煤炭资源型城市城乡空间结构演变及影响因素——以安徽省淮北市为例

doi:10.31497/zrzyxb.20211109

摘要/Abstract

摘要：

以淮北市为例,基于城乡建设用地和相关社会经济发展数据,运用扩张指数、相对变化率等方法,研究1985年以来煤炭资源型城市城乡空间结构演变过程及影响因素。结果表明：（1）煤炭资源型城市城乡空间结构演变大致经历了三个阶段：1985—2000年,城市发展主要围绕煤炭产业进行,形成了“城·矿·乡”三元结构;2000—2010年,城市主城区中心性逐渐凸显,城乡空间结构演变为“中心—外围”结构;2010年至今,城市转型发展速度加快,主城区向郊区扩散,城乡空间结构演变为圈层结构。（2）煤炭资源型城市城乡空间结构演变本质是由分散到集聚、由分离到一体的过程。（3）矿城管理体制、城乡产业结构、市域交通网络和政策制度四个影响因素相互作用,共同促进煤炭资源型城市城乡空间结构的发展。

关键词: 煤炭资源型城市, 城乡空间结构, 影响因素, 淮北市

Abstract:

This paper explored the evolution of urban-rural spatial structure in China and its influencing factors since 1985 by using the urban-rural construction land and socio-economic data, and took Huaibei, a typical coal resource-based city, as a study case. The results showed that: (1) Generally, the urban-rural spatial structure in coal resource-based city develops in three stages. Firstly, the city mainly depended on the coal industry, and formed the "urban-mining-rural" ternary structure in 1985-2000. Secondly, the urban-rural spatial structure has evolved into a "center-peripheral" structure. In addition, the centrality of the major urban area is gradually highlighted. Thirdly, the urban-rural spatial structure evolved into a circle structure in 2010-present. Moreover, the speed of city transformation and development has accelerated. And the main urban area spread to the suburbs. (2) In essence, the evolution of urban-rural spatial structure was a process from dispersion to aggregation, and from separation to integration. (3) Management system of mining city, urban-rural industrial structure, municipal transportation network and policy system interacted to promote the evolution of urban-rural spatial structure in coal resource-based cities.

Key words: coal resource-based cities, urban-rural spatial structure, influencing factor, Huaibei city

管晶, 焦华富. 煤炭资源型城市城乡空间结构演变及影响因素——以安徽省淮北市为例[J]. 自然资源学报, 2021, 36(11): 2836-2852.

GUAN Jing, JIAO Hua-fu. The evolution process and influencing factors of urban-rural spatial structure in coal resource-based city: A case study of Huaibei city in Anhui province[J]. JOURNAL OF NATURAL RESOURCES, 2021, 36(11): 2836-2852.

图/表 12

图1

图2

表1

图3

表2

图4

图5

图6

表3

图7

图8

图9

参考文献 29

[1]	朱纪广, 李小建, 王德, 等. 传统农区城乡体系空间结构演变及其形成机制研究: 以河南省周口市为例. 人文地理, 2019, 34(4):126-134.
	[ ZHU J G, LI X J, WANG D, et al. Spatial structure evolution and its mechanism of urban-rural settlement in traditional rural areas: A case study of Zhoukou city, Henan province. Human Geography, 2019, 34(4):126-134.]
[2]	刘彦随, 杨忍. 中国环渤海地区城乡发展转型格局测度. 地理学报, 2015, 70(2):248-256.
	[ LIU Y S, YANG R. The spatial pattern measure of urban-rural development transformation in the Bohai Rim Region in China. Acta Geographica Sinica, 2015, 70(2):248-256.]
[3]	杨忍, 徐茜, 李璐婷. 珠三角地区城乡空间转型过程及影响因素. 地理研究, 2016, 35(12):2261-2272.
	[ YANG R, XU Q, LI L T. Spatial urban-rural transformation and its driving factors in the Pearl River Delta Region. Geographical Research, 2016, 35(12):2261-2272.]
[4]	ARTHUR L W. Economic development with unlimited supplies of labour. The Manchester School, 1954, 22(2):139-191. doi: 10.1111/j.1467-9957.1954.tb00021.x
[5]	TACOLI C. Rural-urban interactions: A guide to the literature. Environment and Urbanization, 1998, 10(1):147-166. doi: 10.1177/095624789801000105
[6]	PAIN A. Middle India and urban-rural development: Four decades of change. Journal of South Asian Development, 2016, 11(1):141-144. doi: 10.1177/0973174116628710
[7]	李智, 张小林, 李红波, 等. 江苏典型县域城乡聚落规模体系的演化路径及驱动机制. 地理学报, 2018, 73(12):2392-2408.
	[ LI Z, ZHANG X L, LI H B, et al. Evolution paths and the driving mechanism of the urban-rural scale system at the county level: Taking three counties of Jiangsu province as an example. Acta Geographica Sinica, 2018, 73(12):2392-2408.]
[8]	郑毅. 城乡一体化视角下盘锦市域城镇空间结构重组研究. 沈阳: 沈阳建筑大学, 2012.
	[ DENG Y. Perspective of urban-rural integration research on reorganizing of spatial structure of city-town in Panjin city. Shenyang: Shenyang Jianzhu University, 2012.]
[9]	张婧, 李诚固. 中国转型期中心城市城乡关系演变. 地理学报, 2012, 67(8):1021-1030.
	[ ZHANG J, LI C G. The evolution of urban-rural relationship in central cities of China during transformation period. Acta Geographica Sinica, 2012, 67(8):1021-1030.]
[10]	周佳宁, 邹伟, 秦富仓. 等值化理念下中国城乡融合多维审视及影响因素. 地理研究, 2020, 39(8):1836-1851.
	[ ZHOU J N, ZHOU W, QIN F C. Review of urban-rural multi-dimensional integration and influencing factors in China based on the concept of equivalence. Geographical Research, 2020, 39(8):1836-1851.]
[11]	王颖, 孙平军, 李诚固, 等. 2003年以来东北地区城乡协调发展的时空演化. 经济地理, 2018, 38(7):59-66.
	[ WANG Y, SUN P J, LI C G, et al. Spatial-temporal evolution features of urban and rural harmonious in Northeast China since 2003. Economic Geography, 2018, 38(7):59-66.]
[12]	刘艳军, 于会胜, 刘德刚, 等. 东北地区建设用地开发强度格局演变的空间分异机制. 地理学报, 2018, 73(5):818-831.
	[ LIU Y J, YU H S, LIU D G, et al. Spatial differentiation mechanisms of the pattern evolution of construction land development intensity in Northeast China. Acta Geographica Sinica, 2018, 73(5):818-831.]
[13]	马晓冬, 李全林, 沈一. 江苏省乡村聚落的形态分异及地域类型. 地理学报, 2012, 67(4):516-525.
	[ MA X D, LI Q L, SHEN Y. Morphological difference and regional types of rural settlements in Jiangsu province. Acta Geographica Sinica, 2012, 67(4):516-525.]
[14]	李智, 张小林, 李红波. 县域城乡聚落规模体系的演化特征及驱动机理: 以江苏省张家港市为例. 自然资源学报, 2019, 34(1):140-152.
	[ LI Z, ZHANG X L, LI H B. Evolution characteristics and driving mechanism of urban-rural scale system at county level: A case of Zhangjiagang city, Jiangsu province. Journal of Natural Resources, 2019, 34(1):140-152.] doi: 10.31497/zrzyxb.20190112
[15]	贺艳华, 李民, 宾津佑, 等. 近10年来中国城乡一体化空间组织研究进展与展望. 地理科学进展, 2017, 36(2):219-230.
	[ HE Y H, LI M, BIN J Y, et al. Progress and prospect on spatial organization of urban-rural integration in China since 2006. Progress in Geography, 2017, 36(2):219-230.]
[16]	侯志华, 刘敏, 樊晓霞, 等. 汾河流域城乡聚落体系发展潜能测度及空间模式探究. 地理科学, 2020, 40(12):1978-1989.
	[ HOU Z H, LIU M, FAN X X, et al. Development potential and spatial pattern of urban-rural settlement system in the Fenhe River Basin. Scientia Geographica Sinica, 2020, 40(12):1978-1989.]
[17]	姜海宁, 张文忠, 余建辉, 等. 山西资源型城市创新环境与产业结构转型空间耦合. 自然资源学报, 2020, 35(2):269-283.
	[ JIANG H N, ZHANG W Z, YU J H, et al. Spatial coupling of innovative milieu and industrial structure transformation of resource-based cities in Shanxi province. Journal of Natural Resources, 2020, 35(2):269-283.] doi: 10.31497/zrzyxb.20200203
[18]	WU X, FU Y, WANG T, et al. Effects of land use transitions due to underground coal mining on ecosystem services in groundwater table areas: A case study in the Yanzhou coalfield. Land Use Policy, 2018, 71:213-221. doi: 10.1016/j.landusepol.2017.11.059
[19]	HOU Y, LONG R, CHEN H, et al. Research on the sustainable development of China's coal cities based on lock-in effect. Resources Policy, 2018, 59:479-486. doi: 10.1016/j.resourpol.2018.09.002
[20]	胡语宸, 刘艳军, 孙宏日. 城市增长与收缩的演变过程及其影响因素: 以黑龙江省煤炭资源型城市为例. 地理科学, 2020, 40(9):1450-1459.
	[ HU Y C, LIU Y J, SUN H R. Process and factors of urban growth and shrinkage: A case study of mining cities in Heilongjiang province. Scientia Geographica Sinica, 2020, 40(9):1450-1459.]
[21]	李博, 张文忠, 余建辉, 等. 能源富集区市域经济发展水平空间格局演变: 基于晋陕蒙甘宁地区. 自然资源学报, 2020, 35(3):668-682.
	[ LI B, ZHANG W Z, YU J H, et al. Spatial pattern evolution of municipal economic development in energy-rich areas: A case study of Shanxi-Shaanxi-Inner Mongolia-Gansu-Ningxia Region. Journal of Natural Resources, 2020, 35(3):668-682.] doi: 10.31497/zrzyxb.20200313
[22]	谭俊涛, 张新林, 刘雷, 等. 中国资源型城市转型绩效测度与评价. 经济地理, 2020, 40(7):57-64.
	[ TAN J T, ZHANG X L, LIU L, et al. Research on the urban transformation performance of China's resource-based cities. Economic Geography, 2020, 40(7):57-64.]
[23]	杨显明, 焦华富, 许吉黎. 煤炭资源型城市空间结构演化过程、模式及影响因素: 基于淮南市的实证研究. 地理研究, 2015, 34(3):513-524.
	[ YANG X M, JIAN H F, XU J L. Study on the evolution model, process and influence factors of the coal resource-based cities' spatial structure: A case study of Huainan city. Geographical Research, 2015, 34(3):513-524.]
[24]	杨显明, 焦华富, 许吉黎. 不同发展阶段煤炭资源型城市空间结构演化的对比研究: 以淮南、淮北为例. 自然资源学报, 2015, 30(1):92-105.
	[ YANG X M, JIAO H F, XU J L. A comparative study on the urban spatial structure evolution of different kinds of coal resource-based cities: Taking Huainan and Huaibei as an example. Journal of Natural Resources, 2015, 30(1):92-105.]
[25]	景普秋. 资源型区域矿—城—乡冲突及其协调发展研究. 城市发展研究, 2013, 20(5):146-151.
	[ JING P Q. Studies on mine-urban-rural conflict and coordination development in resource-based regions. Urban Development Studies, 2013, 20(5):146-151.]
[26]	李星汐. 基于城乡一体化的煤炭资源型城市基础设施评价与规划策略研究. 徐州: 中国矿业大学, 2019.
	[ LI X X. Research on evaluation and planning strategies for infrastructures based on urban and rural integration of coal resource based cities. Xuzhou: China University of Mining and Technology, 2019.]
[27]	李怡, 刘正佳, 李裕瑞. 边境贫困县建设用地变化特征与驱动因素: 以广西龙州为例. 自然资源学报, 2018, 33(8):1291-1303.
	[ LI Y, LIU Z J, LI Y R. Spatio-temporal features and driving forces of construction land change in typical poverty-stricken border counties: A case study of Longzhou county in the Guangxi Zhuang Autonomous Region. Journal of Natural Resources, 2018, 33(8):1291-1303.] doi: 10.31497/zrzyxb.20180276
[28]	海贝贝, 李小建, 许家伟. 巩义市农村居民点空间格局演变及其影响因素. 地理研究, 2013, 32(12):2257-2269.
	[ HAI B B, LI X J, XU J W. Spatio-temporal evolution of rural settlements in Gongyi. Geographical Research, 2013, 32(12):2257-2269.]
[29]	张玉民, 郑甲苏. 煤炭资源型城市空间结构重组战略模式研究: 以山西省孝义市为例. 城市规划, 2010, 34(9):82-85.
	[ ZHANG Y M, ZHENG J S. Spatial restructuring pattern of coal resources based cities: A case study of Xiaoyi city of Shanxi province. City Planning Review, 2010, 34(9):82-85.]

时间	1985—2000年	2000—2010年	2010—2018年
发展阶段	“城·矿·乡”分离,低速均衡发展阶段	“城·矿·乡”协调,单中心集聚发展阶段	“城·矿·乡”融合,圈层扩散发展阶段
经济结构	煤炭产业一枝独大,资源依赖,产业结构单一	煤炭产业延伸,非煤产业培育,产业结构向多样化方向演变	积极培养高新技术产业,产业向多元化、高级化方向演变
要素流动	“城·矿·乡”要素互动水平低,流动速度慢,以乡村要素向城、矿系统流动为主	各要素向主城区高度集中,“城·矿·乡”要素流动壁垒打破,互动速度加快	各要素向主城区和近郊矿区集聚;城乡要素互动频繁,主城区扩散效应加强
空间分工	乡村地区传统农业;矿区煤炭产业和服务业;主城区较弱的第三产业和制造业;形成水平相对平衡的分工格局	乡村地区农业、农产品加工业;矿区煤炭产业;主城区实力较强的第三产业和制造业;形成梯度分层的分工格局	乡村地区规模农业、农副产品加工业;近郊矿区煤炭产业、制造业;主城区第三产业;形成圈层协调的分工格局
空间结构	煤炭产业繁荣,挤出制造业;经济分散化使主城区发展缓慢,规模效应减弱,形成“城·矿·乡”三元结构	主城区快速发展,带来各种要素的集聚,促进集聚效应的发挥,形成“中心—外围”结构	主城区要素向外围扩散,其周边建设新城,近郊矿区城市化,城乡联系日益密切,形成圈层结构

年份	1985	2000	2010	2018
ANN	1.261	1.255	1.251	1.230
Z	22.683	22.596	22.560	19.961
P	0.000	0.000	0.000	0.000

年份	公路里程	公路等级
年份	公路里程	一级	二级	三级	四级
2000	567	32	197	215	123
2018	4244	110.1	237.1	733.8	3163.3
