基于地理标记照片的入境游客空间特征与移动轨迹——以南京市为例

doi:10.31497/zrzyxb.20210204

摘要/Abstract

摘要：

随着互联网与社交媒体的兴起,用户分享内容中的地理标记数据成为旅游流研究的重要对象。以南京入境旅游流空间特征为研究对象,以2010—2018年Flickr平台内南京地理标记照片为基础,利用DBSCAN算法、ArcGIS 10.2等方法与技术探究南京入境旅游热点区域、游客移动轨迹特征及模式。研究结果显示：（1）南京入境游客访问峰值出现在3-6月及10月,以一日游为主。（2）南京AOI空间分布差异明显,历史城区是南京入境旅游最热门区域,其AOI分布与旅游景区、商业购物等相关产业空间高度重合;中心城区的AOI分布数量次之,钟山风景区是其热度核心,深受热衷历史文化的游客追捧;郊区的AOI分布数量最少,基本与当地旅游景区相吻合。（3）单日游和多日游的游客移动轨迹网具有显著差异性,分别体现在网络范围、网络体系、旅游对流及转移差值4个方面。（4）南京入境游客移动轨迹模式可划分为区域内部移动轨迹模式和区域间移动轨迹模式。根据上述研究结果,分别针对历史城区、中心城区及郊区提出相应的发展建议。

关键词: 地理标记照片, 入境旅游流, 空间特征, 移动轨迹, 南京市

Abstract:

With the rise of the Internet and social media, geo-tagged data in the sharing of users has become an important content of tourism flow research. Based on the photos of on the Flickr platform during 2010-2018, this study takes the spatial characteristics of Nanjing inbound tourism flow as the research object, and uses the methods of DBSCAN algorithm, ArcGIS 10.2 and others to explore inbound tourism hotspots area, the features of moving trajectory and patterns of Nanjing. The results of the study show that: (1) The peak of inbound visits occurred in March-June and October, and the tourists mainly took one-day trips. (2) There are obvious differences in the spatial distribution of Area of Interest (AOI) in Nanjing. The historical urban district (HUD) is most popular for inbound tourists, and has the largest number of AOI, followed by the central urban area (CUA), and the suburbs. The distribution of AOI in the HUD is highly coincident with its related industrial space, such as tourist attractions and commercial shopping centers; Zhongshan Scenic Area in the CUA is a hotspot for tourists who are interested in history and culture; the distribution of AOI in the suburbs is basically consistent with that of local tourist attractions. (3) There are great differences in moving trajectories between single-day and multi-day trips, which are reflected in the network scope, network system, tourism inflow and outflow, and transfer difference. (4) The patterns of inbound moving trajectory can be divided into intra-area pattern and inter-area pattern. Based on the above results, suggestions are proposed for development of historical urban area, central urban area and the suburbs.

Key words: geo-tagged photos, inbound tourism flow, spatial characteristics, moving trajectory, Nanjing city

卢淑莹, 黄鑫, 陶卓民. 基于地理标记照片的入境游客空间特征与移动轨迹——以南京市为例[J]. 自然资源学报, 2021, 36(2): 315-326.

LU Shu-ying, HUANG Xin, TAO Zhuo-min. Spatial patterns and moving trajectory of inbound tourists based on geo-tagged photos:A case study of Nanjing city[J]. JOURNAL OF NATURAL RESOURCES, 2021, 36(2): 315-326.

图/表 9

图1

图2

图3

图4

图5

表1

表2

图6

图7

参考文献 26

[1]	王永明, 王美霞, 吴殿廷, 等. 基于ZINB模型的中国省域间入境旅游流影响因素. 经济地理, 2018,38(11):234-240.
	[ WANG Y M, WANG M X, WU D T, et al. Determinants of inbound tourism flows between provinces in China based on ZINB model. Economic Geography, 2018,38(11):234-240.]
[2]	PALDINO S, BOJIC I, SOBOLEVSKY S, et al. Urban magnetism through the lens of geo-tagged photography. EPJ Data Science, 2015,4(1):5.
[3]	唐弘久, 保继刚. 我国主要入境客源地游客的时空特征及影响因素. 经济地理, 2018,38(9):222-230, 239.
	[ TANG H J, BAO J G. Spatio-temporal characteristics and influencing factors of tourists from main inbound tourist source for mainland China. Economic Geography, 2018,38(9):222-230, 239.]
[4]	HU Y J, GAO S, JANOWICZ K, et al. Extracting and understanding urban areas of interest using geotagged photos. Computers, Environment and Urban Systems, 2015, (54):240-254.
[5]	鲁小波, 陈晓颖, 马斌斌. 东北亚各国间旅游流规模与潜力分析. 干旱区资源与环境, 2015,29(11):208-213.
	[ LU X B, CHEN X Y, MA B B. Tourism flow scales and potentials among Northeast Asian countries. Journal of Arid Land Resources and Environment, 2015,29(11):208-213.]
[6]	马晓龙. 西安旅游区入境旅游流时空演变及系统调控. 人文地理, 2006,21(4):88-93.
	[ MA X L. Tempo-spatial varieties of oversea tourists flow and its systematical adjusting in Xi'an tourism districts. Human Geography, 2006,21(4):88-93.]
[7]	卞显红, 沙润, 杜长海. 长江三角洲城市入境旅游流区域内流动份额分析. 人文地理, 2007,22(2):32-38.
	[ BIAN X H, SHA R, DU C H. Analysis on regional floating share of inbound tour flow in the Yangtze River Delta. Human Geography, 2007,22(2):32-38.]
[8]	刘宏盈, 马耀峰, 白凯, 等. 口岸入境旅游流扩散转移特征研究: 以上海为例. 社会科学家, 2008, (1):99-103.
	[ LIU H Y, MA Y F, BAI K, et al. A study of the characteristics of diffusion and transfer of inbound tourism flow at port: A case study of Shanghai. Social Scientist, 2008, (1):99-103.]
[9]	杨敏, 马耀峰, 李天顺, 等. 网络信息与入境旅游流的V-R耦合关系分析: 以澳大利亚入境旅游流为例. 干旱区资源与环境, 2012,26(6):214-219.
	[ YANG M, MA Y F, LI T S, et al. An analysis on the V-R coupling relationship on the internet information and the inbound tourist flow: A case of the Australian inbound tourist flow. Journal of Arid Land Resources and Environment, 2012,26(6):214-219.]
[10]	张春晖, 马耀峰, 吴晶, 等. 供需视角下西部入境旅游流与目的地耦合协调度及其时空分异研究. 经济地理, 2013,33(10):174-181.
	[ ZHANG C H, MA Y F, WU J, et al. Coupling coordination degree between inbound tourist flows and destinations and its spatio-temporal differences in the western region of China: A study from the perspective of supply-demand relationship. Economic Geography, 2013,33(10):174-181.]
[11]	董亚娟, 马耀峰, 李振亭, 等. 西安入境旅游流与城市旅游环境耦合协调关系研究. 地域研究与开发, 2013,32(1):98-101.
	[ DONG Y J, MA Y F, LI Z T, et al. Coupling coordination of Xi'an inbound tourist flows and urban tourism environment. Areal Research and Development, 2013,32(1):98-101.]
[12]	李幼龙, 胡敏, 马耀峰. 新疆入境旅游流与区域经济耦合协调度分析. 资源开发与市场, 2013,29(4):418-421.
	[ LI Y L, HU M, MA Y F. Analysis on coupling degree of coordination between flow of inbound tourism in Xinjiang and regional economic. Resource Development & Market, 2013,29(4):418-421.]
[13]	杨兴柱, 蒋锴, 陆林. 南京市游客路径轨迹空间特征研究: 以地理标记照片为例. 经济地理, 2014,34(1):181-187.
	[ YANG X Z, JIANG K, LU L. Urban tourist path trajectory spatial characteristics: An empirical analysis of geotagged photos. Economic Geography, 2014,34(1):181-187.]
[14]	朱鹤, 刘家明, 陶慧, 等. 基于网络信息的北京市旅游资源吸引力评价及空间分析. 自然资源学报, 2015,30(12):2081-2094.
	[ ZHU H, LIU J M, TAO H, et al. Evaluation and spatial analysis of tourism resources attraction in Beijing based on the internet information. Journal of Natural Resources, 2015,30(12):2081-2094.]
[15]	王守成, 郭风华, 傅学庆, 等. 基于自发地理信息的旅游地景观关注度研究: 以九寨沟为例. 旅游学刊, 2014,29(2):84-92.
	[ WANG S C, GUO F H, FU X Q, et al. A study of the spatial patterns of tourist sightseeing based on volunteered geographic information: The case of the Jiuzhai Valley. Tourism Tribune, 2014,29(2):84-92.]
[16]	GARCÍA-PALOMARES J C, GUTIÉRREZ J, MÍNGUEZ C. Identification of tourist hot spots based on social networks: A comparative analysis of European metropolises using photo-sharing services and GIS. Applied Geography, 2015,63:408-417.
[17]	VU H Q, LI G, LAW R, et al. Exploring the travel behaviors of inbound tourists to Hong Kong using eotagged photos. Tourism Management, 2015,46:222-232.
[18]	MAJID A, CHEN L, CHEN G C, et al. A context-aware personalized travel recommendation system based on geotagged social media data mining. International Journal of Geographical Information Science, 2013,27(4):662-684.
[19]	唐鸣镝, 秦静, 黄震宇, 等. 北京城市旅游功能热区的演变与规划响应. 规划师, 2018,34(4):88-94.
	[ TANG M D, QIN J, HUANG Z Y, et al. Beijing urban tourism functional zone evolution and planning response from AOI viewpoint. Planners, 2018,34(4):88-94.]
[20]	秦静, 李郎平, 唐鸣镝, 等. 基于地理标记照片的北京市入境旅游流空间特征. 地理学报, 2018,73(8):1556-1570.
	[ QIN J, LI L P, TANG M D, et al. Exploring the spatial characteristics of Beijing inbound tourist flow based on geotagged photos. Acta Geographica Sinica, 2018,73(8):1556-1570.]
[21]	范梦余, 陈怡宁, 张辉. 呼伦贝尔游客POI空间格局与移动轨迹研究: 基于地理标记照片的实证分析. 干旱区资源与环境, 2019,33(6):203-208.
	[ FAN M Y, CHEN Y N, ZHANG H. Spatial patterns of tourist POI and tourist moving trajectory in Hulunbuir city. Journal of Arid Land Resources and Environment, 2019,33(6):203-208.]
[22]	ESTER M, KRIEGEL H P, SANDER J, et al. A density-based algorithm for discovering clusters in large spatial databases with noise. In: SIMOUDIS E, HAN J W, FAYYAD U. Proceedings of the 2nd International Conference on Knowledge Discovery and Data Mining. Portland, USA: AAAI Press, 1996: 226-231.
[23]	李新延, 李德仁. DBSCAN空间聚类算法及其在城市规划中的应用. 测绘科学, 2005, (3):51-53, 5.
	[ LI X Y, LI D R. DBSCAN spatial clustering algorithm and its application in urban planning. Science of Surveying and Mapping, 2005, (3):51-53, 5.]
[24]	周红芳, 王鹏. DBSCAN算法中参数自适应确定方法的研究. 西安理工大学学报, 2012,28(3):289-292.
	[ ZHOU H F, WANG P. Research on adaptive parameters determination in DBSCAN algorithm. Journal of Xi'an University of Technology, 2012,28(3):289-292.]
[25]	朱孟珏, 庄大昌, 李涛. 1990—2014年中国煤炭运输网络的时空特征研究. 自然资源学报, 2018,33(3):454-466.
	[ ZHU M J, ZHUANG D C, LI T. Spatial characteristics of coal transportation network in China during 1990-2014. Journal of Natural Resources, 2018,33(3):454-466.]
[26]	段亚明, 刘勇, 刘秀华, 等. 基于POI大数据的重庆主城区多中心识别. 自然资源学报, 2018,33(5):788-800.
	[ DUAN Y M, LIU Y, LIU X H, et al. Identification of polycentric urban structure of Central Chongqing using points of interest big data. Journal of Natural Resources, 2018,33(5):788-800.]

所属区域	热点区域	具体地点	排名	访客量/名
历史城区	玄武湖鸡鸣寺片区	玄武湖公园、鸡鸣寺、神策门至解放门城墙、南京站等	1	273
	夫子庙秦淮河片区	夫子庙、秦淮河、瞻园、东水关等	3	227
	新街口总统府片区	新街口、总统府、净觉寺、郑和公园等	4	142
	阅江楼仪凤门片区	阅江楼、仪凤门至定淮门城墙、南京长江大桥等	5	117
	中华门大报恩寺片区	中华门瓮城、朝天宫、大报恩寺遗址公园等	6	65
	南大东南鼓楼片区	南京大学、东南大学、鼓楼公园、紫峰大厦、清凉山等	7	57
	南京博物院明故宫片区	南京博物院、明故宫遗址、太平门至光华门城墙等	10	38
中心城区	钟山风景区	紫金山天文台、中山陵、明孝陵、灵谷寺等	2	232
	雨花台片区	雨花台风景区、南京科技馆、花神湖、南京南站等	8	54
	侵华日军南京大屠杀遇难同胞纪念馆片区	侵华日军南京大屠杀遇难同胞纪念馆、莫愁湖公园等	9	46
	栖霞山仙林大学城片区	栖霞山、南京大学仙林校区等	12	29
	河西CBD	绿博园、奥体中心、国际博览中心等	13	17
郊区	浦口片区	浦口火车站、四方美术馆、老山森林公园等	15	9
	牛首汤山片区	牛首山、汤山等	11	30
	南京禄口机场	南京国际禄口机场	14	15
	溧水片区	傅家边、观音禅寺、无想山等	16	4
