滨海湿地盐沼植被修复中的种子产品制作过程及其有效性

doi:10.31497/zrzyxb.20191210

摘要/Abstract

摘要：

针对当前滨海湿地种子流在潮汐过程中种子有效沉降降低、土壤种子库分布不均、定植效率低和栖息地裸斑现象等关键问题,以黄河三角洲盐沼湿地的盐地碱蓬（Suaeda salsa）为修复物种,研发一种应用于滨海湿地盐沼植被修复的固态种子产品,阐述固态种子产品的制作过程,并开展三种不同保水材料为核心材料（聚丙烯酰胺PAM,羟乙基纤维素HEC,羟丙基甲基纤维素HPMC）的种子产品的有效性研究。研究结果表明：（1）包装制作后的盐地碱蓬种子的吸水倍率和保水持续时间显著高于普通天然种子,表现出良好的吸水保水特性;（2）包装后的盐地碱蓬种子受盐度梯度变化的影响较小,表现出良好的耐盐抗性;（3）包装后的盐地碱蓬种子具有更高的萌发潜力,而不同保水材料的种子产品包装对盐地碱蓬种子萌发的促进作用表现为PAM>HPMC>HEC>天然种子;（4）包装后的盐地碱蓬种子具有更短的悬浮时间和较快的平均沉降速度,表明了种子产品增强了盐地碱蓬种子抵抗水动力干扰的潜力,其中以PAM为保水材料的种子产品可以直接、快速地沉降。本文首次将种子产品技术应用于滨海湿地盐沼植被修复中,为种子产品技术在退化滨海湿地的植被修复领域的应用与实践提供了理论基础。

关键词: 盐沼湿地, 生态修复, 种子产品, 保水材料, 盐地碱蓬

Abstract:

A crucial question in restoration of coastal saltmarsh ecosystem is how to keep sustainable and evenly distributed seed banks, and approaches to enhance the seed settlement and germination. Thus, an urgent need is to develop a method by ameliorating the available conditions for seeds settlement and germination, thereby promoting the effectiveness of coastal vegetation restoration. Here, using an annual saltmarsh vegetation Suaeda salsa as a model species in the Yellow River Delta, we experimentally enveloped a thin layer outside each seed by three kinds of super absorbent materials, thereby testing their difference and providing an optimal selection for the restoration of Suaeda salsa. The materials we selected were polyacrylamide PAM, hydroxyethyl cellulose HEC, and hydroxypropyl methyl cellulose HPMC, which of each harbors the high ability in water absorption. Firstly, we coated the powder of each kind of absorbent material outside the seeds; secondly, we experimentally manipulated a gradient of water salinity to know the coated seed germination vary with the salinity; thirdly, we experimentally released 30 seeds for testing their mean suspension time and 20 seeds for the whole process of settlement; in the end, we investigated the seeds germination with different absorbent materials. Our results showed that, compared to the natural seeds dispersed to the bare ground, seeds that were enveloped by the water retaining materials (i.e. seed product) significantly harbored more water and maintained the water for a longer time. Our findings are that seed product coated by absorbent materials presented shorter suspension time and quick settlement within the sea water; the seed product significantly increased the germination rate and salt tolerance In addition, we observed that PAM, HPMC and HEC differed significantly in making contribution to the seed suspension, settlement, and seed germination, showing that the seed product with PAM is higher than HPMC, HEC and natural seeds, successively. Our study provides an available approach for governing the persistence of the coastal seed banks, with important management implication to use artificial seed products in the restoration of degraded saltmarsh ecosystems.

Key words: saltmarsh, ecological restoration, seed coating, superabsorbent material, Suaeda salsa

隋皓辰, 马旭, 闫家国, 张树岩, 盖凌云, 刘泽正, 邱冬冬, 崔保山. 滨海湿地盐沼植被修复中的种子产品制作过程及其有效性[J]. 自然资源学报, 2019, 34(12): 2601-2614.

SUI Hao-chen, MA Xu, YAN Jia-guo, ZHANG Shu-yan, GAI Ling-yun, LIU Ze-zheng, QIU Dong-dong, CUI Bao-shan. Seed coating methods and availability for applying in the restoration of salt marsh vegetation in coastal wetlands[J]. JOURNAL OF NATURAL RESOURCES, 2019, 34(12): 2601-2614.

图/表 11

图1

图2

图3

表1

表2

图4

图5

图6

图7

表3

图8

参考文献 57

[1]	BERTNESS M D, CRAIN C, HOLDREDGE C, et al.Eutrophication and consumer control of New England salt marsh primary productivity. Conservation Biology, 2008, 22(1): 131-139.
[2]	BERTNESS M D, SILLIMAN B R.Consumer control of salt marshes driven by human disturbance. Conservation Biology, 2008, 22(3): 618-623.
[3]	贺强, 安渊, 崔保山. 滨海盐沼及其植物群落的分布与多样性. 生态环境学报, 2010, 19(3): 657-664.
	[HE Q, AN Y, CUI B S.Coastal salt marshes and distribution and diversity of salt marsh plant communities. Ecology & Environmental Sciences, 2010, 19(3): 657-664.]
[4]	崔保山, 谢湉, 王青, 等. 大规模围填海对滨海湿地的影响与对策. 中国科学院院刊, 2017, 32(4): 418-425.
	[CUI B S, XIE T, WANG Q, et al.Impact of large-scale reclamation on coastal wetlands and implications for ecological restoration, compensation, and sustainable exploitation framework. Bulletin of Chinese Academy of Sciences, 2017, 32(4): 418-425.]
[5]	曾玉红, 朱曦. 经水媒传布种子的漂浮及沉降特性研究进展. 人民长江, 2017, 48(17): 20-24.
	[ZENG Y H, ZHU X.Review on seeds floating and settling kinetic characteristics dispersed by hydrochory. Yangtze River, 2017, 48(17): 20-24.]
[6]	DE JONGE V N, DE JONG D J. Ecological Restoration of Aquatic and Semi-aquatic Ecosystems in the Netherlands (NW Europe). Dordrecht: Springer, 2002: 7-28.
[7]	FOSTER N M, HUDSON M D, BRAY S, et al.Intertidal mudflat and saltmarsh conservation and sustainable use in the UK: A review. Journal of Environmental Management, 2013, 126: 96-104.
[8]	MORSING J, FRANDSEN S I, VEJRE H, et al.Do the principles of ecological restoration cover EU LIFE nature cofunded projects in Denmark?. Ecology and Society, 2013, 18(4): 15.
[9]	MERRITT D J, DIXON K W.Restoration seed banks: A matter of scale. Science, 2011, 332(6028): 424-425.
[10]	JAMES J J, SVEJCAR T J, RINELLA M J.Demographic processes limiting seedling recruitment in arid grassland restoration. Journal of Applied Ecology, 2011, 48(4): 961-969.
[11]	LIU Y, HORISAWA S, MUKOHATA Y.Effect of seed coating on plant growth and soil conditions: A preliminary study for restoration of degraded rangeland in the Qinghai-Tibetan Plateau, China. Grassland Science, 2010, 56(3): 145-152.
[12]	MADSEN M D, DAVIES K W, WILLIAMS C J, et al.Agglomerating seeds to enhance native seedling emergence and growth. Journal of Applied Ecology, 2012, 49(2): 431-438.
[13]	TURNER S R, PEARCE B, ROKICH D P, et al.Influence of polymer seed coatings, soil raking, and time of sowing on seedling performance in post-mining restoration. Restoration Ecology, 2006, 14(2): 267-277.
[14]	PEDRINI S, MERRITT D J, STEVENS J, et al.Seed coating: Science or marketing spin?. Trends in plant science, 2017, 22(2): 106-116.
[15]	MACDONALD L H, LARSEN I J.Fire Effects on Soils and Restoration Strategies. Enfield: Science Publishers, 2009: 423-452.
[16]	MADSEN M D, KOSTKA S J, INOUYE A L, et al.Postfire restoration of soil hydrology and wildland vegetation using surfactant seed coating technology. Rangeland Ecology & Management, 2012, 65(3): 253-259.
[17]	MADSEN M, ZVIRZDIN D, ROUNDY B, et al.Improving reseeding success after catastrophic wildfire with surfactant seed coating technology. Pesticide Formulation and Delivery Systems: 33rd Volume, "Sustainability: Contributions from Formulation Technology". ASTM International, 2014.
[18]	HOSSEINI M, GONZALEZ-PELAYO O, VASQUES A, et al.The short-term effectiveness of surfactant seed coating and mulching treatment in reducing post-fire runoff and erosion. Geoderma, 2017, 307: 231-237.
[19]	RICHARDSON M D, HIGNIGHT K W.Seedling emergence of tall fescue and kentucky bluegrass, as affected by two seed coating techniques. Hort Technology, 2010, 20(2): 415-417.
[20]	MADSEN M D, DAVIES K W, MUMMEY D L, et al.Improving restoration of exotic annual grass-invaded rangelands through activated carbon seed enhancement technologies. Rangeland Ecology & Management, 2014, 67(1): 61-67.
[21]	MADSEN M D, DAVIES K W, BOYD C S, et al.Emerging seed enhancement technologies for overcoming barriers to restoration. Restoration Ecology, 2016, 24: S77-S84.
[22]	MADSEN M D, SVEJCAR A J. Seed pillow for overcoming the limiting factors controlling rangeland reseeding success: US, 9326451, 2016-05-03.
[23]	SILINSKI A, HEUNER M, SCHOELYNCK J, et al.Effects of wind waves versus ship waves on tidal marsh plants: A flume study on different life stages of Scirpus maritimus. Plos One, 2015, 10(3): e0118687.
[24]	BALKE T, HERMAN P M J, BOUMA T J. Critical transitions in disturbance-driven ecosystems: Identifying windows of opportunity for recovery. Journal of Ecology, 2014, 102(3): 700-708.
[25]	NICHOLS P G H, MALIK A I, STOCKDALE M, et al. Salt tolerance and avoidance mechanisms at germination of annual pasture legumes: Importance for adaptation to saline environments. Plant & Soil, 2009, 315(1/2): 241-255.
[26]	王伟宏. 黄河口地区海水盐度场对泥沙固结过程影响研究. 青岛: 中国海洋大学, 2015.
	[WANG W H.Effect of the salinity field on the sediment consolidation process in the Yellow River Estuary. Qingdao: Ocean University of China, 2015.]
[27]	CHANG E R, VEENEKLAAS R M, BUITENWERF R, et al.To move or not to move: Determinants of seed retention in a tidal marsh. Functional Ecology, 2008, 22(4): 720-727.
[28]	VAN LEEUWEN C H A, SARNEEL J M, VAN PAASSEN J, et al. Hydrology, shore morphology and species traits affect seed dispersal, germination and community assembly in shoreline plant communities. Journal of Ecology, 2014, 102(4): 998-1007.
[29]	GRIFFITH A B F, I. N. Primary and secondary seed dispersal of a rare, tidal wetland annual, aeschynomene virginica. Wetlands, 2002, 22: 696-704.
[30]	HUISKES A H L, KOUTSTAAL B P, HERMAN P M J, et al. Seed dispersal of halophytes in Tidal Salt Marshes. Journal of Ecology, 1995, 83(4): 559.
[31]	WANG Q, WANG C H, HUANG S F, et al.Review on salt marsh plant communities: Distribution, succession and impact factors. Ecology and Environment Sciences, 2012, 21(2): 375-388.
[32]	郭焕, 刘国军, 刘素花, 等. 淀粉接枝丙烯酸高吸水树脂的制备. 大连工业大学学报, 2013, 32(4): 293-296.
	[GUO H, LIU G J, LIU S H, et al.Preparation of super absorbent polymer by graft copolymerization of acrylic acid onto starch. Journal of Dalian Polytechnic University, 2013, 32(4): 293-296.]
[33]	冯晓琦, 邓卫波, 申峻, 等. 分子筛改性羧甲基纤维素类高吸水性树脂研究. 化工新型材料, 2012, 40(10): 37-39.
	[FENG X Q, DENG W B, SHEN J, et al.Study on the carboxymethyl cellulose superabsorbent modified by molecular sieve. New Chemical Materials, 2012, 40(10): 37-39.]
[34]	黄慧珍. 聚丙烯酸—海藻酸钠吸水树脂的制备及性能研究. 广州化工, 2012, 40(12): 96-97.
	[HUANG H Z.Study on preparation and properties of polyacrylic acid-sodium alginate absorbent resin. Guangzhou Chemical Industry, 2012, 40(12): 96-97.]
[35]	FLORY P J.Pringeiples of Polymer Chemistry. New York: Cornell University Press, 1953: 57-59.
[36]	闫辉, 张丽华, 周秀苗, 等. 高吸水性树脂保水保肥性能研究. 化工科技, 2001, 9(5): 4-7.
	[YAN H, ZHANG L H, ZHOU X M, et al.Study on water retention capacity and fertilizer retention capacity of super absorbent polymers. Science and Technology in Chemical Industry, 2001, 9(5): 4-7.]
[37]	潘滋涵, 刘涛, 吴效楠, 等. 秸秆纤维素接枝 AA/AM 高吸水性树脂合成与性能研究. 塑料科技, 2018, 46(1): 46-50.
	[PANG Z H, LIU T, WU X N, et al.Study on synthesis and properties of straw cellulose grafted with AA/AM high adsorbent resin. Plastics Science and Technology, 2018, 46(1): 46-50.]
[38]	ZOHURIAAN-MEHR M J, KABIRI K. Superabsorbent polymer materials: A review. Iranian Polymer Journal, 2008, 17(6): 451.
[39]	SONG J, FAN H, ZHAO Y, et al.Effect of salinity on germination, seedling emergence, seedling growth and ion accumulation of a euhalophyte Suaeda salsa in an intertidal zone and on saline inland. Aquatic Botany, 2008, 88(4): 331-337.
[40]	海燕, 丁雪梅, 周婵, 等. 盐胁迫对三种盐生禾草种子萌发及其胚生长的影响. 草地学报, 2004, 12(1): 45-5.
	[HAI Y, DING X M, ZHOU C, et al.The effect of saline stress on the germination and embryo growth of three saline-grass seeds. Acta Agrestia Sinica, 2004, 12(1): 45-50.]
[41]	UHVITS R.Effect of osmotic pressure on water absorption and germination of alfalfa seeds. American Journal of Botany, 1946, 33(4): 278-285.
[42]	WERNER J E, FINKELSTEIN R R.Arabidopsis mutants with reduced response to NaCl and osmotic stress. Physiologia Plantarum, 1995, 93(4): 659-666.
[43]	徐卯林, 张洪熙, 黄年生, 等. 高吸水种衣剂在水稻旱育抛秧上的应用. 中国水稻科学, 1998, 12(2): 92-98.
	[XU M L, ZHANG H X, HUANG N S, et al.Application of high-hydroscopicity seed-coating material in dry-raised scattered-transplantation rice. Chinese Journal of Riceence, 1998, 12(2): 92-98.]
[44]	姜绍通, 周建芹, 赵妍嫣, 等. 甘薯淀粉接枝共聚高吸水树脂的合成及在种子包衣上的应用研究. 农业工程学报, 2004, 20(1): 207-210.
	[JIANG S T, ZHOU J Q, ZHAO Y Y, et al.Synthesis of sweet potato starch grafted copolymer super absorbent resin and its application to seed-coating. Transactions of the CSAE, 2004, 20(1): 207-210.]
[45]	陈恒伟, 姜绍通, 周建芹, 等. 高吸水树脂种衣剂对玉米种子生理特性的影响. 合肥工业大学学报: 自然科学版, 2004, 27(3): 242-246.
	[CHEN H W, JIANG S T, ZHOU J Q, et al.Super absorbent polymer seed coating and its effect on physiological features of corn seed. Journal of Hefei University of Technology, 2004, 27(3): 242-246.]
[46]	伍亚华, 石亚中. 甘薯淀粉基高吸水树脂棉花包衣剂研究. 应用化工, 2009, 38(2): 182-184.
	[WU Y H, SHI Y Z.Study on cotton seed coating with sweet potato starch super absorbent polymer. Applied Chemical Industry, 2009, 38(2): 182-184.]
[47]	王志玉, 刘作新, 魏义长. 高吸水树脂包衣对大豆光合作用及水分利用效率的影响. 干旱地区农业研究, 2004, 22(3): 105-108.
	[WANG Z Y, LIU Z X, WEI Y C.Effects of super absorbent polymers coating on photosynthesis and water use efficiency of soybean. Agricultural Research in the Arid Areas, 2004, 22(3): 105-108.]
[48]	AWADHWAL N G.Soil crust and its impact on crop establishment: A review. Soil and Tillage Research, 1985, 5(3): 289-302.
[49]	CARTHEY A J R, FRYIRS K A, RALPH T J, et al. How seed traits predict floating times: A biophysical process model for hydrochorous seed transport behaviour in fluvial systems. Freshwater Biology, 2016, 61(1): 19-31.
[50]	HUISKES A H L, BLOM C W P M, ROZEMA J. Vegetation between Land and Sea: Structure and Processes. Dordrecht: Springer, 1987: 226-235.
[51]	GURNELL A, THOMPSON K, GOODSON J, et al.Propagule deposition along river margins: Linking hydrology and ecology. Journal of Ecology, 2008, 96(3): 553-565.
[52]	DANVIND M, NILSSON C.Seed floating ability and distribution of alpine plants along a Northern Swedish River. Journal of Vegetation Science, 1997, 8(2): 271-276.
[53]	BOEDELTJE G, BAKKER J P, TEN B A, et al.Dispersal phenology of hydrochorous plants in relation to discharge, seed release time and buoyancy of seeds: The flood pulse concept supported. Journal of Ecology, 2004, 92(5): 786-796.
[54]	MCDONALD K.Tidal Seed Dispersal Potential of Spartina Densiflora in Humboldt Bay. California: Humboldt State University, 2014.
[55]	VAN D B T, VAN D R, BOBBINK R. Variation in seed buoyancy of species in wetland ecosystems with different flooding dynamics. Journal of Vegetation Science, 2005, 16(5): 579-586.
[56]	MARKWITH S H, LEIGH D S.Subaqueous hydrochory: Open-channel hydraulic modelling of non-buoyant seed movement. Freshwater Biology, 2008, 53(11): 2274-2286.
[57]	YOSHIKAWA M, HOSHINO Y, IWATA N.Role of seed settleability and settling velocity in water for plant colonization of river gravel bars. Journal of Vegetation Science, 2013, 24: 712-723.

种子产品类型	产品直径/mm	5粒重/g
PAM的种子产品	6.38±0.6512 a	0.8881±0.1559 b
HEC的种子产品	6.17±0.7025 a	0.8257±0.1098 b
HPMC的种子产品	6.28±0.5884 a	1.0989±0.0910 a
天然种子	2.68±0.2658 b	0.0020±0.0008 c

保水材料类型	吸水（25 ppt）倍率/ （g·g^-1）	保水持续时间/h
PAM	15.2956±1.1742 ab	23±0.5864 a
HEC	17.6671±1.2237 a	22±1.5216 a
HPMC	13.7958±2.1925 b	19±0.7389 b

种子产品类型	悬浮时间/s
PAM的种子产品	0 c
HEC的种子产品	42.00±12.0949 b
HPMC的种子产品	145.87±47.3465 a
天然种子	12小时内未沉降
