中国矿产资源基地划定指标体系构建与应用——以铁矿为例

doi:10.31497/zrzyxb.20211108

摘要/Abstract

摘要：

矿产资源基地是优化中国矿产资源勘查开发布局、保障国内资源有效供应的战略核心区域。在分析基地布局影响因素的基础上,从资源基础、开发条件、市场需求和国家战略等方面构建了矿产资源基地划定指标体系。其中资源基础包括预测资源量、查明资源储量和设计开采规模,开发条件包括缺水程度和交通优势度,市场需求包括后续冶炼加工企业布局与产值,国家战略主要体现为区域协调发展战略对矿产资源基地布局的要求。在此基础上,以铁矿为例开展了实证研究,采用聚类分析、核密度估计等方法对各单项指标进行了分析评价,在全国识别了辽宁鞍山—本溪等12个铁矿资源基地。研究结果可以为“十四五”时期中国矿产资源基地调整优化提供参考,对其他矿产资源空间政策区的划定具有一定借鉴意义。

关键词: 矿产资源基地, 指标体系, 铁矿, 核密度估计

Abstract:

Mineral resources bases are the strategic core area to optimize the layout of mineral resources exploration and development in China and ensure resources security. Based on the analysis of the influencing factors of mineral resources bases layout, this study formulated an index system to delimitate the mineral resources bases from the following four aspects: resource endowment, development conditions, market demand and national strategy. The resource endowment includes three indexes, namely, forecast resources, identified resources and development & utilization status quo; the development conditions include water shortage degree and transportation superiority; the market demand includes both the layout and output values of subsequent smelting and processing enterprises; the national strategy can be mainly reflected by the requirements of regional coordinated development strategy for the layout of mineral resources bases. On this basis, taking iron ore as an example, this paper carried out an empirical study on the delimitation of mineral resources bases to test the rationality of the index system. After evaluation of the resource endowment indexes by cluster analysis and kernel density estimation, and analysis of all the other indexes, twelve iron ore resources bases were identified through comprehensive judgment, including Anshan-Benxi of Liaoning, Eastern Hebei, Panzhihua-Xichang of Sichuan, Xinzhou-Luliang of Shanxi, Central-Western Shandong, Baotou of Inner Mongolia, Huoqiu and Ningwu-Luzong of Anhui, Southwest Hubei, Lancang of Yunnan, Tianshan and Western Kunlun of Xinjiang. The results provide some references for the adjustment and optimization of China's mineral resources bases for the "14th Five-year Plan", and might be significative to the delimitation of other mineral resources spatial policy areas.

Key words: mineral resources bases, index system, iron ore, kernel density estimation

张玉韩, 吴尚昆, 张寿庭, 王成福, 赵玉. 中国矿产资源基地划定指标体系构建与应用——以铁矿为例[J]. 自然资源学报, 2021, 36(11): 2825-2835.

ZHANG Yu-han, WU Shang-kun, ZHANG Shou-ting, WANG Cheng-fu, ZHAO Yu. The formulation and application of the index system for the delimitation of mineral resources bases in China: A case study of iron ore[J]. JOURNAL OF NATURAL RESOURCES, 2021, 36(11): 2825-2835.

图/表 7

表1

图1

图2

图3

图4

图5

图6

参考文献 50

[1]	PAULIUK S, WANG T, MÜLLER D B. Steel all over the world: Estimating in-use stocks of iron for 200 countries. Resources, Conservation and Recycling, 2013, 71:22-30. doi: 10.1016/j.resconrec.2012.11.008
[2]	沈镭, 张红丽, 钟帅, 等. 新时代下中国自然资源安全的战略思考. 自然资源学报, 2018, 33(5):721-734.
	[ SHEN L, ZHANG H L, ZHONG S, et al. Strategic thinking on the security of natural resources of China in the New Era. Journal of Natural Resources, 2018, 33(5):721-734.]
[3]	陈其慎, 于汶加, 张艳飞, 等. 资源—产业“雁行式”演进规律. 资源科学, 2015, 37(5):871-882.
	[ CHEN Q S, YU W J, ZHANG Y F, et al. Resources-industry "flying geese" evolving pattern. Resources Science, 2015, 37(5):871-882.]
[4]	王安建, 王高尚, 邓祥征, 等. 新时代中国战略性关键矿产资源安全与管理. 中国科学基金, 2019, 33(2):133-140.
	[ WANG A J, WANG G S, DENG X Z, et al. Security and management of China's critical mineral resources in the New Era. Bulletin of National Natural Science Foundation of China, 2019, 33(2):133-140.]
[5]	DAW G. Security of mineral resources: A new framework for quantitative assessment of criticality. Resources Policy, 2017, 53:173-189. doi: 10.1016/j.resourpol.2017.06.013
[6]	金碚. 关于“高质量发展”的经济学研究. 中国工业经济, 2018, (4):5-18.
	[ JIN B. Study on the "high-quality development" economics. China Industrial Economics, 2018, (4):5-18.]
[7]	曾现来, 闫晓宇, 张宇平, 等. 中国资源的进出口与产出率: 演化、挑战及对策. 自然资源学报, 2018, 33(4):552-562.
	[ ZENG X L, YAN X Y, ZHANG Y P, et al. Importation, exportation, and productivity of resources in China: Evolution, challenges, and solutions. Journal of Natural Resources, 2018, 33(4):552-562.]
[8]	习近平. 决胜全面建成小康社会夺取新时代中国特色社会主义伟大胜利: 在中国共产党第十九次全国代表大会上的报告. 北京: 人民出版社, 2017.
	[ XI J P. Determine the Victory in Building a Well-off Society in an all-round Way and Achieve Great Victory of Socialism with Chinese Characteristics in the New Era: The Report at the 19th National Congress of the Communist Party of China. Beijing: People's Publishing House, 2017.]
[9]	吴尚昆, 张玉韩. 中国矿产资源基地分布与管理政策研究. 中国工程科学, 2019, 21(1):81-87.
	[ WU S K, ZHANG Y H. Distribution and management policy of energy resource bases in China. Strategic Study of CAE, 2019, 21(1):81-87.]
[10]	王梓懿, 张京祥, 李镝. 空间政策分区的国际经验及其对主体功能区战略完善的启示., http://kns.cnki.net/kcms/detail/11.5583.TU.20200423.1700.002.html, 2020-04-23.
	[ WANG Z Y, ZHANG J X, LI D. International experience of spatial policy zoning and its enlightenment to the planning and improvement of main functional areas, http://kns.cnki.net/kcms/detail/11.5583.TU.20200423.1700.002.html, 2020-04-23.]
[11]	SHAFER C. US national park buffer zones: Historical, scientific, social, and legal aspects. Environmental Management, 1999, 23(1):49-73. doi: 10.1007/s002679900167
[12]	SHELFORD V. List of reserves that may serve as nature sanctuaries of national and international importance, in Canada, the United States, and Mexico. Ecology, 1941, 22(1):100-107.
[13]	KNIGHT A, COWLING R, ROUGET M, et al. Knowing but not doing: Selecting priority conservation areas and the research-implementation gap. Conservation Biology, 2008, 22(3):610-617. doi: 10.1111/j.1523-1739.2008.00914.x
[14]	MYERS N, MITTERMEIER R, MITTERMEIER C, et al. Biodiversity hotspots for conservation priorities. Nature, 2000, 403:853-858. doi: 10.1038/35002501
[15]	BLASI C, MARIGNANI M, COPIZ R, et al. Important plant areas in Italy: From data to mapping. Biological Conservation, 2011, 44(1):220-226.
[16]	KOYAMA Y. What is the so-called national comprehensive development plan (part one). Land Comprehensive Research, 2011, Spring:18-32.
[17]	BLOTEVOGEL H H. Neuorientierung der Raumordnungspolitik? Die neuen, Leitbilder und andlungsstrategien fiir die Raumentwicklung in Deutschland" in der Diskussion. Raumforschung und Raumordnung, 2006, 64(6):460-472. doi: 10.1007/BF03183112
	[ BLOTEVOGEL H H. A re-orientation of spatial planning policy? The new "Concepts and Action Strategies for Spatial Development in Germany" under discussion. Space Research and Spatial Planning, 2006, 64(6):460-472.]
[18]	SCOTT M, DIMITRAKOPOULOS R. Quantitative analysis of mineral resources for strategic planning: Implications for Australian geological surveys. Natural Resources Research, 2001, 10(3):159-177. doi: 10.1023/A:1012536823294
[19]	WAGNER H, TIESS G, ŠOLAR S, et al. Minerals planning policies in Europe. Materials and Geoenvironment, 2006, 52(3):607-620.
[20]	MAKAROV A. Science and technology forecasts and problems of Russia's energy development up to 2030. Herald of the Russian Academy of Sciences, 2009, 79(2):99-108. doi: 10.1134/S101933160902004X
[21]	WRIGHTON C E, BEE E J, MANKELOW J M. The development and implementation of mineral safeguarding policies at national and local levels in the United Kingdom. Resources Policy, 2014, 41:160-170. doi: 10.1016/j.resourpol.2014.05.006
[22]	NEWSHAM R, HOUGH E, MORIGI A N. Minerals safeguarding areas for Shropshire and Telford & Wrekin. http://nora.nerc.ac.uk/id/eprint/20028, 2012-10-17.
[23]	DUNN J R, CUEMAN E R, PRESTON C M. Zoning for mineral in Carroll county, Maryland. In: Proceedings of the Fourteenth Annual Forum on the Geology of Industrial Minerals. New York: State Mus. Bull., 1980: 3-5.
[24]	BAKER D, HENDY B. Planning for Sustainable Construction Aggregate Resource in Australia. In: Sidwell, Anthony Charles (Ed.), Proceedings of the Queensland University of Technology Research Week International Conference. Queensland: Queensland University of Technology, Brisbane., 2005: 4-5.
[25]	AMIRI H, SAMADIAN F, YAHOO M, et al. Natural resource abundance, institutional quality and manufacturing development: evidence from resource-rich countries. Resources Policy, 2019, 62:550-560. doi: 10.1016/j.resourpol.2018.11.002
[26]	吴钢, 魏东, 周政达, 等. 我国大型煤炭基地建设的生态恢复技术研究综述. 生态学报, 2014, 34(11):2812-2820.
	[ WU G, WEI D, ZHOU Z D, et al. A summary of study on ecological restoration technology of large coal bases construction in China. Acta Ecologica Sinica, 2014, 34(11):2812-2820.]
[27]	范继涛, 贾文龙, 薛亚洲. 浅析矿产资源储备基地选择的影响因素. 中国矿业, 2010, 19(8):12-14.
	[ FAN J T, JIA W L, XUE Y Z. Analysis on factors of mineral resources reserve base selection. China Mining Magazine, 2010, 19(8):12-14.]
[28]	陈万勇, 侯奎. 试论攀钢基地的矿产资源体系. 自然资源学报, 1990, 5(1):31-41.
	[ CHEN W Y, HOU K. On the mineral resource system of the Panzhihua Iron and Steel Base. Journal of Natural Resources, 1990, 5(1):31-41.]
[29]	李德亭, 刘建明, 袁怀雨. 关于建立大兴安岭固体矿产资源基地的探讨. 中国矿业, 2004, 13(7):3-6.
	[ LI D T, LIU J M, YUAN H Y. Discussing in founding solid mineral resource base of Daxinganling Region. China Mining Magazine, 2004, 13(7):3-6.]
[30]	肖克炎, 娄德波, 阴江宁, 等. 中国铁矿资源潜力定量分析. 地质通报, 2011, 30(5):650-660.
	[ XIAO K Y, LOU D B, YIN J N, et al. Quantified research on iron potential of China. Geological Bulletin of China, 2011, 30(5):650-660.]
[31]	梁仁彩. 试论能源基地的类型及其综合发展. 地理研究, 1985, 4(2):9-17.
	[ LIANG R C. Dealing with the division of the patterns of energy basis and its comprehensive development. Geographical Research, 1985, 4(2):9-17.]
[32]	罗德江, 程龙, 刘红军, 等. 四川省矿产资源勘查开发基地划分与评价. 四川地质学报, 2016, 36(4):689-693.
	[ LUO D J, CHENG L, LIU H J, et al. Partitioning and evaluation of mineral exploration and exploitation bases in Sichuan province. Acta Geologica Sichuan, 2016, 36(4):689-693.]
[33]	马吉宇. 基于聚类分析的我国铁矿资源勘查开发基地划分研究. 北京: 中国地质大学(北京), 2015.
	[ MA J Y. Study on division of China iron ore exploration and development base using cluster analysis. Beijing: China University of Geosciences (Beijing), 2015.]
[34]	张玉韩, 董延涛, 马吉宇. 基于核密度估计的我国铁矿资源开发基地研究. 中国矿业, 2015, 24(11):46-50.
	[ ZHANG Y H, DONG Y T, MA J Y. Research on exploitation base of iron mine resources in China using nuclear density estimation. China Mining Magazine, 2015, 24(11):46-50.]
[35]	王春艳, 牛丽贤. 基于GIS的有色金属勘查开发基地区划方法研究. 矿产勘查, 2016, 7(1):191-197.
	[ WANG C Y, NIU L X. Study on GIS-based regionalization methods for non-ferrous metal resources exploration and exploitation bases. Mineral Exploration, 2016, 7(1):191-197.]
[36]	龙如银, 杨家慧. 国家矿产资源安全研究现状及展望. 资源科学, 2018, 40(3):465-476.
	[ LONG R Y, YANG J H. Research status and prospect of national mineral resource security. Resources Science, 2018, 40(3):465-476.]
[37]	张玉韩, 侯华丽, 沈悦, 等. 乌蒙山片区矿产资源开发功能分区及扶贫政策探索. 资源科学, 2018, 40(9):1716-1729.
	[ ZHANG Y H, HOU H L, SHEN Y, et al. Study on the functional division of mineral resources development and poverty alleviation policy in Wumeng Mountain Area. Resources Science, 2018, 40(9):1716-1729.]
[38]	闫军印, 赵国杰. 区域矿产资源开发生态经济系统及其模拟分析. 自然资源学报, 2009, 24(8):1334-1342.
	[ YAN J Y, ZHAO G J. Simulating on ecological & economic system of regional mineral resources exploitation. Journal of Natural Resources, 2009, 24(8):1334-1342.]
[39]	侯华丽, 张玉韩, 吴尚昆, 等. 基于多要素的中国固体矿产资源丰度评价. 中国人口·资源与环境, 2016, 26(s2):240-244.
	[ HOU H L, ZHANG Y H, WU S K, et al. Solid mineral resources abundance evaluation in China based on multiple elements. China Population, Resources and Environment, 2016, 26(s2):240-244.]
[40]	王爱虎, 钟雨晨. 中国吸引跨国外包的经济环境和政策研究. 经济研究, 2006, (8):81-92.
	[ WANG A H, ZHONG Y C. Research on the economic environment and policies of China in attracting international outsourcing. Economic Research Journal, 2006, (8):81-92.]
[41]	金凤君, 王成金, 李秀伟. 中国区域交通优势的甄别方法及应用分析. 地理学报, 2008, 63(8):787-798.
	[ JIN F J, WANG C J, LI X W. Discrimination method and its application analysis of regional transport superiority. Acta Geographica Sinica, 2008, 63(8):787-798.]
[42]	ROSENBLATT M. Remarks on some nonparametric estimates of a density function. The Annals of Mathematical Statistics, 1956, 3:832-837.
[43]	PARZEN E. On estimation of a probability density function and mode. Annals of Mathematical Statistics, 1962, 33(3):1065-1076. doi: 10.1214/aoms/1177704472
[44]	金巍, 刘双双, 张可, 等. 农业生产效率对农业用水量的影响. 自然资源学报, 2018, 33(8):1326-1339.
	[ JIN W, LIU S S, ZHANG K, et al. Influence of agricultural production efficiency on agricultural water consumption. Journal of Natural Resources, 2018, 33(8):1326-1339.] doi: 10.31497/zrzyxb.20170690
[45]	SILVERMAN B. Density estimation for statistics and data analysis. Chapman & Hall/CRC, 1986.
[46]	周璞, 侯华丽, 吴尚昆. 我国矿产资源自然区划研究. 中国矿业, 2019, 28(2):29-33.
	[ ZHOU P, HOU H L, WU S K. Preliminary study on natural zoning of mineral resources in China. China Mining Magazine, 2019, 28(2):29-33.]
[47]	阴江宁, 肖克炎, 娄德波. 中国铁矿预测模型与资源潜力分析. 地学前缘, 2018, 25(3):107-117.
	[ YIN J N, XIAO K Y, LOU D B. Prediction model and resource potential of iron in China. Earth Science Frontiers, 2018, 25(3):107-117.]
[48]	雷岩, 刘伯恩. 构建国外矿产资源稳定供应机制的思考. 中国国土资源经济, 2014, 27(6):51-55.
	[ LEI Y, LIU B E. Establishing a steady supply mechanism of foreign mineral resources. Natural Resource Economics of China, 2014, 27(6):51-55.]
[49]	侯华丽, 吴尚昆, 王传君, 等. 基于基尼系数的中国重要矿产资源分布不均衡性分析. 资源科学, 2015, 37(5):915-920.
	[ HOU H L, WU S K, WANG C J, et al. Uneven spatial distribution analysis of important Chinese mineral resources based on Gini coefficients. Resources Science, 2015, 37(5):915-920.]
[50]	王嫱. 2018年全球铁矿资源供需形势分析. 中国国土资源经济, 2020, 33(3):59-68.
	[ WANG Q. Analysis of global supply and demand situation of iron ore resources in 2018. Natural Resource Economics of China, 2020, 33(3):59-68.]

目标层	准则层	指标层	指标功能
矿产资源基地布局	资源基础	预测资源量	反映矿产资源潜力
		查明资源储量	反映矿产资源储量
		设计开采规模	反映矿产资源产能
	开发条件	交通优势度	反映交通基础设施发展水平
	开发条件	缺水程度	反映支撑矿产开发的水资源供给条件
	市场需求	冶炼与压延加工业布局	反映产业链下游市场分布
	市场需求	冶炼与压延加工业产值	反映产业链下游市场需求程度
	国家战略	区域协调发展战略	反映国家发展战略对矿产资源勘查开发的需求
