基于生态约束的城市开发边界模拟研究——以南京为例

doi:10.31497/zrzyxb.20211114

摘要/Abstract

摘要：

城市开发边界划定是国土空间规划的重要内容,也是实施国土空间管治、城乡建设管理和生态安全管控的关键抓手,对于推动城市空间高质量发展具有基础性和约束性作用。综合利用回归分析模型、InVEST模型和CA模型,探索构建基于生态约束的城市开发边界划定方法,并以南京市中心城区为例,在评价城市生态用地重要性和建设用地空间扩展潜力基础上,开展不同目标年份的城市用地扩张模拟,据此划定城市开发边界。研究表明：城市建设用地扩张具有动态性、复杂性、系统性特征,受到多因子相互作用,基于生态约束的城市开发边界模拟能够兼顾城市空间发展需求和居民高品质生态环境诉求,促进城市发展与生态保护相统一、人口经济和资源环境相协调,有助于丰富城市开发边界划定方法研究,为国土空间规划编制提供科学参考。

关键词: 城市开发边界, 生态约束, 扩张潜力, 模型模拟, 空间管控

Abstract:

The delineation of urban development boundary is an important part of land spatial planning, and also a key to the implementation of land spatial governance, urban and rural development management, and ecological security management and control. It plays a fundamental and restrictive role in promoting the high-quality development of urban space. This article takes the central urban area of Nanjing as an example, and the logistic regression analysis model, InVEST model and CA model were used to explore and construct a method of urban development boundary delineation based on ecological constraints. According to the evaluation of the importance of urban ecological land and the spatial expansion potential of construction land, a simulation of urban land expansion in different target years was carried out to delineate urban development boundary. The results show that the expansion of urban construction land has dynamic, complex and systematic characteristics, and is subject to multi-factor interactions. The urban development boundary simulation based on ecological constraints can take into account the needs of urban space development and residents' high-quality ecological environment demands, promote the unification of urban development and ecological protection, the coordination of population economy and resources and the environment, and help enrich the delineation methods of urban development boundary research, which provide scientific reference for the preparation of land spatial planning.

Key words: urban development boundary, ecological constraints, expansion potential, model simulation, space control

孙伟, 刘崇刚, 王苏宁. 基于生态约束的城市开发边界模拟研究——以南京为例[J]. 自然资源学报, 2021, 36(11): 2913-2925.

SUN Wei, LIU Chong-gang, WANG Su-ning. Simulation research of urban development boundary based on ecological constraints: A case study of Nanjing[J]. JOURNAL OF NATURAL RESOURCES, 2021, 36(11): 2913-2925.

图/表 10

图1

图2

表1

图3

表2

图4

图5

图6

图7

图8

参考文献 38

[1]	丛佃敏, 赵书河, 于涛, 等. 综合生态安全格局构建与城市扩张模拟的城市增长边界划定: 以天水市规划区(2015—2030年)为例. 自然资源学报, 2018, 33(1):14-26.
	[ CONG D M, ZHAO S H, YU T, et al. Urban growth boundary delimitation method integrating comprehensive ecological security pattern and urban expansion simulation: A case study of planning areas in Tianshui city (2015-2030). Journal of Nature Resources, 2018, 33(1):14-26.]
[2]	BATTY M. New ways of looking at cities. Nature, 1995, 377(6550):574. doi: 10.1038/377574a0
[3]	LOURES L. Post-industrial landscapes as drivers for urban redevelopment: Public versus expert perspectives towards the benefits and barriers of the reuse of post-industrial sites in urban areas. Habitat International, 2015, 45:72-81. doi: 10.1016/j.habitatint.2014.06.028
[4]	STALEY S, EDGENS J G, MILDNER G C S. A line in the land: Urban-growth boundaries, smart growth, and housing affordability. Los Angels: Reason Public Policy Institute, 1999.
[5]	INGRAM G K, CARBONELL A, HONG Y H, et al. Smart growth policies: An evaluation of programs and outcomes. Cambridge, Massachusetts: Lincoln Institute of Land Policy, 2009.
[6]	BEER A. Leadership and the governance of rural communities. Journal of Rural Studies, 2014, 34:254-262. doi: 10.1016/j.jrurstud.2014.01.007
[7]	CUBUKCU K M. The problem of fair division of surplus development rights in redevelopment of urban areas: Can the Shapley value help?. Land Use Policy, 2019, 91:104320, Doi: 10.1016/j.landusepol.2019.104320. doi: 10.1016/j.landusepol.2019.104320
[8]	DONOVAN G H, LANDRY S, WINTER C. Urban trees, house price, and redevelopment pressure in Tampa, Florida. Urban Forestry & Urban Greening, 2019, 38:330-336.
[9]	ERFANI G. Sense of place as an investigative method for the evaluation of participatory urban redevelopment. Cities, 2020, 99:102648, Doi: 10.1016/j.cities.2020.102648. doi: 10.1016/j.cities.2020.102648
[10]	RENTERGHEM T V, DEKONINCK L, BOTTELDOOREN D. Multi-stage sound planning methodology for urban redevelopment. Sustainable Cities and Society, 2020, 62:102362, Doi: 10.1016/j.scs.2020.102362. doi: 10.1016/j.scs.2020.102362
[11]	TAYYEBI A, PERRY P C, TAYYEBI A H. Predicting the expansion of an urban boundary using spatial Logistic regression and hybrid raster-vector routines with remote sensing and GIS. International Journal of Geographical Information Science, 2014, 28(4):639-659. doi: 10.1080/13658816.2013.845892
[12]	CALTHORPE P, FULTON W. The Regional City. Washington D C: Island Press, 2001.
[13]	林坚, 乔治洋, 叶子君. 城市开发边界的“划”与“用”: 我国14个大城市开发边界划定试点进展分析与思考. 城市规划学刊, 2017, (2):36-43.
	[ LIN J, QIAO Z Y, YE Z J. "Delimitation" and "Implementation" of urban growth boundary: Analysis and thoughts on the practice in 14 pilot cities in China. Urban Planning Forum, 2017, (2):36-43.]
[14]	钟珊, 赵小敏, 郭熙, 等. 基于空间适宜性评价和人口承载力的贵溪市中心城区城市开发边界的划定. 自然资源学报, 2018, 33(5):83-94.
	[ ZHONG S, ZHAO X M, GUO X, et al. Delimitation of urban growth boundary based on spatial suitability evaluation and population carrying capacity in Guixi county. Journal of Natural Resources, 2018, 33(5):83-94.]
[15]	黄木易, 岳文泽, 何翔. 长江经济带城市扩张与经济增长脱钩关系及其空间异质性. 自然资源学报, 2018, 33(2):219-232.
	[ HUANG M Y, YUE W Z, HE X. Decoupling relationship between urban expansion and economic growth and its spatial heterogeneity in the Yangtze Economic Belt. Journal of Natural Resources, 2018, 33(2):219-232.]
[16]	苏伟忠, 杨桂山, 陈爽, 等. 城市增长边界分析方法研究: 以长江三角洲常州市为例. 自然资源学报, 2012, 27(2):322-331.
	[ SU W Z, YANG G S, CHEN S, et al. Analysis method of urban growth boundary of the Changzhou city in the Yangtze River Delta. Journal of Natural Resources, 2012, 27(2):322-331.]
[17]	俞孔坚, 游鸿, 许立言, 等. 北京市住宅用地开发压力与城市扩张预景: 基于阻力面的分析. 地理研究, 2012, 31(7):1173-1184.
	[ YU K J, YOU H, XU L Y, et al. A minimum cumulative resistance (MCR) analysis approach. Geographical Research, 2012, 31(7):1173-1184.]
[18]	王振波, 张蔷, 张晓瑞, 等. 基于资源环境承载力的合肥市增长边界划定. 地理研究, 2013, 32(12):2302-2311.
	[ WANG Z B, ZHANG Q, ZHANG X R, et al. Urban growth boundary delimitation of Hefei city based on the resources and environment carrying capability. Geographical Research, 2013, 32(12):2302-2311.]
[19]	黄木易, 岳文泽, 冯少茹, 等. 基于MCR模型的大别山核心区生态安全格局异质性及优化. 自然资源学报, 2019, 34(4):101-114.
	[ HUANG M Y, YUE W Z, FENG S R, et al. Analysis of spatial heterogeneity of ecological security based on MCR model and ecological pattern optimization in the Yuexi county of the Dabie Mountain Area. Journal of Natural Resources, 2019, 34(4):101-114.]
[20]	周锐, 王新军, 苏海龙, 等. 平顶山新区生态用地的识别与安全格局构建. 生态学报, 2015, 35(6):2003-2012.
	[ ZHOU R, WANG X J, SU H L, et al. Identification and security pattern of ecological land in Pingdingshan Newly Developed Area. Acta Ecologica Sinica, 2015, 35(6):2003-2012.]
[21]	王颖, 顾朝林. 基于格网分析法的城市弹性增长边界划定研究: 以苏州市为例. 城市规划, 2017, 41(3):25-30.
	[ WANG Y, GU C L. Grid-Based spacial evaluation of establishing urban growth boundary: A case study of Suzhou city. City Planning Review, 2017, 41(3):25-30.]
[22]	张亮. 基于生态安全格局的城市增长边界划定与管理研究. 杭州: 浙江大学, 2018.
	[ ZHANG L. Demarcation and management of urban growth boundary in combination with ecological security patterns. Hangzhou: Zhejiang Normal University, 2018.]
[23]	CHO S H, POUDYAL N, LAMBERT D M. Estimating spatially varying effects of urban growth boundaries on land development and land value. Land Use Policy, 2008, 25(3):320-329. doi: 10.1016/j.landusepol.2007.08.004
[24]	JIANG P H, CHENG Q W, GONG Y, et al. Using urban development boundaries to constrain uncontrolled urban sprawl in China. Annals of the Association of American Geographers, 2016, 106(6):1321-1343.
[25]	WU J S, ZHANG L Q, PENG J, et al. The integrated recognition of the source area of the urban ecological security pattern in Shenzhen. Acta Ecologica Sinica, 2013, 33(13):4125-4133. doi: 10.5846/stxb
[26]	范擎宇, 杨山. 协调视角下长三角城市群的空间结构演变与优化. 自然资源学报, 2019, 34(8):1581-1592.
	[ FAN Q Y, YANG S. Evolution and optimization of spatial structure of the Yangtze River Delta Urban Agglomeration from the perspective of coordination. Journal of Natural Resources, 2019, 34(8):1581-1592.] doi: 10.31497/zrzyxb.20190802
[27]	陈力, 关瑞明. 城市空间形态中的人类行为. 华侨大学学报: 自然科学版, 2000, 21(3):296-301.
	[ CHEN L, GUAN R M. Human behavior in urban spatial pattern. Journal of Huaqiao University: Natural Science, 2000, 21(3):296-301.]
[28]	李传华, 俞慧云, 张巧英, 等. 基于Logistic的土地利用格局模拟案例研究. 人民黄河, 2012, (10):103-105.
	[ LI C H, YU H Y, ZHANG Q Y, et al. A case study of simulation of land use patterns based on Logistic model. Yellow River, 2012, (10):103-105.]
[29]	罗平, 姜仁荣, 李红旮, 等. 基于空间Logistic和Markov模型集成的区域土地利用演化方法研究. 中国土地科学, 2010, 24(1):31-36.
	[ LUO P, JIANG R R, LI H G, et al. Research on the method of regional land use evolution based on the combination of spatial Logistic model and Markov model. China Land Science, 2010, 24(1):31-36.]
[30]	潘韬, 吴绍洪, 戴尔阜, 等. 基于InVEST模型的三江源区生态系统水源供给服务时空变化. 应用生态学报, 2013, 24(1):183-189.
	[ PAN T, WU S H, DAI E F, et al. Spatiotemporal variation of water source supply service in Three Rivers Source Area of China based on InVEST model. Chinese Journal of Applied Ecology, 2013, 24(1):183-189.]
[31]	杨园园, 戴尔阜, 付华. 基于InVEST模型的生态系统服务功能价值评估研究框架. 首都师范大学学报: 自然科学版, 2012, (3):44-50.
	[ YANG Y Y, DAI E F, FU H, et al. The assessment framework of ecosystem service value based on InVEST model. Journal of Capital Normal University: Natural Sciences Edition, 2012, (3):44-50.]
[32]	闫业超, 岳书平, 张树文. 降雨资料时间序列长度对降雨侵蚀力平均值置信度的影响. 自然资源学报, 2013, 28(2):321-327.
	[ YAN Y C, YUE S P, ZHANG S W. The confidence coefficient of mean annual rainfall erosivity influenced by record length of rainfall datasets. Journal of Natural Resources, 2013, 28(2):321-327.]
[33]	李季孝, 丁剑宏, 陶余铨, 等. 云南省土壤可蚀性及其空间分布特征. 人民黄河, 2019, (8):103-106.
	[ LI J X, DING J H, TAO Y S, et al. Soil erodibility and its spatial distribution characteristics in Yunnan province. Yellow River, 2019, (8):103-106.]
[34]	何莎莎, 朱文博, 崔耀平, 等. 基于InVEST模型的太行山淇河流域土壤侵蚀特征研究. 长江流域资源与环境, 2019, 28(2):426-439.
	[ HE S S, ZHU W B, CUI Y P, et al. Study on soil erosion characteristics of Qihe Watershed in Taihang Mountains based on the InVEST model. Resources and Environment in the Yangtze Basin, 2019, 28(2):426-439.]
[35]	党虹, 葛丽娟, 赵传燕, 等. 基于InVEST模型的称钩河流域土壤保持功能研究. 兰州大学学报: 自然科学版, 2018, 54(5):69-75.
	[ DANG H, GE L J, ZHAO C Y, et al. Soil conservation function of Chenggou River Basin based on the InVEST model. Journal of Lanzhou University: Natural Sciences, 2018, 54(5):69-75.]
[36]	马世发, 艾彬, 欧金沛. 约束性CA在城乡建设用地指标空间化中的应用. 地理科学, 2013, 36(10):91-97.
	[ MA S F, AI B, OU J P. Spatial allocation of construction land with constrained Cellular Automata Model. Scientia Geographica Sinica, 2013, 36(10):91-97.]
[37]	汪贝, 张金亭, 彭晓军. 基于约束性CA的“三规”空间管制整合引导下的城市增长模拟. 地理与地理信息科学, 2017, 33(5):69-74.
	[ WANG B, ZHANG J T, PENG X J. The simulation of urban growth induced by the spatial regulation integration of "Three Regulation" using constrained CA. Geography and Geo-Information Science, 2017, 33(5):69-74.]
[38]	王海军, 夏畅, 张安琪, 等. 基于约束性CA的大都市郊区城镇增长的情景模拟与管控: 以武汉市江夏区为例. 地理科学进展, 2016, 35(7):793-805.
	[ WANG H J, XIA C, ZHANG A Q, et al. Scenario simulation and control of metropolitan outskirts urban growth based on constrained CA: A case study of Jiangxia district of Wuhan city. Progress in Geography, 2016, 35(7):793-805.]

类别	评价因子	单位
人口	常住人口密度	人/km²
人口	人口活动分布	人/km²
经济	经济变化	亿元
区位	距市中心的距离	km
区位	距区中心的距离	km
基础设施分布	距主干道距离	km
	公交站点核密度	个/km²
	地铁站点核密度	个/km²
	医疗卫生点核密度	个/km²
	教育点核密度	个/km²
	商服点核密度	个/km²

解释变量	回归系数	标准误差	Wald统计量	自由度	显著性水平	发生比率
常住人口密度	1.42	0.27	22.63	1	<0.001	3.65
人口活动分布	17.96	4.1	41.29	1	<0.001	1.95
经济变化	3.72	0.08	290.42	1	<0.001	3.55
距区中心距离	-0.18	0.09	3.62	1	0.05	0.9
距主干道距离	-0.4	0.078	2.74	1	<0.001	0.57
公交站点核密度	0.61	0.23	4.56	1	0.006	1.92
地铁站点核密度	0.6	0.2	12.52	1	0.001	1.54
教育点核密度	-1.7	0.44	13.01	1	<0.001	0.2
常量	1.24	1.03	56.5	1	<0.001	2060.1
