生态—社会经济系统耦合方法在县域国土空间生态修复规划中的运用——以四川威远县为例

doi:10.31497/zrzyxb.20210910

摘要/Abstract

摘要：

国土空间规划体制具有强烈生态指向意义,生态安全已是国土空间安全的重点。以四川省威远县为研究对象,针对县域生态国土空间的生态资源破坏、生态系统紊乱等问题,利用生态—社会经济系统耦合方法,从要素修复、结构优化、系统价值提升三个角度构筑系统耦合度评价指标体系,计算系统耦合度及子系统综合功效,综合耦合系统时空格局变化分析得出县域生态修复安全目标格局与生态修复对策。研究结果表明：（1）县域生态修复规划具有目标多层次性、系统复合性及途径多样化性,可从宏、中、微观层级提出对策。（2）系统耦合度在0.457~0.497区间浮动,耦合系统现处于拮抗时期向磨合时期发展。（3）依据系统耦合度、子系统综合功效及指标影响度构建“点—线—面”的生态修复格局。研究提出应对县域尺度的生态修复专项规划方法和实践运用,可为当前县域国土空间规划编制提供新的思路和方法。

关键词: 生态—社会系统, 县域, 国土空间生态修复, 威远县

Abstract:

With the transformation brought by the renewal and reform of territorial space planning, the improvement of the value of territorial ecological space, the construction of security pattern and the integrated development of multiple elements are becoming more and more important. The establishment of the national territory development planning system is the great ecological significance, and ecological priority is the core value of the formation of the national territory development planning system. Among them, the ecological restoration planning at the county level is an important part of the current national territory development planning. This study takes the land space of Weiyuan county, Sichuan as the research object, analyzes its serious problems of ecological resources destruction, ecosystem disruption, and low ecological efficiency in the background of industrialization and urbanization. It is pointed out that the construction of ecological security pattern is the goal orientation of national territory ecological restoration planning, and the evaluation index system of coupling degree is constructed by using the coupling method of eco-socioeconomic system. From the three aspects of the restoration of ecological elements, the optimization of ecological structure and the promotion of ecosystem value, combined with the typical ecological engineering technology, the ecological restoration security pattern composed of point, line and area is constructed, and the countermeasures of ecological management and restoration are proposed. The results show that: (1) The ecological restoration planning of counties has the characteristics of multi-level objectives, system complexity and diversity of approaches, and the response planning countermeasures can be put forward from the macro, meso and micro levels. (2) The coupling degree of eco-socioeconomic system in Weiyuan fluctuates between 0.457 and 0.497, and the ecosystem and socioeconomic system are now in an antagonistic period and have a development trend in the running-in period. (3) According to the calculation results of coupling degree, comprehensive efficacy and index influence degree, the overall pattern of ecological restoration of "multi-corridor and multi-point, two veins and two rings, one screen and two areas" can be constructed. The study puts forward the special planning methods and practical application of ecological restoration at the county scale, which can provide new ideas and methods for the current national territory spatial ecological restoration planning system of counties.

Key words: eco-sociosystem, county, ecological restoration of territorial space, Weiyuan county

杨培峰, 焦泽飞. 生态—社会经济系统耦合方法在县域国土空间生态修复规划中的运用——以四川威远县为例[J]. 自然资源学报, 2021, 36(9): 2308-2319.

YANG Pei-feng, JIAO Ze-fei. Application of coupling method of eco-socioeconomic system in national territory spatial ecological restorationplanning system of counties:A case study of Weiyuan county[J]. JOURNAL OF NATURAL RESOURCES, 2021, 36(9): 2308-2319.

图/表 11

图1

图2

Table 1

表2

表3

图3

图4

图5

图6

图7

图8

参考文献 16

[1]	强海洋. 生态国土建设思路与方向研究. 国土资源情报, 2018, (5):15-21.
	[ QIANG H Y. Research on the thinking and direction of ecological land construction. Land and Resources Information, 2018, (5):15-21.]
[2]	强海洋. 生态文明视野下的国土空间规划再认识. 中国土地, 2020, (1):26-28.
	[ QIANG H Y. Re-recognition of land and space planning from the perspective of ecological civilization. China Land, 2020, (1):26-28]
[3]	陈从喜, 马永欢, 王楠, 等. 生态国土建设的科学内涵和基本框架. 资源科学, 2018, 40(6):1130-1137.
	[ CHEN C X, MA Y H, WANG N, et al. Scientific connotation and basic paths for constructing ecological land. Resources Science, 2018, 40(6):1130-1137.]
[4]	王军, 应凌霄, 钟莉娜. 新时代国土整治与生态修复转型思考. 自然资源学报, 2020, 35(1):26-36.
	[ WANG J, YING L X, ZHONG L N. Thinking for the transformation of land consolidation and ecological restoration in the New Era. Journal of Natural Resources, 2020, 35(1):26-36.]
[5]	曹宇, 王嘉怡, 李国煜. 国土空间生态修复: 概念思辨与理论认知. 中国土地科学, 2019, 33(7):1-10.
	[ CAO Y, WANG J Y, LI G Y. Ecological restoration for territorial space: Basic concepts and foundations. China Land Science, 2019, 33(7):1-10.]
[6]	关文彬, 谢春华, 马克明, 等. 景观生态恢复与重建是区域生态安全格局构建的关键途径. 生态学报, 2003, 23(1):64-73.
	[ GUAN W B, XIE C H, MA K M, et al. A vital method for constructing regional ecological security pattern: Landscape ecological restoration and rehabilitation. Acta Ecologica Sinica, 2003, 23(1):64-73.]
[7]	WALTERS G, BARUAH M, KARAMBIRI M, et al. The power of choice: How institutional selection influences restoration success in Africa. Land Use Policy, 2019, 9:1-12.
[8]	RYDSTEDT L W, JOHNSEN S A K. Towards an integration of recovery and restoration theories. Heliyon, 2019, 5(7):1-7.
[9]	易行, 白彩全, 梁龙武, 等. 国土生态修复研究的演进脉络与前沿进展. 自然资源学报, 2020, 35(1):37-52.
	[ YI X, BAI C Q, LIANG L W, et al. The evolution and frontier development of land ecological restoration research. Journal of Natural Resources, 2020, 35(1):37-52.]
[10]	宓泽锋, 曾刚, 尚勇敏, 等. 中国省域生态文明建设评价方法及空间格局演变. 经济地理, 2016, 36(4):15-21.
	[ MI Z F, ZENG G, SHANG Y M, et al. The evaluation method and spatial pattern evolution of ecological civilization construction of Chinese provinces. Economic Geography, 2016, 36(4):15-21.]
[11]	李智, 张小林. 江苏省县域生态经济系统协调度的空间分异及影响因素. 水土保持研究, 2017, 24(6):209-215.
	[ LI Z, ZHANG X L. Spatial differentiation and influencing factors of eco-economic harmony at county level in Jiangsu province. Research of Soil and Water Conservation, 2017, 24(6):209-215.]
[12]	黎晓亚, 马克明, 傅伯杰, 等. 区域生态安全格局: 设计原则与方法. 生态学报, 2004, 24(5):1055-1062.
	[ LI X Y, MA K M, FU B J, et al. The regional pattern for ecological security (RPES): Designing principles and method. Acta Ecologica Sinica, 2004, 24(5):1055-1062.]
[13]	袁少雄, 陈军, 宫清华, 等. 基于Apache Spark机器学习的生态安全格局构建方法. 生态学报, 2019, 39(13):4793-4805.
	[ YUAN S X, CHEN J, GONG Q H, et al. An ecological security pattern construction method based on Apache Spark machine learning. Acta Ecologica Sinica, 2019, 39(13):4793-4805.]
[14]	彭建, 吕丹娜, 董建权, 等. 过程耦合与空间集成:国土空间生态修复的景观生态学认知. 自然资源学报, 2020, 35(1):3-13.
	[ PENG J, LYU D N, DONG J Q, et al. Processes coupling and spatial integration: Characterizing ecological restoration of territorial space in view of landscape ecology. Journal of Natural Resources, 2020, 35(1):3-13.]
[15]	方恺, 吴次芳, 董亮. 城市化进程中的土地自然资本利用动态分析. 自然资源学报, 2018, 33(1):1-13.
	[ FANG K, WU C F, DONG L. The use of land natural capital in the context of urbanization. Journal of Natural Resources, 2018, 33(1):1-13.]
[16]	刘耀彬, 李仁东, 宋学锋. 中国城市化与生态环境耦合度分析. 自然资源学报, 2005, 20(1):105-112.
	[ LIU Y B, LI R D, SONG X F. Analysis of coupling degrees of urbanization and ecological environment in China. Journal of Natural Resources, 2005, 20(1):105-112.]

子系统	指标	权重
生态	土地覆盖指数A₁	0.121
	工业用地面积比A₂	0.121
	林草业用地面积比A₃	0.022
	水面率A₄	0.028
	湿地面积比A₅	0.028
	地形起伏指数A₆	0.021
	植被覆盖率A₇	0.136
	人均公园绿地面积A₈	0.026
	土地退化指数A₉	0.148
社会经济	人口增长率B₁	0.056
	GDP增长率B₂	0.074
	第三产业产值增长率B₃	0.069
	第二产业产值增长率B₄	0.065
	城市化率B₅	0.086

耦合度取值	耦合等级	耦合特征
C=0	最小耦合	系统之间或内部要素之间为无关状态,系统将无序发展
0<C≤0.3	低水平耦合	经济发展水平低,生态系统承载力强
0.3<C≤0.5	拮抗	经济进入快速发展时期,生态承载力下降
0.5<C≤0.8	磨合	经济与生态开始出现良性共振
0.8<C<1	高水平耦合	社会经济与生态相互促进
C=1	最大耦合	耦合度最大,系统之间或系统内部要素之间达到共振耦合,系统趋向新有序结构

耦合等级	生态系统空间结构	生态—社会系统空间结构	社会经济系统结构	空间变化特征
低水平耦合时期（0<C≤0.3）				系统耦合空间被必要基础设施建设,呈割裂趋势
拮抗时期（0.3<C≤0.5）				系统耦合空间被大量建设性破坏,呈破碎化趋势
磨合时期（0.5<C≤0.8）				系统耦合空间被强人工干预修复,呈点状修复趋势
高水平磨合时期（0.8<C<1）				系统耦合空间结合宏观调控,出现新型生态系统“斑块—廊道—基质” 趋势
