基于人类行为视角的市县国土空间总体规划管控措施编制思路探究

doi:10.31497/zrzyxb.20191018

摘要/Abstract

摘要：

在明确国土空间规划应融合多规,以主体控制线统一管控分区,强化底线约束,实施用途管制的前提下,管控措施编制对国土空间规划管控策略、管控体系的构建与实施至关重要。本研究的目的是探索基于人类行为的市县国土空间总体规划管控措施编制思路。尝试从人类行为视角进一步延伸管控思路,并衔接现行法律法规、部门规章等管控文件作为编制参照,根据人类行为与自然资源、国土空间的作用关系,结合行为开展与分区用途是否匹配,推导相关行为在对应市县国土空间总体规划管控分区的管控措施,以期为实现国土空间规划精准落地和国土空间资源保护与开发精细化管理提供参考。

关键词: 国土空间规划, 市县国土空间总体规划, 空间管控, 人类行为

Abstract:

Since the territorial spatial planning is required to merge multi-planning, unify zoning, and implement baseline regulations by land functions, compilation of spatial regulation is significant for constructing and implementing the strategies and system of spatial regulation. Even though we can unify the zoning of multi-planning through the boundary lines of spatial regulation districts, three issues must be concentrated to coordinate multi-planning regulation and reinforce the binding of territorial spatial master planning regulation to special plans and site plans. First, implement spatial regulations with human behaviors as the objects to improve constraint on negative influences. Second, merge current ordinances into territorial spatial master planning regulations. Third, enhance the guidance and constraint of baseline control model to non-developing and constructing human behaviors. The current researches have studied the definitions and objectives of the territorial spatial planning regulations through legal principles, logics, zoning and policies, and attempted to compile the strategies and systems of the territorial spatial planning regulation as well. Meanwhile, some researches have studied the influence relations among human behaviors, natural resources and territorial space. However, they lack a discussion of the compiling thinking of regulation ordinance from the perspective of human behaviors, which is an indispensable factor supporting the implementation of territorial spatial planning. This research aims at establishing a compiling thinking of the territorial spatial master planning regulation based on the perspective of human behaviors. We coordinate the zoning and regulations between territorial spatial planning regulations and regulation ordinances with human behaviors as carriers, and infer the relevant regulations of territorial spatial master plan according to the impacts caused by human behaviors to ensure the targeted implementation.

Key words: territorial spatial plan, city and county territorial spatial master plan, spatial regulation, human behaviors

赵坤, 许景权, 沈迟. 基于人类行为视角的市县国土空间总体规划管控措施编制思路探究[J]. 自然资源学报, 2019, 34(10): 2234-2243.

ZHAO Kun, XU Jing-quan, SHEN Chi. Research on the compiling thinking of city and county territorial spatial master planning regulations based on the perspective of human behaviors[J]. JOURNAL OF NATURAL RESOURCES, 2019, 34(10): 2234-2243.

图/表 7

表1

图1

表2

表3

人类行为分类"

人类行为	具体行为
保护行为	农业生产无关设施迁出、资源保护无关设施迁出、历史建筑外部修缮、历史建筑原址保护、限制荒芜基本农田、自然资源保护设施建设、退耕还湿与退养还滩、种植保护性树木、污染事故补救与处理、文物遗址保护、历史建筑异地迁移、保持和培肥地力、遗留工矿与废弃地复垦、整治河道、轮作休耕、退耕还林还草、人工回灌地下水、抢救性发掘、监测、维护、清淤疏浚、污染耕地阻控修复、荒漠化草原治理、关闭矿山、禁牧休牧、救火
开发生产建设行为	拆除历史性建筑、基础设施建设、危险与污染品生产和储存设施建设、历史性建筑原址重建、公共服务设施建设、林下种植、使用城市垃圾与污泥作为肥料、人工草地建设、临时设置、临时建设、倾倒污染物、污染物运输、排污管道建设、修建缆车索道、取水与截断水源、拆迁、设置垃圾场、林下养殖、耕作、天然草原改良、全面整地、生产经营、禽畜养殖、喷洒农药、使用化肥、修坟立碑、影视摄制、化工原料与矿物油储备、堆放废弃物、农业生产生活设施建设、狩猎、捕捞、围湖造地、采石、挖沙、砍伐、开垦、排放污水、公共设施维护、地下工程维护维修更新、烧荒、炼山、爆破、采挖植物、放牧、开山、旅游、取土、防灾工程建设、勘察开采矿产、建窑、建房、发展林果业、挖塘养鱼、填埋与排干、打井、灌溉、临时占用
其他行为	驯化繁殖珍稀濒危动植物、保护区范围和功能的改变、诱发地质灾害的活动、拆除非历史性建筑、闲置与拆除污染物处理设施、引进外来物种、科学研究与观测调查、大型群众性活动、考古调查勘探与发掘、打捞船舶、原住民居住、教学实习、参观考察、标本采集、填堵河道废除防洪河堤、砍柴、用火、抢险救灾、防火设施设置、汽车行驶、土地闲置、城市生活垃圾处置、农田闲置荒芜、引进优良草种、刻划与涂污、建筑垃圾处置、飞机飞行

表3

图2

图3

图4

参考文献 24

[1]	史家明, 范宇, 胡国俊, 等. 基于“两规融合”的上海市国土空间“四线”管控体系研究. 城市规划学刊, 2017, (s1): 31-41.
	[SHI J M, FAN Y, HU G J, et al."Four line" control system based on spatial plan integration in Shanghai. Urban Planning Forum, 2017, (s1): 31-41.]
[2]	王宁. 中国语境下“规划指引”的内涵思辨和制度解释: 兼对中国式规划管控方式的反思. 规划师, 2013, 29(8): 10-15.
	[WANG N.The connotation and institution of "planning guidance" in China. Planners, 2013, 29(8): 10-15.]
[3]	王国恩. “三规”空间管制问题的辨析与解决思路. 现代城市研究, 2015, (2): 33-39.
	[WANG G N.Discrimination and solutions to the problems of three-plan spatial regulation. Modern Urban Research, 2015, (2): 33-39.]
[4]	余亮亮, 蔡银莺. 国土空间规划管制与区域经济协调发展研究: 一个分析框架. 自然资源学报, 2017, 32(8): 1445-1456.
	[YU L L, CAI Y Y.Research on spatial regulation of land use planning and coordinated development of regional economy: An analytical framework. Journal of Natural Resources, 2017, 32(8): 1445-1456.]
[5]	吕晓, 黄贤金, 钟太洋, 等. 土地利用规划对建设用地扩张的管控效果分析: 基于一致性与有效性的复合视角. 自然资源学报, 2015, 30(2): 177-187.
	[LYU X, HUANG X J, ZHONG T Y, et al.The controlling effects of land-use planning on construction land expansion based on the perspective compositing consistency and effectiveness. Journal of Natural Resources, 2015, 30(2): 177-187.]
[6]	曹靖, 李星银, 陈婷婷, 等. 基于空间增长模拟的安庆城市开发边界划定方法及管控策略. 规划师, 2016, 32(6): 23-30.
	[CAO J, LI X Y, CHEN T T, et al.Anqing urban development boundary specification and management based on spatial growth simulation. Planners, 2016, 32(6): 23-30.]
[7]	聂晶鑫, 黄亚平, 单卓然, 等. 基于边界管控的城乡边缘区空间发展策略探索. 规划师, 2017, 33(10): 65-69.
	[NIE J X, HUANG Y P, SHAN Z R, et al.Spatial development of urban fringe area based on border control. Planners, 2017, 33(10): 65-69.]
[8]	吴之凌, 汪云, 夏巍. 新型城镇化视角下的武汉近郊区规划管控研究. 规划师, 2013, 29(9): 94-98.
	[WU Z L, WANG Y, XIA W.Metropolitan suburb planning control from new urbanization viewpoint Wuhan. Planners, 2013, 29(9): 94-98.]
[9]	胡立兵, 欧名豪. 城市国有土地供应机制与有效管控研究: 基于南京市的实证分析. 中国土地科学, 2012, 26(4): 23-28, 35.
	[HU L B, OU M H.A study on the mechanism and effectiveness control of state-owned urban land supply: An empirical study of Nanjing city. China Land Sciences, 2012, 26(4): 23-28, 35.]
[10]	潘悦, 程超, 洪亮平. 基于规划协同的市(县)空间管制区划研究. 城市发展研究, 2017, 24(3): 1-8.
	[PAN Y, CHENG C, HONG L P.Research on the spatial control zoning in urban (county) based on multiple plans coordination. Urban Studies, 2017, 24(3): 1-8.]
[11]	辛修昌, 邵磊, 顾朝林, 等. 从“做什么”到“不做什么”: 基于“多规融合”的县域空间管制体系构建. 城市发展研究, 2016, 23(3): 15-21.
	[XIN X C, SHAO L, GU C L, et al.From "what to do" to "what not to do": The construction of county spatial control system based on "multiple planning coordination". Urban Studies, 2016, 23(3): 15-21.]
[12]	林坚, 吴宇翔, 吴佳雨, 等. 论空间规划体系的构建: 兼析空间规划、国土空间用途管制与自然资源监管的关系. 城市规划, 2018, 42(5): 9-17.
	[LIN J, WU Y X, WU J Y, et al.Construction of the spatial planning system: With discussions on the relationship between spatial planning, territorial spatial regulation, and natural resources supervision. City Planning Review, 2018, 42(5): 9-17.]
[13]	林坚, 陈诗弘, 许超诣, 等. 空间规划的博弈分析. 城市规划学刊, 2015, (1): 10-14.
	[LIN J, CHEN S H, XU C Y, et al.Game analysis of spatial planning. Urban Planning Forum, 2015, (1): 10-14.]
[14]	王金岩. 空间规划体系与空间治理. 南京: 东南大学出版社, 2017: 24-25.
	[WANG J Y.Spatial Planning System and Spatial Governance. Nanjing: Southeast University Press, 2017: 24-25.]
[15]	杜黎明, 张成军. 实施空间管治的土地政策研究: 基于主体功能区的视角. 北京: 经济科学出版社, 2011: 38-39.
	[DU L M, ZHANG C J.Land Policy Research of the Implementation of Spatial Governance based on the Perspective of Major Function Oriented Zoning. Beijing: Economic Science Press, 2011: 38-39.]
[16]	林坚, 许超诣. 土地发展权、空间管制与规划协同. 城市规划, 2014, 38(1): 26-34.
	[LIN J, XU C Y.Land development rights, space control, and synergetic planning. City Planning Review, 2014, 38(1): 26-34.]
[17]	沈悦, 刘天科, 周璞. 自然生态空间用途管制理论分析及管制策略研究. 中国土地科学, 2017, 31(12): 17-24.
	[SHEN Y, LIU T K, ZHOU P.Theoretical analysis and strategies of natural ecological space use control. China Land Sciences, 2017, 31(12): 17-24.]
[18]	ALBRECHTS L.Strategic (spatial) planning reexamined. Environment and Planning B: Urban Analytics and City Science, 2004, 31(5): 743-758.
[19]	杨玲. 基于空间管制的“多规合一”控制线系统初探: 关于县(市)域城乡全覆盖的空间管制分区的再思考. 城市发展研究, 2016, 23(2): 8-15.
	[YANG L.Preliminary study on "multi-planning united" control system based on spatial control: Further consideration on the spatial control division of urban and rural full coverage in county (city) area. Urban Studies, 2016, 23(2): 8-15.]
[20]	刘超. 生态空间管制的环境法律表达. 法学杂志, 2014, 35(5): 22-32.
	[LIU C.Environmental law expression of ecological space control policy. Law Science Magazine, 2014, 35(5): 22-32.]
[21]	郝晋伟, 李建伟, 刘科伟. 城市总体规划中的空间管制体系建构研究. 城市规划, 2013, 37(4): 62-67.
	[HAO J W, LI J W, LIU K W.Study on spatial control system in city master plan. City Planning Review, 2013, 37(4): 62-67.]
[22]	汪劲柏, 赵民. 论建构统一的国土及城乡空间管理框架: 基于对主体功能区划、生态功能区划、空间管制区划的辨析. 城市规划, 2008, (12): 40-48.
	[WANG J B, ZHAO M.Towards unified territory and urban-rural spatial administration framework. City Planning Review, 2008, (12): 40-48.]
[23]	王磊, 沈建法. 规划管理、空间管制机制与规划协调: 以S市规划体制改革试点为例. 城市规划, 2017, 41(2): 18-26.
	[WANG L, SHEN J F.Planning administration, spatial regulation mechanisms, and planning coordination: A case study of planning system reform in S city. City Planning Review, 2017, 41(2): 18-26.]
[24]	史怀昱, 陈健. 新时期城市空间管控体系构建与榆林实践. 规划师, 2016, 32(3): 120-124.
	[SHI H Y, CHEN J.Urban space governance system in the new era Yulin. Planners, 2016, 32(3): 120-124.]

		六类分区
		刚性管控区	弹性管控区
三类空间	生态空间	生态保护红线区	生态缓冲区
	农业空间	永久基本农田红线区	一般农业区
	城镇空间	城镇开发建设区	城镇开发建设预留区

市县国土空间总体规划管控分区
生态空间		农业空间		城镇空间
生态保护红线区	自然保护区核心区缓冲区饮用水水源一级保护区地质灾害危险区风景名胜核心区地质遗迹一级保护区基本草原（生态保护地区）省级以上保护名录动植物栖息地禁猎区世界文化遗产核心区国家公益林一级保护区 I、II级保护林地国家与地方重要湿地沙化土地封禁保护区洪泛区	永久基本农田红线区	基本农田保护区	城镇开发建设区	城乡居民点建设用地世界文化遗产区域交通设施用地区域公用设施用地特殊用地其他建设用地区域市政走廊用地道路红线和外围控制区防洪保护区文物保护单位文物地下埋藏区城市绿地水功能开发利用区
生态缓冲区	自然保护区实验区水源二级和准保护区蓄滞洪区风景名胜非核心区地质遗迹二三级保护区文物保护单位文物地下埋藏区世界文化自然遗产缓冲区国家公益林二三级保护区 III、IV级保护林地一般湿地森林公园(不与自然保护核心区重叠) 采矿用地与采矿采空区	一般农业区	一般农地区牧业用地村庄建设用地蓄滞洪区水功能开发利用区采矿用地采矿采空区	城镇开发建设预留区	采矿用地采矿采空区城市基础设施用地村庄与集镇建设用地文物保护单位文物地下埋藏区城市绿地蓄滞洪区
