黄河经济带生态文明建设与城市化耦合关系及空间特征研究

doi:10.31497/zrzyxb.20210106

摘要/Abstract

摘要：

通过研究系统耦合协同评价体系,构建一个适宜大区域的评价生态文明建设和城市化情况的指标体系,借助该指标体系,从时空两个维度分析黄河经济带2008—2016年生态文明建设和城市化耦合协调发展状况、格局及空间关系。实证结果表明：（1）2008—2016年,黄河经济带生态文明建设成效并不显著,压力依然很大;城市化有所提升,但发展速度依然偏慢。两方面均不存在明显的龙头城市,且空间差异明显。（2）2008—2016年,研究区生态文明建设与城市化处于低度耦合阶段,协调度处于轻度失调状态,生态文明建设普遍滞后于城市化,表现出明显的空间异质性和行政指向性。（3）协调度表现出一定的空间依赖,存在一定的空间溢出效应,地理临近的区域更容易受高协调度区域的影响。

关键词: 黄河经济带, 生态文明, 城市化, 耦合协调模型

Abstract:

To explore the sustainability of regional development, on the basis of the system coupling collaborative evaluation system, a comprehensive index system suitable for large regions and multi-cities is constructed, which can evaluate the construction of ecological civilization and urbanization. With the help of this index system, the ecological civilization construction and the coupling and coordinated development of urbanization in 80 cities at and above the Yellow River Economic Belt from 2008 to 2016 were evaluated from two dimensions of time and space. Then, the exploratory spatial data analysis method is used to analyze the spatial pattern and spatial relation characteristics of the coupling coordination level in the research area. The empirical results show that: (1) From 2008 to 2016, the ecological civilization construction in the Yellow River Economic Belt did not achieve significant results, and the pressure was still very high, which proves the necessity and urgency of ecological protection and high-quality development in the Yellow River Basin. The overall urbanization had improved, but the entire development rate was still too slow. There was no obvious leading city in both aspects, and the spatial difference was distinct. (2) From 2008 to 2016, the ecological civilization construction and urbanization in the cities of the Yellow River Economic Belt were in a low degree of coupling, the coordination degree was slightly unbalanced, and the ecological civilization construction generally lagged behind the urbanization development. The spatial pattern was characterized by obvious spatial heterogeneity and administrative orientation. (3) The coordination degree of ecological civilization and urbanization in the research area showed a certain spatial dependence and spatial connection, and the coordination degree showed a certain spatial spillover effect, and the geographical adjacent areas were more susceptible to the influence of regions with high coordination degree.

Key words: Yellow River Economic Belt, ecological civilization, urbanization, coupling coordination model

葛世帅, 曾刚, 杨阳, 胡浩. 黄河经济带生态文明建设与城市化耦合关系及空间特征研究[J]. 自然资源学报, 2021, 36(1): 87-102.

GE Shi-shuai, ZENG Gang, YANG Yang, HU Hao. The coupling relationship and spatial characteristics analysis between ecological civilization construction and urbanization in the Yellow River Economic Belt[J]. JOURNAL OF NATURAL RESOURCES, 2021, 36(1): 87-102.

图/表 12

表1

表2

图1

图2

图3

图4

图5

图6

图7

图8

图9

图10

参考文献 48

[1]	王耕, 李素娟, 马奇飞. 中国生态文明建设效率空间均衡性及格局演变特征. 地理学报, 2018,73(11):2198-2209.
	[ WANG G, LI S J, MA Q F. Spatial equilibrium and pattern evolution of ecological civilization construction efficiency in China. Acta Geographica Sinica, 2018,73(11):2198-2209.]
[2]	陈明星, 梁龙武, 王振波, 等. 美丽中国与国土空间规划关系的地理学思考. 地理学报, 2019,74(12):2467-2481.
	[ CHEN M X, LIANG L W, WANG Z B, et al. Geographical thinking on the relationship between beautiful China and land spatial planning. Acta Geographica Sinica, 2019,74(12):2467-2481.]
[3]	王振波, 梁龙武, 方创琳, 等. 京津冀特大城市群生态安全格局时空演变特征及其影响因素. 生态学报, 2018,38(12):4132-4144.
	[ WANG Z B, LANG L W, FANG C L, et al. Study of the evolution and factors influencing ecological security of the Beijing-Tianjin-Hebei Urban Agglomeration. Acta Ecologica Sinica, 2018,38(12):4132-4144.]
[4]	FANG C L, WANG Z B, XU G. Spatial distribution of PM_2.5 in Chinese urban agglomerations. Journal of Geographical Sciences, 2016,26(11):1519-1532.
[5]	刘华, 钟炜, 张建民, 等. 城市化过程中的生态问题初探. 经济地理, 2006,26(1):92-95.
	[ LIU H, ZHONG W, ZHANG J M, et al. A study of urbanization and urban ecological problems. Economic Geography, 2006,26(1):92-95.]
[6]	陈炳, 曾刚, 曹贤忠, 等. 长三角城市群生态文明建设与城市化耦合协调发展研究. 长江流域资源与环境, 2019,28(3):530-541.
	[ CHEN B, ZENG G, CAO X Z, et al. Coupling coordination development between ecological civilization construction and urbanization in Yangtze River Delta Urban Agglomerations. Resources and Environment in the Yangtze Basin, 2019,28(3):530-541.]
[7]	HOWARD E. To-tomorrow: A Peaceful Path to Real Reform. London, UK: S. Sonnenschein & Co, 1898.
[8]	何梅, 汪云, 夏巍, 等. 特大城市生态空间体系规划与管控研究. 北京: 中国建筑工业出版社, 2010: 15-30.
	[ HE M, WANG Y, XIA W, et al. Ecological Spatial System Planning and Management Study of Megacity. Beijing: China Architecture & Building Press, 2010: 15-30.]
[9]	DRAKAKIS-SMITH D, DIXON C. Sustainable urbanization in Vietnam. Geoforum, 1997,28(1):21-38. pmid: 12348286
[10]	宓泽锋, 曾刚, 尚勇敏, 等. 中国省域生态文明建设评价方法及空间格局演变. 经济地理, 2016,36(4):15-21.
	[ MI Z F, ZENG G, SHANG Y M, et al. The evaluation method and spatial pattern evolution of ecological civilization construction of Chinese provinces. Economic Geography, 2016,36(4):15-21.]
[11]	龙花楼, 刘永强, 李婷婷, 等. 生态文明建设视角下土地利用规划与环境保护规划的空间衔接研究. 经济地理, 2014,34(5):1-8.
	[ LONG H L, LIU Y Q, LI T T, et al. Spatial interlinking of land use planning and environmental protection planning from the perspective of ecological civilization construction. Economic Geography, 2014,34(5):1-8.]
[12]	钟镇涛, 张鸿辉, 洪良, 等. 生态文明视角下的国土空间底线管控:“双评价”与国土空间规划监测评估预警. 自然资源学报, 2020,35(10):2415-2427.
	[ ZHONG Z T, ZHANG H H, HONG L, et al. Territorial space baseline control from the perspective of ecological civilization: "Double evaluation" and monitoring-evaluation-warning. Journal of Natural Resources, 2020,35(10):2415-2427.]
[13]	容贤标, 胡振华, 熊曦. 旅游业发展与生态文明建设耦合度的地区间差异. 经济地理, 2016,36(8):189-194.
	[ RONG X B, HU Z H, XIONG X. Regional differences in the coupling relationship between tourism development and ecological civilization construction. Economic Geography, 2016,36(8):189-194.]
[14]	毕国华, 杨庆媛, 刘苏. 中国省域生态文明建设与城市化的耦合协调发展. 经济地理, 2017,37(1):50-58.
	[ BI G H, YANG Q Y, LIU S. Coupling coordination development between ecological civilization construction and urbanization in China. Economic Geography, 2017,37(1):50-58.]
[15]	杨立, 黄涛珍. 基于耦合协调度模型的生态文明与新型城镇化作用机理及关系研究. 生态经济, 2019,35(12):60-66.
	[ YANG L, HUANG T Z. Mechanism and interrelationship between ecological civilization and new urbanization based on Coupling Coordination Model. Ecological Economy, 2019,35(12):60-66.]
[16]	郭向阳, 明庆忠, 穆学青, 等. 城市旅游业与生态文明耦合协调态势的时空演化研究: 以河南省为例. 资源开发与市场, 2017,33(6):732-737, 753.
	[ GUO X Y, MING Q Z, MU X Q, et al. Study on spatial and temporal evolution of urban tourism and ecological civilization: Taking Henan province as an example. Resource Development & Market, 2017,33(6):732-737, 753.]
[17]	刘耀彬, 李仁东, 宋学锋. 中国区域城市化与生态环境耦合的关联分析. 地理学报, 2005,60(2):237-247.
	[ LIU Y B, LI R D, SONG X F. Grey associative analysis of regional urbanization and eco-environment coupling in China. Acta Geographica Sinica, 2005,60(2):237-247.]
[18]	黄金川, 方创琳. 城市化与生态环境交互耦合机制与规律性分析. 地理研究, 2003,22(2):211-220.
	[ HUANG J C, FANG C L. Analysis of coupling mechanism and rules between urbanization and eco-environment. Geographical Research, 2003,22(2):211-220.]
[19]	傅伯杰. 地理学:从知识、科学到决策. 地理学报, 2017,72(11):1923-1932.
	[ FU B J. Geography: From knowledge, science to decision making support. Acta Geographica Sinica, 2017,72(11):1923-1932.]
[20]	任宇飞, 方创琳, 孙思奥, 等. 城镇化与生态环境近远程耦合关系研究进展. 地理学报, 2020,75(3):589-606.
	[ REN Y F, FANG C L, SUN S A, et al. Progress in local and tele-coupling relationship between urbanization and eco-environment. Acta Geographica Sinica, 2020,75(3):589-606.]
[21]	中国社会科学网. 推进区域协调发展谋划黄河(生态)经济带建设. http://ex.cssn.cn/index/zb/201906/t20190606_4914013_1.shtml, 2020-10-30.
	[ China Social Sciences Network. Promote coordinated regional development and plan the construction of the Yellow River (ecological) Economic Belt. http://ex.cssn.cn/index/zb/201906/t20190606_4914013_1.shtml, 2020-10-30.]
[22]	中国社会科学网. 促进黄河经济带可持续发展. http://www.cssn.cn/zx/bwyc/201905/t20190508_4875455.shtml, 2020-10-30.
	[ China Social Sciences Network. Promote the sustainable development of the Yellow River Economic Belt. http://www.cssn.cn/zx/bwyc/201905/t20190508_4875455.shtml, 2020-10-30.]
[23]	金凤君. 黄河流域生态保护与高质量发展的协调推进策略. 改革, 2019, (11):33-39.
	[ JIN F J. Coordinated promotion strategy of ecological protection and high-quality development in the Yellow River Basin. Reform, 2019, (11):33-39.]
[24]	中华人民共和国环境保护部. 生态县、生态市、生态省建设指标(修订版). http://www.mee.gov.cn/gkml/zj/wj/200910/t20091022_172492.htm, 2020-06-30.
	[ Ministry of Ecology and Environment of the People's Republic of China. Construction indexes of ecological counties, cities and provinces (revised draft). http://www.mee.gov.cn/gkml/zj/wj/200910/t20091022_172492.htm, 2020-06-30.]
[25]	卞有生, 何军, 张文国. 生态县、生态市、生态省建设规划编制导则. 中国工程科学, 2004,6(11):1-7.
	[ BIAN Y S, HE J, ZHANG W G. Guidelines for compiling construction plans of ecological counties, cities and provinces. Strategic Study of CAE, 2004,6(11):1-7.]
[26]	马世骏, 王如松. 社会—经济—自然复合生态系统. 生态学报, 1984,4(1):1-9.
	[ MA S J, WANG R S. The social-economic-natural complex ecosystem. Acta Ecologica Sinica, 1984,4(1):1-9.]
[27]	王如松. 生态整合与文明发展. 生态学报, 2013,33(1):1-11.
	[ WANG R S. Integrating ecological civilization into social-economic development. Acta Ecologica Sinica, 2013,33(1):1-11.]
[28]	刘某承, 苏宁, 伦飞, 等. 区域生态文明建设水平综合评估指标. 生态学报, 2014,34(1):97-104.
	[ LIU M C, SU N, LUN F, et al. An integrated indicator on regional ecological civilization construction. Acta Ecologica Sinica, 2014,34(1):97-104.]
[29]	陈明星, 陆大道, 张华. 中国城市化水平的综合测度及其动力因子分析. 地理学报, 2009,64(4):387-398.
	[ CHEN M X, LU D D, ZHANG H. Comprehensive evaluation and the driving factors of China's urbanization. Acta Geographica Sinica, 2009,64(4):387-398.]
[30]	齐爱荣, 周忠学, 刘欢. 西安市城市化与都市农业发展耦合关系研究. 地理研究, 2013,32(11):2133-2142.
	[ QI A R, ZHOU Z X, ZHANG H. The coupling relationship between urbanization and urban agriculture development in Xi'an city. Geographical Research, 2013,32(11):2133-2142.]
[31]	宓泽锋, 周灿, 朱菲菲, 等. 生态文明建设的路径依赖与互动关系变化: 基于2003—2015年长江经济带地级市面板数据. 地理研究, 2018,37(10):1915-1926.
	[ MI Z F, ZHOU C, ZHU F F, et al. The path dependence and relationship change of ecological civilization construction: Based on the panel data analysis of prefecture-level cities in the Yangtze River Economic Belt from 2003 to 2015. Geographical Research, 2018,37(10):1915-1926.]
[32]	刘润佳, 把多勋. 中国省会城市紧凑度与城镇化水平关系. 自然资源学报, 2020,35(3):586-600.
	[ LIU R J, BA D X. The relationship between urban compactness and urbanization level in capital cities of China. Journal of Natural Resources, 2020,35(3):586-600.]
[33]	苗长虹. 黄河经济带的战略需求与战略定位. 中国社会科学报, 2019-06-06(006).
	[ MIAO C H. Strategic demand and strategic positioning of Yellow River Economic Belt. Chinese Social Sciences Today, 2019-06-06(006).]
[34]	王海江, 苗长虹, 乔旭宁. 黄河经济带中心城市服务能力的空间格局. 经济地理, 2017,37(7):33-39.
	[ WANG H J, MIAO C H, QIAO X N. Central cities external service capabilities spatial distribution of Yellow River Economic Belt. Economic Geography, 2017,37(7):33-39.]
[35]	丁志伟, 刘晓阳, 程迪, 等. 黄河经济带县域城乡收入差距的空间格局及影响因素. 河南大学学报: 自然科学版, 2019,49(1):1-12.
	[ DING Z W, LIU X Y, CHENG D, et al. Spatial pattern of urban-rural income gap and its influencing factors at county level in Yellow River Economic Belt. Journal of Henan University: Natural Science, 2019,49(1):1-12.]
[36]	曹贤忠, 曾刚. 基于熵权TOPSIS法的经济技术开发区产业转型升级模式选择研究: 以芜湖市为例. 经济地理, 2014,34(4):13-18.
	[ CAO X Z, ZENG G. The mode of transformation and upgrading based on the methods of Entropy Weight and TOPSIS in case of Wuhu Economic and Technological Development Zone. Economic Geography, 2014,34(4):13-18.]
[37]	赵建吉, 王艳华, 张洁, 等. 中部地区人口结构与产业结构的时空耦合. 经济地理, 2019,39(12):129-137.
	[ ZHAO J J, WANG Y H, ZHANG J, et al. Spatio-temporal coupling of population structure and industrial structure in Central China. Economic Geography, 2019,39(12):129-137.]
[38]	韩增林, 赵启行, 赵东霞, 等. 2000—2015年东北地区县域人口与经济耦合协调演变及空间差异: 以辽宁省为例. 地理研究, 2019,38(12):3025-3037.
	[ HAN Z L, ZHAO Q H, ZHAO D X, et al. Population and economic coupling coordinated evolution and spatial differences at county level in Northeast China during 2000-2015: Taking Liaoning province as an example. Economic Geography, 2019,38(12):3025-3037.]
[39]	马丽, 金凤君, 刘毅. 中国经济与环境污染耦合度格局及工业结构解析. 地理学报, 2012,67(10):1299-1307.
	[ MA L, JIN F J, LIU Y. Spatial pattern and industrial sector structure analysis on the coupling and coordinating degree of regional economic development and environmental pollution in China. Acta Geographica Sinica, 2012,67(10):1299-1307.]
[40]	周亮, 车磊, 孙东琪. 中国城镇化与经济增长的耦合协调发展及影响因素. 经济地理, 2019,39(6):97-107.
	[ ZHOU L, CHE L, SUN D Q. The coupling coordination development between urbanization and economic growth and its influencing factors in China. Economic Geography, 2019,39(6):97-107.]
[41]	张荣天, 焦华富. 中国省际城镇化与生态环境的耦合协调与优化探讨. 干旱区资源与环境, 2015,29(7):12-17.
	[ ZHANG R T, JIAO H F. Coupling and coordination between urbanization and ecological environment in China. Journal of Arid Land Resources and Environment, 2015,29(7):12-17.]
[42]	吴媛媛, 宋玉祥. 中国旅游经济空间格局演变特征及其影响因素分析. 地理科学, 2018,38(9):1491-1498.
	[ WU Y Y, SONG Y X. Spatial pattern evolution and influence factors of tourism economy in China. Scientia Geographica Sinica, 2018,38(9):1491-1498.]
[43]	张凡凡, 张启楠, 李福夺, 等. 中国水足迹强度空间关联格局及影响因素分析. 自然资源学报, 2019,34(5):934-944.
	[ ZHANG F F, ZHANG Q N, LI F D, et al. The spatial correlation pattern of water footprint intensity and its driving factors in China. Journal of Natural Resources, 2019,34(5):934-944.]
[44]	陈怡平, 傅伯杰. 关于黄河流域生态文明建设的思考. 中国科学报, 2019-12-20(006).
	[ CHEN Y P, FU B J. On the construction of ecological civilization in the Yellow River Basin. Chinese Social Sciences Today, 2019-12-20(006).]
[45]	求是. 科学把握生态文明建设的新形势. http://www.qstheory.cn/dukan/qs/2018-06/29/c_1123054114.htm, 2020-10-30.
	[ QIUSHI . Grasp the new situation of ecological civilization construction scientifically. http://www.qstheory.cn/dukan/qs/2018-06/29/c_1123054114.htm, 2020-10-30.]
[46]	李雪松, 龙湘雪, 齐晓旭. 长江经济带城市经济—社会—环境耦合协调发展的动态演化与分析. 长江流域资源与环境, 2019,28(3):505-516.
	[ LI X S, LONG X X, QI X X. Dynamic evolution and analysis of coupling development of economy, society and environment in Yangtze River Economic Belt. Resources and Environment in the Yangtze Basin, 2019,28(3):505-516.]
[47]	陆大道, 孙东琪. 黄河流域的综合治理与可持续发展. 地理学报, 2019,74(12):2431-2436.
	[ LU D D, SUN D Q. Development and management tasks of the Yellow River Basin: A preliminary understanding and suggestion. Acta Geographica Sinica, 2019,74(12):2431-2436.]
[48]	ANSELIN L, SYABRI I, KHO Y. GeoDa: An introduction to spatial data analysis. Geographical Analysis, 2005,38(1):5-22.

I级指标	Ⅱ级指标	单位	正/负向
生态	建成区绿化覆盖率	%	正
	人均公园绿地面积	m²/人	正
	城市污水集中处理率	%	正
	生活垃圾无害化处理率	%	正
	工业固体废物综合利用率	%	正
	每万人二氧化硫排放量	t/万人	负
	工业粉尘去除率	%	正
	PM_2.5浓度	μg/m3	负
经济	第三产业占比	%	正
	人均公共财政支出	元/人	正
	人均GDP	元/人	正
	单位建设用地创造的GDP	万元/km²	正
社会	城镇登记失业率	%	负
	人均用电量	kW·h/人	负
	人口自然增长率	‰	正
	科技支出占公共财政支出的比例	%	正
	每万人拥有公共汽车数辆	辆/万人	正
	人均道路面积	m²/人	正
人口城市化	城镇人口比例	%	正
人口城市化	二三产业就业人员比例	%	正
经济城市化	二三产业产值占GDP比例	%	正
经济城市化	人均工业总产值	元/人	正
社会城市化	万人医疗卫生机构床位个数	张/万人	正
	百人公共图书馆藏书量	件/百人	正
	万人在校大学生数	人/万人	正
	互联网普及率	%	正
土地城市化	建成区面积占辖区面积比比例	%	正
土地城市化	城市人均建设用地面积	km²/人	正

协调度	协调等级
0.00~0.19	严重失调
0.20~0.39	轻度失调
0.40~0.59	一般协调
0.60~0.79	良好协调
0.80~1.00	优质协调
