辽西北春玉米旱灾灾损风险区划

doi:10.31497/zrzyxb.20210519

摘要/Abstract

摘要：

开展干旱风险区划研究,对实现抗旱减灾及粮食稳产增产至关重要。以辽西北为研究区域,以作物水分亏缺指数（CWDI）为干旱表征指标,利用该区1965—2019年逐日气象数据及多年玉米种植资料,通过数理统计和通径分析方法揭示研究区玉米干旱时空演变及对各气象因子的响应特征,在此基础上构建干旱灾损指数进行旱灾风险区划,结果表明:（1）近54年春玉米抽穗—成熟期CWDI值以2.2/10 a的速率上升,其他生育阶段呈下降趋势,空间上干旱频率由辽西向辽北递减;（2）相对湿度和降水量与CWDI指数呈明显负相关,其他气象因子呈正相关,其中气温和相对湿度对其直接影响最大;（3）辽西北分四个灾损风险区,且风险程度由辽北向辽西递增。研究结果可为优化春玉米农田管理和防灾减灾提供一定参考。

关键词: CWDI, 时空变化, 影响因素, 灾损风险区划, 辽西北地区

Abstract:

The research on divisions of drought risk is vital to reducing drought disasters and increasing grain yield. In this paper, crop water deficit index (CWDI) was used as a drought index in the northwestern Liaoning province. Based on the daily meteorological data from 1965-2019 and the data of maize planting over years, the spatial and temporal evolution of maize drought and the response characteristics of meteorological factors were revealed by mathematical statistics and path analysis. And the drought risk regionalization was carried out by constructing the drought disaster loss model. The results showed that: (1) In the past 54 years, the CWDI of spring maize during the heading-maturation period increased at a rate of 2.2/10 a, and the other growth stages showed a downward trend. And the spatial distribution of drought frequency of spring maize in the study area gradually increased from north to west. (2) Relative humidity and precipitation are negatively correlated with CWDI, while other meteorological factors are positively correlated; among which temperature and relative humidity have direct influence on it. (3) Northwestern Liaoning is divided into four disaster risk areas, and the degree of drought disaster risk shows an increasing trend from north to west. The research results can provide some reference for spring maize field management and disaster prevention and mitigation.

Key words: CWDI, spatio-temporal evolution, influencing factor, risk zoning of drought disaster loss, Northwestern Liaoning province

曹永强, 路洁, 冯兴兴. 辽西北春玉米旱灾灾损风险区划[J]. 自然资源学报, 2021, 36(5): 1346-1358.

CAO Yong-qiang, LU Jie, FENG Xing-xing. Risk assessment and divisions of loss caused by drought for spring maize in Northwestern Liaoning[J]. JOURNAL OF NATURAL RESOURCES, 2021, 36(5): 1346-1358.

图/表 8

图1

表1

表2

图2

图3

图4

表3

图5

参考文献 30

[1]	陈洁, 刘玉洁, 潘韬, 等. 1961—2010年中国降水时空变化特征及对地表干湿状况影响. 自然资源学报, 2019,34(11):2440-2453.
	[ CHEN J, LIU Y J, PAN T, et al. Characteristics of temporal and spatial changes of precipitation in China from 1961 to 2010 and its impact on the surface dry and wet conditions. Journal of Natural Resources, 2019,34(11):2440-2453.]
[2]	江丽, 安萍莉. 我国自然灾害时空分布及其粮食风险评估. 灾害学, 2011,26(1):48-53, 59.
	[ JIANG L, AN P L. Temporal and spatial distribution of natural disasters and food risk assessment in my country. Disaster Science, 2011,26(1):48-53, 59.]
[3]	黄岩, 李晶, 王莹, 等. 不同生育期干旱对玉米生长及产量的影响模拟. 农业灾害研究, 2019,9(6):47-49, 92.
	[ HUANG Y, LI J, WANG Y, et al. Simulation of the effect of drought on the growth and yield of maize in different growth stages. Agricultural Disaster Research, 2019,9(6):47-49, 92.]
[4]	罗纲, 阮甜, 陈财, 等. 农业干旱与气象干旱关联性: 以淮河蚌埠闸以上地区为例. 自然资源学报, 2020,35(4):977-991.
	[ LUO G, RUAN T, CHEN C, et al. The correlation between agricultural drought and meteorological drought: Taking the area above the Bengbu Gate of the Huaihe River as an example. Journal of Natural Resources, 2020,35(4):977-991.]
[5]	吴英杰, 李玮, 王文君, 等. 基于降水量距平百分率的内蒙古地区干旱特征. 干旱区研究, 2019,36(4):943-952.
	[ WU Y J, LI W, WANG W J, et al. Drought characteristics in Inner Mongolia based on the percentage of precipitation anomaly. Arid Zone Research, 2019,36(4):943-952.]
[6]	李明, 王贵文, 柴旭荣, 等. 基于空间聚类的中国东北气候分区及其气象干旱时间变化特征. 自然资源学报, 2019,34(8):1682-1693.
	[ LI M, WANG G W, CHAI X R, et al. Climatic division of Northeast China based on spatial clustering and its meteorological drought temporal change characteristics. Journal of Natural Resources, 2019,34(8):1682-1693.]
[7]	YANG X J, LIU Y, BAI W, et al. Spatiotemporal assessment of drought related to soybean production and sensitivity analysis in Northeast China. Journal of Applied Meteorology and Climatology, 2017,56(4):937-952. doi: 10.1175/JAMC-D-16-0195.1
[8]	丁怡博, 徐家屯, 李亮, 等. 基于SPEI和MI分析陕西省干旱特征及趋势变化. 中国农业科学, 2019,52(23):4296-4308.
	[ DING Y B, XU J T, LI L, et al. Analysis of drought characteristics and trend changes in Shaanxi province based on SPEI and MI. Chinese Journal of Agricultural Sciences, 2019,52(23):4296-4308.]
[9]	张强, 邹旭恺, 肖风劲. 气象干旱等级GB/T 20481-2006. 北京: 中国标准出版社, 2006: 17.
	[ ZHANG Q, ZOU X K, XIAO F J. Meteorological Drought Level GB/T 20481-2006. Beijing: China Standard Press, 2006: 17.]
[10]	刘荣花, 薛昌颖, 方文松, 等. QX/T260-2015 北方玉米干旱等级. 北京: 气象出版社, 2015.
	[ LIU R H, XUE C Y, FANG W S, et al. QX/T260-2015 Drought Rating of Northern Maize. Beijing: Meteorological Press, 2015.]
[11]	张艳红, 吕厚荃, 李森, 等. 作物水分亏缺指数在农业干旱监测中的适用性. 气象科技, 2008,36(5):596-600.
	[ ZHANG Y H, LYU H Q, LI S, et al. Applicability of crop water deficit index in agricultural drought monitoring. Meteorological Science and Technology, 2008,36(5):596-600.]
[12]	曹言, 王杰, 李尤亮, 等. 基于作物水分亏缺指数的云南省夏玉米不同生育期干旱时空特征分析. 灌溉排水学报, 2019,38(8):97-106.
	[ CAO Y, WANG J, LI Y L, et al. Analysis of the spatial and temporal characteristics of drought in different growth stages of summer maize in Yunnan province based on crop water deficit index. Journal of Irrigation and Drainage, 2019,38(8):97-106.]
[13]	吴东丽, 王春乙, 薛红喜, 等. 华北地区冬小麦干旱风险区划. 生态学报, 2011,31(3):760-769.
	[ WU D L, WANG C Y, XUE H X, et al. Drought risk zoning of winter wheat in North China. Journal of Ecology, 2011,31(3):760-769.]
[14]	魏堃, 张勃, 马尚谦, 等. 甘肃省河东地区春玉米干旱演变特征及灾损风险区划. 干旱地区农业研究, 2019,37(6):238-247.
	[ WEI K, ZHANG B, MA S Q, et al. Spring maize drought evolution characteristics and disaster risk zoning in Hedong Area of Gansu province. Agricultural Research in Arid Areas, 2019,37(6):238-247.]
[15]	陈东东, 紫檀, 张玉芳. 基于水分盈亏指数的四川省小麦生育期干旱风险评估. 自然灾害学报, 2017,26(4):155-163.
	[ CHEN D D, ZI T, ZHANG Y F. Drought risk assessment of wheat growth period in Sichuan province based on water profit and loss index. Journal of Natural Disasters, 2017,26(4):155-163.]
[16]	何鑫, 吴吉东, 李颖, 等. 基于SPEI的辽西地区气象干旱时空分布特征. 干旱区地理, 2017,40(2):340-347.
	[ HE X, WU J D, LI Y, et al. Spatial-temporal distribution characteristics of meteorological drought in Western Liaoning based on SPEI. Geography of Arid Areas, 2017,40(2):340-347.]
[17]	刘晓静, 张继权, 马东来. 基于MODIS数据的辽西北地区玉米干旱脆弱性评价研究. 中国农业资源与区划, 2016,37(11):44-49.
	[ LIU X J, ZHANG J Q, MA D L. Research on drought vulnerability assessment of maize in Northwestern Liaoning based on MODIS data. Chinese Journal of Agricultural Resources and Regional Planning, 2016,37(11):44-49.]
[18]	徐建文, 居辉, 刘勤. 黄淮海平原典型站点冬小麦生育阶段的干旱特征及气候趋势的影响. 生态学报, 2014,34(10):2765-2774.
	[ XU J W, JU H, LIU Q. Drought characteristics of winter wheat at typical sites in the Huanghuaihai Plain and the influence of climate trends. Journal of Ecology, 2014,34(10):2765-2774.]
[19]	高继卿, 杨晓光, 董朝阳. 气候变化背景下中国北方干湿区降水资源变化特征分析. 农业工程学报, 2015,31(12):99-110.
	[ GAO J Q, YANG X G, DONG C Y. Analysis of the changing characteristics of precipitation resources in dry and wet areas of Northern China under the background of climate change. Transactions of the CSAE, 2015,31(12):99-110.]
[20]	HUA D, HAO X M, ZHANG Y, et al. Uncertainty assessment of potential evapotranspiration in arid areas, as estimated by the Penman-Monteith method. Journal of Arid Land, 2020,12(1):166-180. doi: 10.1007/s40333-020-0093-7
[21]	曹永强, 李维佳, 赵博雅. 气候变化下辽西北春玉米生育期需水量研究. 资源科学, 2018,40(1):150-160.
	[ CAO Y Q, LI W J, ZHAO B Y. Research on water requirement of spring maize in Northwestern Liaoning under climate change. Resources Science, 2018,40(1):150-160.]
[22]	黄晚华, 杨晓光, 曲辉辉, 等. 基于作物水分亏缺指数的春玉米季节性干旱时空特征分析. 农业工程学报, 2009,25(8):28-34.
	[ HUANG W H, YANG X G, QU H H, et al. Analysis of the temporal and spatial characteristics of spring maize seasonal drought based on crop water deficit index. Transactions of the CSAE, 2009,25(8):28-34.]
[23]	董秋婷, 李茂松, 刘江, 等. 近50年东北地区春玉米干旱的时空演变特征. 自然灾害学报, 2011,20(4):52-59.
	[ DONG Q T, LI M S, LIU J, et al. Spatial-temporal evolution characteristics of spring maize drought in Northeast China in the past 50 years. Journal of Natural Disasters, 2011,20(4):52-59.]
[24]	房世波. 分离趋势产量和气候产量的方法探讨. 自然灾害学报, 2011,20(6):13-18.
	[ FANG S B. Discussion on the method of separating trend yield and climatic yield. Journal of Natural Disasters, 2011,20(6):13-18.]
[25]	江和文, 张录军, 曹士民, 等. 辽宁省主要粮食作物产量灾损风险评估. 干旱地区农业研究, 2011,29(4):238-244.
	[ JIANG H W, ZHANG L J, CAO S M, et al. Risk assessment of major food crop yield damage in Liaoning province. Agricultural Research in Arid Areas, 2011,29(4):238-244.]
[26]	杨小利, 吴颖娟, 王丽娜, 等. 陇东地区主要农作物干旱灾损风险分析及区划. 西北农林科技大学学报: 自然科学版, 2010,38(2):83-90.
	[ YANG X L, WU Y J, WANG L N, et al. Risk analysis and zoning of drought damage of main crops in Longdong area. Journal of Northwest A&F University: Natural Science Edition, 2010,38(2):83-90.]
[27]	何风华, 李明辉. Excel在通径分析中的应用. 中国卫生统计, 2005,22(5):331-332.
	[ HE F H, LI M H. Application of excel in path analysis. China Health Statistics, 2005,22(5):331-332.]
[28]	王蕊, 张继权, 郭恩亮, 等. 近55 a吉林中西部玉米生长季旱涝时空特征分析. 自然灾害学报, 2018,27(1):186-197.
	[ WANG R, ZHANG J Q, GUO E L, et al. Analysis of spatial and temporal characteristics of drought and waterlogging during maize growing season in mid-west of Jilin in recent 55 years. Journal of Natural Disasters, 2018,27(1):186-197.]
[29]	虞海燕, 刘树华, 赵娜, 等. 我国近59年日照时数变化特征及其与温度、风速、降水的关系. 气候与环境研究, 2011,16(3):389-398.
	[ YU H Y, LIU S H, ZHAO N, et al. Changes in sunshine duration in my country in the past 59 years and its relationship with temperature, wind speed and precipitation. Climatic and Environmental Research, 2011,16(3):389-398.]
[30]	严俊. 基于作物水分亏缺指数的辽宁省玉米干旱时空变化特征分析. 沈阳: 沈阳农业大学, 2018.
	[ YAN J. Analysis of drought spatio-temporal variation characteristics of maize based on crop water deficit index. Shenyang: Shenyang Agricultural University, 2018.]

时间/(月,旬)	辽宁西部	辽宁北部	时间/(月,旬)	辽宁西部	辽宁北部
4月中（播种期）	0.36	0.35	7月上（拔节期）	0.91	0.93
4月下（播种期）	0.46	0.44	7月中（拔节期）	1.17	1.14
5月上（苗期）	0.47	0.45	7月下（抽穗期）	1.21	1.16
5月中（苗期）	0.51	0.46	8月上（抽穗期）	1.02	1.08
5月下（苗期）	0.55	0.48	8月中（成熟期）	0.97	0.98
6月上（苗期）	0.58	0.51	8月下（成熟期）	0.95	0.93
6月中（苗期）	0.68	0.62	9月上（成熟期）	0.91	0.89
6月下（拔节期）	0.80	0.81	9月中（成熟期）	0.78	0.79

等级	类型	CWDI/%
0	无旱	CWDI≤15
1	轻旱	15<CWDI≤30
2	中旱	30<CWDI≤45
3	重旱	45<CWDI≤60
4	特旱	CWDI>60

影响因子	与CWDI的相关系数	与CWDI的直接通径	与CWDI的间接通径
影响因子	与CWDI的相关系数	与CWDI的直接通径	降水量	平均气温	最低气温	最高气温	平均风速	日照时数	相对湿度
降水量	-0.60^**	-0.29	—	-0.16	-0.08	-0.04	-0.07	-0.08	0.44
平均气温	0.31^*	-0.33	-0.16	—	0.46	0.15	-0.26	-0.14	-0.32
最低气温	0.02	0.45	-0.20	1.08	—	-0.93	-0.35	-0.18	-0.57
最高气温	0.34^*	0.64	-0.07	0.26	-0.71	—	-0.08	0.02	-0.06
平均风速	0.28^*	0.26	-0.04	-0.12	-0.07	-0.02	—	0.19	-0.06
日照时数	0.15	-0.16	-0.33	-0.53	-0.28	0.04	1.54	—	-0.46
相对湿度	-0.68^**	-0.44	2.06	-1.49	-1.11	-0.15	-0.63	-0.58	—
