皖江经济带土壤Cd空间分布特征与生态风险评价

doi:10.31497/zrzyxb.20211218

自然资源学报 ›› 2021, Vol. 36 ›› Issue (12): 3261-3270.doi: 10.31497/zrzyxb.20211218

• 其他研究论文 • 上一篇

皖江经济带土壤Cd空间分布特征与生态风险评价

周葆华¹(), 胡睿鑫¹, 赵宽¹(), 万昕¹, 汪瑜¹, 梁玉辉², 汤金来²

1. 安庆师范大学资源环境学院,皖江流域水环境保护与污染控制安徽省教育厅重点实验室,安庆 246133
2. 安徽省地质调查院,合肥 230001

收稿日期:2020-08-16 修回日期:2020-11-25 出版日期:2021-12-28 发布日期:2022-02-28
通讯作者: 赵宽（1986- ）,男,安徽池州人,博士,副教授,研究方向为环境生态毒理学。E-mail: zhaokuan@aqnu.edu.cn
作者简介:周葆华（1963- ）,女,安徽安庆人,教授,研究方向为生态环境调查与风险评估。E-mail: 1979748551@qq.com
基金资助:
安徽省科技重大专项项目(17030701057);安徽省自然科学基金项目(1908085QD149);安徽省高等学校自然科学研究重点项目(KJ2018A0374)

Spatial distribution characteristic of Cd in soils and its ecological risk assessment in the economic belt of Yangtze River in Anhui

ZHOU Bao-hua¹(), HU Rui-xin¹, ZHAO Kuan¹(), WAN Xin¹, WANG Yu¹, LIANG Yu-hui², TANG Jin-lai²

1. School of Resource and Environment, Key Laboratory of Aqueous Environment Protection and Pollution Control of Yangtze River in Anhui of Anhui Provincial Education Department, Anqing Normal University, Anqing 246133, Anhui, China
2. Anhui Institute of Geological Survey, Hefei 230001, China

Received:2020-08-16 Revised:2020-11-25 Online:2021-12-28 Published:2022-02-28

摘要/Abstract

摘要：

选取2.5 km×2.5 km网格布点法,在皖江经济带A、B、C三地分别采集土壤样品35个、34个、106个,利用ICP-AES分析测定Cd含量特征,运用单项污染指数法、地累积指数法和潜在生态风险指数法对三地土壤Cd污染状况进行生态风险评价。结果表明：（1）A、B、C三地土壤的Cd含量的算术平均值分别为0.40 mg?kg ^-1、0.66 mg?kg ^-1、0.84 mg?kg ^-1,均高于江淮流域Cd含量土壤背景值;（2）三地土壤pH在5.06~7.58之间,整体上处于酸性和弱碱性之间,pH小于7.0的样品167个,占比95.43%;（3）研究区三个地块土壤Cd污染特征存在明显的空间分异,低污染区在空间上呈带状分布,高污染区在空间上呈岛状分布,污染区分布面积C地>B地>A地。（4）三地土壤环境均受重金属Cd污染的影响,存在生态安全风险,风险大小为C地>B地>A地,风险程度均为潜在生态风险高于地累积生态风险高于单项污染生态风险。本区域土壤农业安全利用需要加以重视并进行分类管控。

关键词: 土壤Cd, 空间分布, 风险评价, 皖江经济带

Abstract:

The numbers of 35, 34 and 106 of soil samples in the economic belt of the Yangtze River in Anhui were collected at A, B and C sampling sites by the grid points of 2.5 km× 2.5 km, respectively, the Cd content was measured by ICP-AES, and single factor pollution index, geoaccumulation index and potential ecological risk index were selected to assess the environmental risk of Cd at the three sites. The results showed that: (1) The average values of Cd content were 0.40, 0.66 and 0.84 mg?kg ^-1 in soils of A, B and C sites, respectively, which were higher than the background values of Cd content in the soils of Yangtze-Huaihe river basin of Anhui. (2) The pH values of soils at the three sites were 5.06-7.58, which was between acidic and weakly alkaline. The number of samples with pH less than 7.0 was 167, accounting for 95.43% of the total number. (3) The low pollution area is distributed as a ribbon in space, while the high pollution area is distributed as an island in space of the three sites; different soil types have different pollution characteristics of Cd. (4) The assessment results were identical and presented as follows: site C > site B > site A by the single factor pollution index, the geoaccumulation index and the potential ecological risk index. In conclusion, we should focus on the safe utilization of soils and give targeted guidance to the study regions.

Key words: soil cadmium, spatial distribution, risk assessment, economic belt of Yangtze River in Anhui

周葆华, 胡睿鑫, 赵宽, 万昕, 汪瑜, 梁玉辉, 汤金来. 皖江经济带土壤Cd空间分布特征与生态风险评价[J]. 自然资源学报, 2021, 36(12): 3261-3270.

ZHOU Bao-hua, HU Rui-xin, ZHAO Kuan, WAN Xin, WANG Yu, LIANG Yu-hui, TANG Jin-lai. Spatial distribution characteristic of Cd in soils and its ecological risk assessment in the economic belt of Yangtze River in Anhui[J]. JOURNAL OF NATURAL RESOURCES, 2021, 36(12): 3261-3270.

图/表 7

图1

表1

图2

图3

表2

表3

表4

研究区土壤Cd潜在生态风险指数

	pH	样本数/个	$E r i$ 范围	$E r i$ 平均值	样本超标数/个 (超标率/%)
	pH	样本数/个	$E r i$ 范围	$E r i$ 平均值	低	中等	中高等	高等	极高
A	(5.5, 6.5]	20	13.04~286.01	100.73	3(15.00)	7(35.00)	6(30.00)	4(20.00)	0(0)
A	(6.5, 7.5]	15	42.98~253.27	133.39	0(0)	3(20.00)	9(60.00)	3(20.00)	0(0)
总体评价	5.99~6.98	35	13.04~286.01	114.73	3(8.57)	10(28.57)	15(42.86)	7(20.00)	0(0)
B	≤5.5	5	41.48~438.39	156.25	0(0)	3(60.00)	1(20.00)	0(0)	1(20.00)
	(5.5, 6.5]	21	42.94~360.69	174.53	0(0)	3(14.29)	7(33.33)	9(42.86)	2(9.52)
	(6.5, 7.5]	8	79.38~594.20	247.82	0(0)	1(12.50)	2(25.00)	4(50.00)	1(12.50)
总体评价	5.06~7.36	34	41.48~594.20	189.09	0(0)	7(20.59)	10(29.41)	13(38.24)	4(11.76)
C	≤5.5	6	100.33~665.25	309.85	0(0)	0(0)	1(16.67)	3(50.00)	2(33.33)
	(5.5, 6.5]	56	28.21~1811.22	228.05	1(1.78)	5(8.93)	29(51.79)	14(25.00)	7(12.50)
	(6.5, 7.5]	43	55.10~1143.81	255.81	0(0)	4(9.30)	18(41.86)	7(16.28)	14(32.56)
	>7.5	1	155.39	155.39	0(0)	0(0)	1(100)	0(0)	0(0)
总体评价	5.26~7.58	106	28.21~1811.22	243.26	1(0.94)	9(8.49)	49(46.23)	24(22.64)	23(21.70)

表4

参考文献 26

[1]	KUMAR V, SHARMA A, KAUR P, et al. Pollution assessment of heavy metals in soils of India and ecological risk assessment: A state-of-the-art. Chemosphere, 2019,216(2):449-462.
[2]	吴永红, 靳少非. 基于CiteSpace的重金属污染土壤修复研究文献计量分析. 农业环境科学学报, 2020,39(3):454-461.
	[ WU Y H, JIN S F. Bibliometric analysis of the repair of heavy metal-contaminated soil based on CiteSpace. Journal of Agro-Environment Science, 2020,39(3):454-461.]
[3]	BARSOVA N, YAKIMENKO O, TOLPESHTA I, et al. Current state and dynamics of heavy metal soil pollution in Russian Federation-a review. Environmental Pollution, 2019,249(6):200-207.
[4]	陈能场, 郑煜基, 何晓峰, 等. 《全国土壤污染状况调查公报》探析. 农业环境科学学报, 2017,36(9):1689-1692.
	[ CHEN N C, ZHENG Y J, HE X F, et al Analysis of the bulletin of national soil pollution survey. Journal of Agro-Environment Science, 2017,36(9):1689-1692.]
[5]	李宏薇, 尚二萍, 张红旗, 等. 耕地土壤重金属污染时空变异对比: 以黄淮海平原和长江中游及江淮地区为例. 中国环境科学, 2018,38(9):3464-3473.
	[ LI H W, SHANG E P, ZHANG H Q, et al. Comparative research on spatio-temporal variability of heavy metal pollution in cultivated soils: A case study of Huang-Huai-Hai Plain and middle reaches of the Yangtze River and Jianghuai Region. China Environmental Science, 2018,38(9):3464-3473.]
[6]	雷国建, 陈志良, 刘千钧, 等. 广州郊区土壤重金属污染程度及潜在生态危害评价. 中国环境科学, 2013,33(s1):49-53.
	[ LEI G J, CHEN Z L, LIU Q J, et al. The assessments of polluted degree and potential ecological hazards of heavy metals in suburban soil of Guangzhou city. China Environmental Science, 2013,33(s1):49-53.]
[7]	陈泗进, 何立环, 王业耀. 湖南省桂阳县某铅锌矿周边农田土壤重金属污染及生态风险评价. 环境化学, 2015,34(3):591-592.
	[ CHEN S J, HE L H, WANG Y Y. Heavy metal pollution and ecological risk assessment of farmland soil around a lead-zinc mine in Guiyang county, Hunan province. Environmental Chemistry, 2015,34(3):591-592.]
[8]	陈卫平, 杨阳, 谢天, 等. 中国农田土壤重金属污染防治挑战与对策. 土壤学报, 2018,55(2):261-272.
	[ CHEN W P, YANG Y, XIE T, et al. Challenges and countermeasures for heavy metal pollution control in farmlands of China. Acta Pedologica Sinica, 2018,55(2):261-272.]
[9]	YU L, CHENG J M, ZHAN J C, et al. Environmental quality and sources of heavy metals in the topsoil based on multivariate statistical analyses: A case study in Laiwu city, Shandong province, China. Natural Hazards, 2016,81(3):1435-1445.
[10]	许萌萌, 刘爱风, 师荣光, 等. 天津农田重金属污染特征分析及降雨沥浸影响. 环境科学, 2018,39(3):1095-1101.
	[ XU M M, LIU A F, SHI R G, et al. Characteristics of heavy metals pollution of farmland and the leaching effect of rainfall in Tianjin. Environmental Science, 2018,39(3):1095-1101.]
[11]	ABDELHAFEZ A A, LI J H. Environmental monitoring of heavy metal status and human health risk assessment in the agricultural soils of the Jinxi River Area, China. Human and Ecological Risk Assessment, 2015,21(4):952-971.
[12]	殷汉琴, 陈富荣, 陈兴仁, 等. 铜陵市及其周边地区土壤重金属元素污染评价. 安全与环境学报, 2010,18(3):98-102.
	[ YIN H Q, CHEN F R, CHEN X R, et al. Assessment of heavy metal pollutions to the soils in Tongling city, Anhui. Journal of Safety and Environment, 2010,18(3):98-102.]
[13]	杨西飞. 铜陵矿区农田土壤及水稻的重金属污染现状研究. 合肥: 合肥工业大学, 2007.
	[ YANG X F. A current research on heavy metal pollution to the soil and rice in the farmland soil in Tongling mining district. Hefei: Hefei University of Technology, 2007.]
[14]	李法松, 韩铖, 林大松, 等. 安庆沿江湖泊及长江安庆段沉积物重金属污染特征及生态风险评价. 农业环境科学学报, 2017,36(3):574-582.
	[ LI F S, HAN C, LIN D S, et al. Pollution characteristics and ecological risk assessment of heavy metals in the sediments from lakes of Anqing city and Anqing section of Yangtze River. Journal of Agro-Environment Science, 2017,36(3):574-582.]
[15]	王茜, 张光辉, 田言亮, 等. 皖江经济区基本农田地球化学特征及成因. 地质学报, 2016,90(8):1988-1997.
	[ WANG Q, ZHANG G H, TIAN Y L, et al. The character and influencing factor of geochemical distribution in basic farmland of economic zone along Yangtze River in Anhui. Acta Geologica Sinica, 2016,90(8):1988-1997.]
[16]	赵传冬, 陈富荣, 陈兴仁, 等. 长江流域沿江镉异常源追踪与定量评估的方法技术研究: 以长江流域安徽段为例. 地学前缘, 2008,15(5):179-193.
	[ ZHAO C D, CHEN F R, CHEN X R, et al. A methodology of tracking sources of cadmium anomalies and their quantitative estimation in the Yangtze River Basin. Earth Science Frontiers, 2008,15(5):179-193.]
[17]	池源. 安徽铜陵地区土壤和河流沉积物重金属分布特征与污染评价. 南京: 南京大学, 2013.
	[ CHI Y. Distribution characteristics and pollution evaluation of soil and river sediment heavy metals in Tongling, Anhui. Nanjing: Nanjing University, 2013.]
[18]	钟雪梅, 夏德尚, 宋波, 等. 广西土壤镉含量状况与风险评估研究进展. 自然资源学报, 2017,32(7):1256-1270.
	[ ZHONG X M, XIA D S, SONG B, et al. Review on soil cadmium study and risk assessment in Guangxi. Journal of Natural Resources, 2017,32(7):1256-1270.]
[19]	谢蓉蓉, 吴如林, 唐晨, 等. 互花米草入侵对河口湿地沉积物重金属累积效应. 自然资源学报, 2020,35(5):1238-1249.
	[ XIE R R, WU R L, TANG C, et al. Heavy metal accumulation affected by Spartina alterniflora invasion in estuarine wetland sediments. Journal of Natural Resources, 2020,35(5):1238-1249.]
[20]	HAKANSON L. An ecological risk index for aquatic pollution control: A sedimentological approach. Water Research, 1980,14(8):975-1001.
[21]	吴新民, 潘根兴. 影响城市土壤重金属污染因子的关联度分析. 土壤学报, 2003,40(6):921-929.
	[ WU X M, PAN G X. The correlation analysis between the content of heavy metals and the factors influencing the pollution of heavy metals in urban soils in Nanjing city. Acta Pedologica Sinica, 2003,40(6):921-928.]
[22]	杨元根, PATERSON E, CANPBELLC. 城市土壤中重金属元素的积累及其微生物效应. 环境科学, 2001,22(3):44-48.
	[ YANG Y G, PATERSON E, CANPBELLC. Accumulation of heavy metals in urban soils and impact on microorganisms. Environmental Science, 2001,22(3):44-48.]
[23]	IDASZKIN Y L, CAROL E, ALVAREZ M D P. Mechanism of removal and retention of heavy metals from the acid mine drainage to coastal wetland in the Patagonian marsh. Chemosphere, 2017,183(9):361-370.
[24]	隆茜, 张经. 陆架区沉积物中重金属研究的基本方法及其应用. 海洋湖沼通报, 2002,3(3):25-35.
	[ LONG Q, ZHANG J. The method of heavy metals study in shelf sediments and its application. Transactions of Oceanology and Limnology, 2002,3(3):25-35.]
[25]	WIESE S B O, MACLEOD C L, LESTER J N. A recent history of metal accumulation in the sediments of the Thames Estuary, United Kingdom. Estuaries, 1997,20(3):483-493.
[26]	李宇庆, 陈玲, 仇雁翎, 等. 上海化学工业区土壤重金属元素形态分析. 生态环境, 2004,13(2):154-155.
	[ LI Y Q, CHEN L, QIU Y L, et al. Speciation of heavy metals in soil from Shanghai Chemical Industry Park. Ecology and Environmental, 2004,13(2):154-155.]

	pH	样品数/个	最大值/(mg∙kg^-1)	最小值/(mg∙kg^-1)	平均值/(mg∙kg^-1)	标准差	变异系数/%
A	(5.5, 6.5]	20	0.99	0.05	0.35	0.24	68.43
A	(6.5, 7.5]	15	0.88	0.15	0.46	0.22	47.05
总体情况	5.99~6.98	35	0.99	0.05	0.40	0.23	58.78
B	≤5.5	5	1.52	0.14	0.54	0.56	104.26
	(5.5, 6.5]	21	1.25	0.15	0.61	0.31	51.73
	(6.5, 7.5]	8	2.06	0.28	0.86	0.54	62.53
总体情况	5.06~7.36	34	2.06	0.14	0.66	0.42	63.43
C	≤5.5	6	2.31	0.35	1.07	0.69	63.92
	(5.5, 6.5]	56	6.28	0.10	0.79	0.95	120.16
	(6.5, 7.5]	43	3.96	0.19	0.89	0.80	89.73
	>7.5	1	0.54	0.54	0.54	0	0
总体情况	5.26~7.58	106	6.28	0.10	0.84	0.87	103.01

区域	pH	样本数/个	P值范围	P平均值	样本超标数/个 (超标率/%)
区域	pH	样本数/个	P值范围	P平均值	无污染	轻污染	中度污染	重度污染
A	(5.5, 6.5]	20	0.11~2.48	0.87	14(70.00)	5(25.00)	1(5.00)	0(0)
A	(6.5, 7.5]	15	0.25~1.46	0.77	12(80.00)	3(20.00)	0(0)	0(0)
区域总体评价	5.99~6.98	35	0.11~2.48	0.82	26(74.28)	8(22.86)	1(2.86)	0(0)
B	≤5.5	5	0.48~5.06	1.81	3(60.00)	1(20.00)	0(0)	1(20.00)
	(5.5, 6.5]	21	0.37~3.13	1.51	7(33.33)	9(42.86)	4(19.05)	1(4.76)
	(6.5, 7.5]	8	0.46~3.43	1.43	3(37.50)	4(50.00)	0(0)	1(12.50)
区域总体评价	5.06~7.36	34	0.37~5.06	1.54	13(38.23)	14(41.18)	4(11.77)	3(8.82)
C	≤5.5	6	1.16~7.69	3.58	0(0)	1(16.67)	2(33.33)	3(50.00)
	(5.5, 6.5]	56	0.24~15.70	1.98	17(30.36)	22(39.28)	10(17.86)	7(12.50)
	(6.5, 7.5]	43	0.32~6.61	1.48	24(55.81)	6(13.95)	10(23.26)	3(6.98)
	>7.5	1	0.67	0.67	1(100)	0(0)	0(0)	0(0)
区域总体评价	5.26~7.58	106	0.24~15.70	1.85	42(39.62)	29(27.36)	22(20.76)	13(12.26)

皖江经济带土壤Cd空间分布特征与生态风险评价

Spatial distribution characteristic of Cd in soils and its ecological risk assessment in the economic belt of Yangtze River in Anhui

RichHTML

PDF (PC)

赞

可视化

摘要/Abstract

引用本文

使用本文

图/表 7

参考文献 26

相关文章 15

Metrics

本文评价

推荐阅读 0

区域	pH	样本数/个	I_geo 范围	I_geo 平均值	样本超标数/个 (超标率/%)
区域	pH	样本数/个	I_geo 范围	I_geo 平均值	无污染	轻污染	偏中度污染	中度污染	偏重污染	重污染	严重污染
A	(5.5, 6.5]	20	-1.79~2.67	0.76	4(20.00)	6(30.00)	8(40.00)	2(10.00)	0(0)	0(0)	0(0)
A	(6.5, 7.5]	15	-0.06~2.49	1.41	1(6.67)	3(20.00)	8(53.33)	3(20.00)	0(0)	0(0)	0(0)
总体评价	5.99~6.98	35	-1.79~2.67	1.35	5(14.29)	9(25.71)	16(45.71)	5(14.29)	0(0)	0(0)	0(0)
B	≤5.5	5	-0.12~3.28	1.28	1(20.00)	2(40.00)	1(20.00)	0(0)	1(20.00)	0(0)	0(0)
	(5.5, 6.5]	21	-0.07~3.00	1.74	1(4.76)	3(14.29)	7(33.33)	9(42.86)	1(4.76)	0(0)	0(0)
	(6.5, 7.5]	8	0.82~3.72	2.25	0(0)	1(12.50)	2(25.00)	4(50.00)	1(12.50)	0(0)	0(0)
总体评价	5.06~7.36	34	-0.12~3.72	2.07	2(5.88)	6(17.65)	10(29.41)	13(38.24)	3(8.82)	0(0)	0(0)
C	≤5.5	6	1.16~3.89	2.54	0(0)	0(0)	1(16.67)	3(50.00)	2(33.33)	0(0)	0(0)
	(5.5, 6.5]	56	-0.67~5.33	1.86	2(3.57)	7(12.50)	26(46.43)	14(25.00)	3(5.36)	3(5.36)	1(1.78)
	(6.5, 7.5]	43	0.29~4.67	2.10	0(0)	5(11.63)	19(44.19)	6(13.95)	11(25.58)	2(4.65)	0(0)
	>7.5	1	1.79	1.79	0(0)	0(0)	1(100)	0(0)	0(0)	0(0)	0(0)
总体评价	5.26~7.58	106	-0.67~5.33	2.43	2(1.89)	12(11.32)	47(44.34)	23(21.70)	16(15.09)	5(4.72)	1(0.94)
