ XIONG N N, XIE S Y. A study of the spatio-temporal evolution of ecological footprint and ecological carrying capacity of water resources of Chengdu. Journal of Southwest University: Natural Science Edition, 2018,40(6):124-131.]
[15]	尹默雪, 赵先贵. 基于水足迹理论的内蒙古1990—2016 年水资源评价. 干旱区资源与环境, 2018,32(6):120-125.
	[ YIN M X, ZHAO X G. Evaluation of water resource in Inner Mongolia from 1990 to 2016 based on water footprint theory. Journal of Arid Land Resources and Environment, 2018,32(6):120-125.]
[16]	丁超. 支撑西北干旱地区经济可持续发展的水资源承载力评价与模拟研究. 西安: 西安建筑科技大学, 2013.
	[ DING C. Support the northwest arid areas of sustainable economic development of water resources carrying capacity evaluation and simulation. Xi'an: Xi'an University of Architecture and Technology, 2013.]
[17]	付汉良, 刘晓君. 再生水回用公众心理感染现象的验证及影响策略. 资源科学, 2018,40(6):1222-1229.
	[ FU H L, LIU X J. Verification and influence strategies of residents' spiritual cognition of recycled water reuse. Resources Science, 2018,40(6):1222-1229.]
[18]	田贵良, 李娇娇, 李乐乐. 基于多区域投入产出模型的长江经济带虚拟水流动格局研究. 中国人口·资源与环境, 2019,29(3):81-88.
	[ TIAN G L, LI J J, LI L L. Pattern of virtual water flow in the Yangtze River Economic Belt based on multi-regional input-output model. China Population, Resources and Environment, 2019,29(3):81-88.]
[19]	曹涛, 王赛鸽, 陈彬. 基于多区域投入产出分析的京津冀地区虚拟水核算. 生态学报, 2018,38(3):788-799.
	[ CAO T, WANG S G, CHEN B. Virtual water analysis for the Jing-Jin-Ji region based on multiregional input-output model. Acta Ecologica Sinica, 2018,38(3):788-799.]
[20]	黄晓荣, 裴源生, 梁川. 宁夏虚拟水贸易计算的投入产出方法. 水科学进展, 2005, (4):564-568.
	[ HUANG X R, PEI Y S, LIANG C. Input/output method for calculating the virtual water trading in Ningxia. Advances in Water Science, 2005, (4):564-568.]
[21]	丁雪丽, 张玲玲, 王宗志. 基于省际间粮食贸易的虚拟水综合效益分析. 长江流域资源与环境, 2018,27(5):978-987.
	[ DING X L, ZHANG L L, WANG Z Z. Comprehensive benefits analysis of virtual water based on inter provincial trade. Resources and Environment in the Yangtze Basin, 2018,27(5):978-987.]
[22]	张金良, 蒋桂芹, 杨立彬, 等. 基于投入产出分析的内蒙古虚拟水消费及贸易研究. 水电能源科学, 2018,36(9):52-54.
	[ ZHANG J L, JIANG G Q, YANG L B, et al. Study on virtual water consumption and trade based on input-output analysis in Inner Mongolia. Water Resources and Power, 2018,36(9):52-54.]
[23]	马超, 许长新, 田贵良, 等. 虚拟水贸易的可计算非线性动态投入产出分析模型. 中国人口·资源与环境, 2016,26(11):160-169.
	[ MA C, XU C X, TIAN G L, et al. Computable nonlinear dynamic input-output analysis model of virtual water trade. China Population, Resources and Environment, 2016,26(11):160-169.]
[24]	余灏哲, 韩美. 基于水足迹的山东省水资源可持续利用时空分析. 自然资源学报, 2017,32(3):474-483.
	[ YU H Z, HAN M. Spatial-temporal analysis of sustainable water resources utilization in shandong province based on water footprint. Journal of Natural Resources, 2017,32(3):474-483.]
[25]	吴兆丹, 赵敏, 田泽, 等. 多区域投入产出分析下中国水足迹地区间比较: 基于“总量—相关指标—结构”分析框架. 自然资源学报, 2017,32(1):76-87.
	[ WU Z D, ZHAO M, TIAN Z, et al. Regional comparison of water footprint in China based on the multi-regional input-output analysis: In the analytical framework of "amount-relative index-structure". Journal of Natural Resources, 2017,32(1):76-87.]
[26]	张凡凡, 张启楠, 李福夺, 等. 中国水足迹强度空间关联格局及影响因素分析. 自然资源学报, 2019,34(5):934-944.
	[ ZHANG F F, ZHANG Q N, LI F D, et al. The spatial correlation pattern of water footprint intensity and its driving factors in China. Journal of Natural Resources, 2019,34(5):934-944.]
[27]	刘雅婷, 王赛鸽, 陈彬. 基于投入产出分析的北京市虚拟水核算. 生态学报, 2018,38(6):1930-1940.
	[ LIU Y T, WANG S G, CHEN B. Virtual water analysis for Beijing based on input-output model. Acta Ecologica Sinica, 2018,38(6):1930-1940.]
[28]	王菊翠, 仵彦卿, 党碧玲, 等. 陕西关中地区水资源的可持续发展支持能力. 地球科学与环境学报, 2009,31(2):177-184.
	[ WANG J C, WU Y Q, DANG B L, et al. Water resources supporting capacity for sustaining development in Guanzhong region, Shaanxi province, China. Journal of Earth Sciences and Environment, 2009,31(2):177-184.]
[29]	中华人民共和国水利部. SLZ 712-2014河湖生态环境需水计算规范. 北京: 中国水利水电出版社, 2014.
	[ Ministry of water resources of the people's Republic of China. SLZ 712-2014 Code for Calculation of Water Demand of River and Lake Ecological Environment. Beijing: China Water Conservancy and Hydropower Press, 2014.]
[30]	张雷, 鲁春霞, 吴映梅, 等. 中国流域水资源综合开发. 自然资源学报, 2014,29(2):295-303.
	[ ZHANG L, LU C X, WU Y M, et al. An overall development of water resources for China's rivers. Journal of Natural Resources, 2014,29(2):295-303.]
[31]	吴兆丹, 赵敏, LALL UPMANU. 基于多区域投入产出的我国省区虚拟水流动格局研究. 河海大学学报: 哲学社会科学版, 2016,18(6):62-69.
	[ WU Z D, ZHAO M, LALL U. Pattern of provincial virtual water flow in China based on multi-regional input-output analysis. Journal of Hohai University: Philosophy and Social Sciences, 2016,18(6):62-69.]

省、自治区	虚拟水主要流出地及流出所占比例（前4名）
省、自治区	第1	亿m³	%	第2	亿m³	%	第3	亿m³	%	第4	亿m³	%
陕西	国外	24.8	29.5	内蒙古	12.1	14.4	山东	6.0	7.1	江苏	3.3	3.9
甘肃	山东	9.3	10.9	广东	7.9	9.3	江苏	5.8	6.8	内蒙古	5.2	6.1
青海	山东	0.8	11.0	广东	0.7	10.2	甘肃	0.6	8.7	江苏	0.5	6.8
宁夏	山东	5.8	11.6	广东	5.2	10.4	甘肃	4.8	9.6	江苏	3.3	6.7
新疆	国外	71.5	17.2	山东	40.5	9.8	广东	36.3	8.7	甘肃	33.0	8.0
省、自治区	虚拟水主要流入地及流入所占比例（前4名）
省、自治区	第1	亿m³	%	第2	亿m³	%	第3	亿m³	%	第4	亿m³	%
陕西	国外	20.3	33.1	黑龙江	4.0	6.6	内蒙古	3.5	5.6	新疆	3.4	5.5
甘肃	国外	13.3	26.6	新疆	12.0	24.1	宁夏	9.3	18.7	青海	5.0	10.0
青海	国外	4.3	66.8	新疆	0.7	10.8	宁夏	0.5	8.4	甘肃	0.2	3.3
宁夏	国外	41.9	82.0	新疆	3.1	6.2	青海	1.4	2.7	甘肃	1.0	1.9
新疆	国外	178.5	75.7	陕西	6.2	2.6	黑龙江	5.5	2.4	宁夏	4.8	2.0
