全球能源安全的格局演变与地缘博弈

doi:10.31497/zrzyxb.20201105

摘要/Abstract

摘要：

受经济全球化影响,国家能源安全问题的国际化趋势日益突出。21世纪以来,伴随世界多极化加速发展,世界能源安全格局演变特征及其驱动机制成为能源地缘政治研究的关键问题之一。基于这一认识,对2000年以来全球124个国家能源安全状态进行了系统评价,揭示了世界能源安全空间格局的演变特征及主要形成机制,并提出了未来能源地缘政治的博弈焦点。结果显示：（1）自21世纪初以来,全球能源安全格局演变整体上不断优化,但呈现出明显的阶段性特征,即2010年以来,全球能源安全格局优化趋势更为显著。（2）世界能源安全格局与国际地缘秩序区划基本吻合,即能源安全型国家集中分布在西欧和北美经济发达地区,较安全型国家主要分布在中欧、拉丁美洲以及亚洲高收入地区,过渡型国家主要分布在中东、东南欧以及东亚等能源体系亟需转型的地区,而较危险和危险型国家集中分布在南亚以及非洲经济欠发达地区。（3）近20年以来,世界能源安全水平显著提升主要得益于发达经济体能源使用安全维度的良好表现,而发展中国家由于创新能力较低、生产力较落后、居民可支配收入较少,其能源安全水平提升空间较小。（4）当前及今后一段时期内,全球能源安全格局将受到中美关系变化的冲击、能源转型的胁迫以及政治环境不确定性的影响。

关键词: 能源安全, 格局演变, 地缘博弈, 全球

Abstract:

Under the background of economic globalization, the internationalization of national energy security issues has become increasingly prominent. Since the beginning of the 21st century, along with the acceleration of world multi-polarization, the study on the evolution characteristics of global energy security's pattern and its driving mechanism has become one of the key issues in the field of energy geopolitics. Based on this understanding, this paper systematically evaluates the energy security status of 124 countries since 2000, reveals the evolution characteristics and its mechanism, and identifies the major geopolitical threats. The results show that: (1) Since the beginning of the 21st century, the evolution of the global energy security pattern has been continuously optimized, but it has shown obvious phase characteristics. Since 2010, the optimization trend has become more significant. (2) The global energy security pattern is basically consistent with the international order, that is, energy-safe countries are concentrated in economically developed regions of Western Europe and North America, and the relatively safe countries are mainly distributed in Central Europe, Latin America, and high-income regions in Asia. The countries with transitional energy system are mainly distributed in the developing regions of Middle East, Southeast Europe, and East Asia, while countries with dangerous or relatively dangerous energy system are economically underdeveloped regions in Africa and South Asia. (3) In the past 20 years, the world's energy security level has improved significantly, which is mainly driven by climate-friendly green technologies and the continuous downturn in oil price. For this reason, the level of energy security in developed economies has increased significantly. However, due to the low innovation capacity, backward productivity, and low disposable income of residents, developing countries have less room for improvement in energy security. (4) In the context of the rise of populism, the intensification of trade barriers and the strategic contraction of the United States in the Middle East, the global energy security pattern in the future will be affected by the changes in China-US relation, the increasing urgency to promoting the energy transition, and the polarized political climate.

Key words: energy security, pattern evolution, geopolitical game, global scale

苏俊, 王永洵, 王强. 全球能源安全的格局演变与地缘博弈[J]. 自然资源学报, 2020, 35(11): 2613-2628.

SU Jun, WANG Yong-xun, WANG Qiang. Pattern evolution of global energy security and the geopolitical game[J]. JOURNAL OF NATURAL RESOURCES, 2020, 35(11): 2613-2628.

图/表 11

表1

图1

表2

图2

图3

图4

图5

图6

图7

图8

图9

参考文献 52

[1]	BAZILIAN M, BRADSHAW M, GOLDTHAU A, et al. Model and manage the changing geopolitics of energy. Nature, 2019,569:29-31. doi: 10.1038/d41586-019-01312-5 pmid: 31043726
[2]	COLGAN J D. Fueling the fire: Pathways from oil to war. International Security, 2013,38(2):147-180.
[3]	林初昇. 去中心化和(逆)全球化背景下中国人文地理学的批判性理论探索与方法创新. 热带地理, 2019,39(5):1-9.
	[ LIN C S. Critical theoretical engagements and methodological innovation for China's human geography in a decentering and (anti) globalizing world. Tropical Geography, 2019,39(5):1-9.]
[4]	沈镭, 张红丽, 钟帅, 等. 新时代下中国自然资源安全的战略思考. 自然资源学报, 2018,33(5):721-734.
	[ SHEN L, ZHANG H L, ZHONG S, et al. Strategic thinking on the security of natural resources of China in the New Era. Journal of Natural Resources, 2018,33(5):721-734.]
[5]	沈镭. 三十年来中国自然资源学会的发展与展望. 自然资源学报, 2013,28(9):1464-1478.
	[ SHEN L. Some thoughts on development and prospects of its thirties years of China Society of Natural Resources (CSNR). Journal of Natural Resources, 2013,28(9):1464-1478.]
[6]	董锁成, 石广义, 沈镭, 等. 我国资源经济与世界资源研究进展及展望. 自然资源学报, 2010,25(9):1432-1444.
	[ DONG S C, SHI G Y, SHEN L, et al. Progress and its prospects of research on resource economics and world resources in China. Journal of Natural Resources, 2010,25(9):1432-1444.]
[7]	彭焜, 朱鹤, 王赛鸽, 等. 基于系统投入产出和生态网络分析的能源—水耦合关系与协同管理研究: 以湖北省为例. 自然资源学报, 2018,33(9):1514-1528.
	[ PENG K, ZHU H, WANG S G, et al. Energy-water nexus in Hubei province based on system input-output analysis and ecological network analysis. Journal of Natural Resources, 2018,33(9):1514-1528.]
[8]	张雷, 黄园淅, 杨波, 等. 国家能源供应时空协调: 基本概念、理论与方法. 自然资源学报, 2012,27(4):529-539.
	[ ZHANG L, HUANG Y X, YANG B, et al. Time-space coordination of national energy supply. Journal of Natural Resources, 2012,27(4):529-539.]
[9]	吴初国, 何贤杰, 盛昌明, 等. 能源安全综合评价方法探讨. 自然资源学报, 2011,26(6):964-970.
	[ WU C G, HE X J, SHENG C M, et al. Comprehensive method for evaluation energy security. Journal of Natural Resources, 2011,26(6):964-970.]
[10]	International Energy Agency (IEA). Energy Technology Policy. Paris: OECD/IEA, 1985: 29.
[11]	BOHI D R, TOMAN M A. The Economics of Energy Security. Boston: Kluwer Academic Publishers, 1996: 13-15.
[12]	DORIAN J P, FRANSSEN H T, SIMBECK D R. Global challenges in energy. Energy Policy, 2006,34(15):1984-1991.
[13]	BIELECKI J. Energy security: Is the wolf at the door?. The Quarterly Review of Economics and Finance, 2002,42(2):235-250.
[14]	MULLER-KRAENNER S. Energy Security: Remeasuring the World. London: Earthscan Publications, 2008: 19-23.
[15]	CHESTER L. Conceptualising energy security and making explicit its polysemic nature. Energy policy, 2010,38(2):887-895.
[16]	CABALU H. Indicators of security of natural gas supply in Asia. Energy Policy, 2010,38(1):218-225.
[17]	BADEA A C, TARANTOLA S, BOLADO R. Composite indicators for security of energy supply using ordered weighted averaging. Reliability Engineering & System Safety, 2011,6(6):651-662.
[18]	Asia Paciﬁc Energy Research Centre (APERC). A quest for energy security in the 21st century. Tokyo: Institute of Energy Economics, Asia Paciﬁc Energy Research Centre, 2007: 5-8.
[19]	International Energy Agency (IEA). World energy outlook. https://www.iea.org/topics/energysecurity/what is energy security: 2019-11-22.
[20]	BANG G. Energy security and climate change concerns: Triggers for energy policy change in the United States?. Energy Policy, 2010,38(4):645-1653.
[21]	BROWN M A, DWORKIN M. The environmental dimension of energy security. In: SOVACOOL B. (Ed.). The Routledge Handbook of Energy Security. London: Routledge, 2011: 35-36.
[22]	SOVACOOL B K. The importance of scale to energy security. Journal of Integrative Environmental Sciences, 2012,9(3):167-180.
[23]	刘立涛, 沈镭, 高天明, 等. 中国能源安全评价及时空演进特征. 地理学报, 2012,67(12):1634-1644.
	[ LIU L T, SHEN L, GAO T M, et al. Evaluation and spatial-temporal evolution of energy security in China. Acta Geographica Sinica, 2012,67(12):1634-1644.]
[24]	LESBIREL S H. Diversification and energy security risks: The Japanese case. Japanese Journal of Political Science, 2004,5(1):1-22.
[25]	VIVODA V. Evaluating energy security in the Asia-Pacific region: A novel methodological approach. Energy Policy, 2010,38(9):5258-5263.
[26]	SOVACOOL B K. Evaluating energy security in the Asia Pacific: Towards a more comprehensive approach. Energy Policy, 2011,39(11):7472-7479.
[27]	WANG Q, ZHOU K. A framework for evaluating global national energy security. Applied Energy, 2017,188:19-31.
[28]	WANG Q, XU L L, LI N, et al. The evolution of the spatial-temporal patterns of global energy security since the 1990s. Journal of Geographical Sciences, 2019,29:1245-1260.
[29]	GASSER P. A review on energy security indices to compare country performances. Energy Policy, 2020,139:1-17.
[30]	SCHEEPERS M, SEEBREGTS A, DE JANG J, et al. EU standards for energy security of supply, ECN/Clingendael International Energy Program. Petten. The Netherlands: European Commission, Directorate-General for Energy and Transport, 2007: 15-16.
[31]	JANSEN J C. Energy services security: Some metrics and policy issues. In: Proceedings of the 4th Conference on Energy Economics and Technology. Dresden, 2009: 7-8.
[32]	DUNN L, DUNN R. Washington & Jefferson College Energy Index. Washington & Jefferson College, 2012: 5-16.
[33]	International Energy Agency (IEA). Energy Supply Security: The emergency response of IEA countries. 2014 Ed. Paris, France, 2014: 3-6.
[34]	LE COQ C, PALTSEVA E. Measuring the security of external energy supply in the European Union. Energy Policy, 2011,37:4474-4481.
[35]	GUPTA E. Oil vulnerability index of oil-importing countries. Energy Policy, 2008,36:1195-1211.
[36]	GNANSOUNOU E. Assessing the energy vulnerability: Case of industrialized countries. Energy Policy, 2008,36:3734-3744.
[37]	GNANSOUNOU E. Indicators of Energy Vulnerability. London: UK: World Energy Council, 2009: 21-23.
[38]	International Energy Agency (IEA). The IEA Model of Short-term Energy Security, 2011. https: //www.iea.org/reports/ the-iea-model-of-short-term-energy-security: 2019-11-23.
[39]	CHERP A. Energy and Security: Toward a Sustainable Future. Edited by JOHANSSON T B, PATWARDHAN A, NAKICENOVIC N, et al. Cambridge: Cambridge University Press, 2012: 325-334.
[40]	MUñOZ-DELGADO B. Energy security indices in Europe.Economic Challenges for Energy-Workshop. Madrid, Spain, February 7-8th, 2011.
[41]	U.S.Chamber of Commerce's Global Energy Institute. International Index of Energy Security Risk: 2020 Edition. Washington DC: US Chamber of Commerce, 2020: 17-25.
[42]	VON HIPPEL D, SUZUKI T, WILLIAMS J H, et al. Energy security and sustainability in Northeast Asia. Energy Policy, 2013,39:6719-6130.
[43]	European Commission's Joint Research Centre. Risk of Energy Availability Common Corridors for Europe Supply Security, Summary Report. Project funded by EC FP7 under the theme "Energy Security of Supply". Final Workshop, Brussels May 13th, 2011. https://cordis.europa.eu/project/id/212011, 2019-11-25.
[44]	ANG B W, CHOONG W L, NG T S. A framework for evaluating Singapore's energy security. Applied Energy, 2015,148:314-325.
[45]	World Energy Council. World Energy Trilemma Index 2019. https://trilemma.worldenergy.org/reports/main/2019/2019%20Energy%20 Trilemma%20Index.pdf, 2019-11-18.
[46]	徐玲琳, 王强, 李娜, 等. 20世纪90年代以来世界能源安全时空格局演化过程. 地理学报, 2017,72(12):2166-2178.
	[ XU L L, WANG Q, LI N, et al. Spatial-temporal evolution of global energy security since 1900s. Acta Geographica Sinica, 2017,72(12):2166-2178.]
[47]	DOBRIC' J, SCHMID F. A goodness of fit test for copulas based on rosenblatts' transformation. Computational Statistics & Data Ana lysis, 2007,51(9):4633-4642.
[48]	任仙玲, 张世英. 基于非参数核密度估计的Copula函数选择原理. 系统工程学报, 2010,25(1):36-42.
	[ REN X L, ZHANG S Y. Copula function selection criterion based on nonparametric kernel density estimation. Journal of Systems Engineering, 2010,25(1):36-42.]
[49]	申鹏, 张晓宇, 张婉玉. 中国城乡居民收入的分布动态演进: 1985—2017. 经济论坛, 2019, (11):15-23.
	[ SHEN P, ZHANG X Y, ZHANG W Y. The dynamic evolution of the income distribution of urban and rural residents in China: 1985-2017. Economic Forum, 2019, (11):15-23.]
[50]	International Energy Council. Statistics. https://www.iea.org/classicstats/statisticssearch/report/?country=AUSTRALI&product=balances& year=2015&country=AUSTRALI&product=balances&year=2015, 2019-11-18.
[51]	The World Bank. World Bank Open Data. http://data.worldbank.org/, 2019-11-18.
[52]	The World Bank. World Development Indicators. http://data.worldbank.org.cn/data-catalog/world-development-indicators, 2019-11-18.

目标层	维度层	指标层	单位	权重/%		说明
目标层	维度层	指标层	单位	维度层	指标层	说明
能源安全综合指数	供应维度	一次能源生产量与消费量之比	—	35	7	供应维度用以描述和评价区域能源系统应对能源供给—需求关系失调的能力
		能源供应多样性系数	—		7
		电力多样性系数	—		7
		原油储备量	亿桶		7
		天然气储备量	万亿立方英尺		7
	普惠维度	通电率	%	18	6	普惠维度用以表征能源系统满足区域生产、生活用能需求的综合能力
		汽油零售价格	美元/升		6
		非固态燃料获得率	%		6
	使用维度	化石能源所占比例	%	32	8	使用维度用以测度区域能源使用的环境效应
		可再生能源发电所占比例	%		8
		碳排放因子	t/t油当量		8
		能源效率	10³美元/t油当量（已转换为2011年不变价）		8
	发展环境	政治稳定性	—	15	2	发展环境主要是指区域能源发展的社会、政治与经济环境,其优劣程度显著影响着国家在能源市场中的话语权,以及本地能源政策制定与能源部门投资,继而影响着自身能源安全水平
		管理水平	—		2
		政府效率	—		2
		法律角色	—		2
		腐败控制	—		2
		人均GDP	美元（已转换为2011年不变价）		5
