基于水资源分区的黄河流域土地利用变化对人类活动的响应

doi:10.31497/zrzyxb.20190205

摘要/Abstract

摘要：

在分析黄河流域1980-2015年土地利用面积变化的基础上,基于水资源二级分区,采用土地利用变化重要性指数（C_i）、土地利用变化面积比例（D）、林草植被变化指数（R）三个指标分析8个子区域土地利用变化的方向和程度;然后针对1980-1990年、1990-2000年、2000-2010年、2010-2015年四个时期,采用单一土地利用动态度、综合土地利用动态度及土地利用程度研究各分区的土地利用变化速度与程度。结果表明：与1980年相比,城乡工矿居民用地与水域面积变化最为显著。8个分区的土地利用变化面积比例均在20%左右,相互之间差异不大。在单一土地利用类型变化方面,沙漠及未利用地、水域和城市及工矿用地变化速度明显,其余三种土地利用类型由于面积基数较大,变化速度相对较小,但是变化面积很大。从各时期看,2010-2015年变化速度最大,并且大致呈现随时间推移变化速度逐渐增大的特征。在综合土地利用变化的速度方面,8个分区基本呈现出逐渐增大的趋势,上游龙羊峡以上增加最为明显。

关键词: 土地利用变化, 黄河流域, 水资源二级分区, 人类活动

Abstract:

Land use change analysis at different periods has been very helpful for resource management and essential trends detection through time. In order to understand the changes of land use, we examine the level of land use and the strength of human activities on land use in the Yellow River Basin in recent years. Based on the analysis of the change of land use area in the study area, according to secondary divisions of water resources, importance index of land use change (C_i), proportion of land use change area (D) and vegetation index of forest and grassland (R) were used to analyze the direction and degree of land use change in eight regions of Yellow River Basin during 1980-2015. It is found that land use in this basin underwent significant changes in the 35 years. The intensity of land changes in the Hekouzhen-Longmen section of the Yellow River Basin was the most intense. Although the degree of change in the eight sub-regions was relatively small, the absolute change area was large. The speed and degree of land use change were studied in four periods of 1980-1990, 1990-2000, 2000-2010 and 2010-2015 by using single land use dynamic degree, comprehensive land use dynamic degree and land use degree. The results showed that compared with 1980, the area of built-up land and water changed significantly. By analyzing the rate of single land use change in different periods, the rate of desert and unused land, water and urban and rural industrial and residential land changed significantly. The other three types of land use were not noticeable because of larger base area. In terms of the study periods, the change rate during 2010-2015 was the highest, and presented an increasing trend over time. Through the analysis of land use change rate, there was an increasing trend in all the eight regions; however the increasing trend in Longyangxia region was the most obvious. Except Longyangxia and Huayuankou water resources divisions, the comprehensive index of land use degree in the entire Yellow River basin ranged from -2 to 2 from 1980 to 2015, indicating that the comprehensive level of land use in each division did not change much in this period. From this perspective, human activities have less impact on land use. The reason for this result is that the entire area of the Yellow River Basin is too large, and the areas with intense human activities are only distributed in densely populated towns and plains. In the 35-year period, human activities did not have a profound impact on forests, grasslands, and deserts.

Key words: land use change, Yellow River Basin, secondary divisions of water resources, human activity

张冉, 王义民, 畅建霞, 黎云云. 基于水资源分区的黄河流域土地利用变化对人类活动的响应[J]. 自然资源学报, 2019, 34(2): 274-287.

ZHANG Ran, WANG Yi-min, CHANG Jian-xia, LI Yun-yun. Response of land use change to human activities in the Yellow River Basin based on water resources division[J]. JOURNAL OF NATURAL RESOURCES, 2019, 34(2): 274-287.

图/表 7

图1

表1

图2

图3

图4

表2

表3

参考文献 32

[1]	PORTER J R. GLP (2005) science plan and implementation strategy. IGPB Report No. 53/IHDP Report No. 19. Copenhagen: University of Copenhagen, 2014.
[2]	MCMAHON G, BENJAMINS P, CLARKE K, et al.Geography for a changing world: A science strategy for the geographic research of the U. S. Geological Survey, 2005-2015, Sioux Falls. SD: U. S. Geological Survey Circular, 2005, 1281: 1-76.
[3]	RINDFUSS R R, WALSH S J, ND T B, et al.Developing a science of land change: Challenges and methodological issues. PNAS, 2004, 101: 13976-13981.
[4]	HERRICK J E, URAMA K C, KARL J W, et al.The global land-potential knowledge system (LandPKS): Supporting evidence-based, site-specific land use and management through cloud computing, mobile applications, and crowdsourcing. Journal of Soil and Water Conservation, 2012, 68(1): 5A-12A.
[5]	MOONEY H A, DURAIAPPAH A, LARIGAUDERIE A.Evolution of natural and social science interactions in global change research programs. PNAS, 2013, 110(S1): 3665-3672.
[6]	STERLING S M, DUCHARNE A, POLCHER J.The impact of global land-cover change on the terrestrial water cycle. Nature Climate Change, 2013, 3(4): 385-390.
[7]	VITOUSEK P M.Beyond global warming: Ecology and global change. Ecology, 1994, 75(7): 1862-1876.
[8]	THOMAS W L.Manas W Lience Plan and Implementation Strategy. Chicago: University of Chicago Press, 1956.
[9]	RAMANKUTTY N, FOLEY J A.Estimating historical changes in global land cover: Croplands from 1700 to 1992. Global Biogeochemical Cycles, 1999, 13(4): 997-1027.
[10]	LAMBIN E F, GEIST H J, LEPERS E.Dynamics of land-use and land-cover change in tropical regions. Annual Review of Environment and Resources, 2003, 28(28): 205-241.
[11]	GOLDEWIJK K, RAMANKUTTY N.Land cover change over the last three centuries due to human activities: The availability of new global data sets. Geo Journal, 2004, 61(4): 335-344.
[12]	吴琳娜, 杨胜天, 刘晓燕, 等. 1976年以来北洛河流域土地利用变化对人类活动程度的响应. 地理学报, 2014, 69(1): 54-63.
	[WU L N, YANG S T, LIU X Y, et al.Response analysis of land use change to the degree of human activities in Beiluo River Basin since 1976. Acta Geographica Sinica, 2014, 69(1): 54-63.]
[13]	刘纪远, 刘明亮, 庄大方, 等. 中国近期土地利用变化的空间格局分析. 中国科学(D辑), 2002, 32(12): 1031-1040, 1058-1060.
	[LIU J Y, LIU M L, ZHUANG D F, et al. Study on spatial pattern of land-use change in China during 1995-2000. Science in China (Series D), 2002, 32(12): 1031-1040, 1058-1060.]
[14]	刘纪远, 张增祥, 徐新良, 等. 21世纪初中国土地利用变化的空间格局与驱动力分析. 地理学报, 2009, 64(12): 1411-1420.
	[LIU J Y, ZHANG Z X, XU X L, et al.Spatial patterns and driving forces of land use change in China in the early 21st century. Acta Ecologica Sinica, 2009, 64(12): 1411-1420.]
[15]	刘纪远, 匡文慧, 张增祥, 等. 20世纪80年代以来中国土地利用变化的基本特征与空间格局. 地理学报, 2014, 69(1): 3-14.
	[LIU J Y, KUAGN W H, ZHANG Z X, et al.Spatiotemporal characteristics, patterns and causes of land use changes in China since the late 1980s. Acta Geographica Sinica, 2014, 69(1): 3-14.]
[16]	蒲罗曼, 张树文, 李飞, 等. 近40年东北农牧交错带土地利用变化对人类活动的响应: 以吉林省西部地区为例. 江苏农业科学, 2016, 44(6): 522-525.
	[PU L M, ZHANG S W, LI F, et al.Response of land use change to human activities in Northeast agro pastoral ecotone in recent 40 years: A case study of Western Jilin province. Jiangsu Agricultural Sciences, 2016, 44(6): 522-525.]
[17]	王光谦, 王思远, 陈志祥. 黄河流域的土地利用和土地覆盖变化. 清华大学学报: 自然科学版, 2004, 44(9): 1218-1222.
	[WANG G Q, WANG S Y, CHEN Z X.Land-use/land-cover changes in the Yellow River Basin. Journal of Tsinghua University: Science and Technology, 2004, 44(9): 1218-1222.]
[18]	李帅, 顾艳文, 陈锦平, 等. 宁夏黄河流域土地利用时空变化特征分析. 西南大学学报: 自然科学版, 2016, 38(4): 42-49.
	[LI S, GU Y W, CHEN J P, et al.Spatio-temporal dynamic changes of land use in Ningxia Yellow River Valley. Journal of Southwest University: Natural Science Edition, 2016, 38(4): 42-49.]
[19]	罗娅, 杨胜天, 刘晓燕, 等. 黄河河口镇—潼关区间1998-2010年土地利用变化特征. 地理学报, 2014, 69(1): 42-53.
	[LUO Y, YANG S T, LIU X Y, et al.Land use change in the reach from Hekouzhen to Tongguan of the Yellow River during 1998-2010. Acta Geographica Sinica, 2014, 69(1): 42-53.]
[20]	高清竹, 江源. 黄河中游砒砂, 岩地区长川流域土地利用变化分析. 地理科学进展, 2004, 23(4): 52-62.
	[GAO Q Z, JIANG Y.An analysis of land-use change in Changchuan Watershed, a soft sand-rock, area at the middle reach of Yellow River. Progress in Geography, 2004, 23(4): 52-62.]
[21]	董斌, 冯仲科, 钱国英. 基于遥感的山东黄河流域土地利用动态及有林地转移. 福建农林大学学报: 自然科学版, 2010, 39(6): 646-650.
	[DONG B, FENG Z K, QIAN G Y.Dynamic study on land use and forest land transfer based on remote sensing in Yellow River Basin of Shandong province, China. Journal of Fujian Agriculture and Forestry University: Natural Science Edition, 2010, 39(6): 646-650.]
[22]	郭振华, 杨武年, 杨鑫, 等. 洛阳市近十年土地利用遥感动态监测及驱动力分析. 测绘, 2012, 32(2): 62-65, 77.
	[GUO Z H, YANG W N, YANG X, et al.Remote sensing dynamic monitoring and driving force analysis of land use/cover changes about Luoyang in recently 10 years. Surveying and Mapping, 2012, 32(2): 62-65, 77.]
[23]	刘晓燕, 杨胜天, 李晓宇, 等. 黄河主要来沙区林草植被变化及对产流产沙的影响机制. 中国科学: 技术科学, 2015, 45(10): 1052-1059.
	[LIU X Y, YANG S T, LI X Y, et al.The current vegetation restoration effect and its influence mechanism on the sediment and runoff yield in severe erosion area of Yellow River Basin. Scientia Sinica: Technologica, 2015, 45(10): 1052-1059.]
[24]	李艳忠, 刘昌明, 刘小莽, 等. 植被恢复工程对黄河中游土地利用/覆被变化的影响. 自然资源学报, 2016, 31(12): 2005-2020.
	[LI Y Z, LIU C M, LIU X M, et al.Impact of the grain for green project on the land use/cover change in the middle Yellow River. Journal of Natural Resources, 2016, 31(12): 2005-2020.]
[25]	黄河水利委员会黄河志总编辑室. 黄河流域综述. 郑州: 河南人民出版社, 1998.
	[Chief Editor of the Yellow River Annals of the Yellow River Water Conservancy Commission. Summary of the Yellow River Basin. Zhengzhou: Henan People's Publishing House, 1998.]
[26]	水利部黄河水利委员会. 黄河年鉴2009. 郑州: 黄河水利委员会黄河年鉴社, 2009.
	[Yellow River Water Conservancy Commission of Ministry of Water Resources. Yellow River Yearbook 2009. Zhengzhou: Yellow River Water Conservancy Commission the Yellow River Yearbook Society, 2009.]
[27]	王秀兰, 包玉海. 土地利用动态变化研究方法探讨. 地理科学进展, 1999, 18(1): 81-87.
	[WANG X L, BAO Y H.Study on the methods of land use dynamic change research. Progress in Geography, 1999, 18(1): 81-87.]
[28]	宋开山, 刘殿伟, 王宗明. 1954年以来三江平原土地利用变化及驱动力. 地理学报, 2008, 63(1): 93-104.
	[SONG K S, LIU D W, WANG Z M, et al.Land use change in Sanjiang Plain and its driving forces analysis since 1954. Acta Ecologica Sinica, 2008, 63(1): 93-104.]
[29]	冯永玖, 韩震, 基于遥感的黄浦江沿岸土地利用时空演化特征分析. 国土资源遥感, 2010, (2): 91-96.
	[FENG Y J, HAN Z.Remote sensing based spatial-temporal evolution of land use pattern in Huangpu River coast. Remote Sensing for Land & Resources, 2010, (2): 91-96.]
[30]	刘纪远, 布和敖斯尔. 中国土地利用变化现代过程时空特征的研究: 基于卫星遥感数据. 第四纪研究, 2000, 20(3): 229-239.
	[LIU J Y, BUHEAOSIER. A study on spatial-temporal feature of modern land use change in China: Using remote sensing techniques. Quaternary Sciences, 2000, 20(3): 229-239.]
[31]	WANG S Y, LIU J S, MA T B.Dynamics and changes in spatial patterns of land use in Yellow River Basin, China. Land Use Policy, 2010, 27(2): 313-323.
[32]	全斌. 土地利用覆盖变化导论. 北京: 中国科学技术出版社, 2010.
	[QUAN B.The Introduction to Land Use and Land Cover Change. Beijing: China Science and Technology Press, 2010.]

土地利用类型	面积/万km²					2015年比1980年增加或减少/万km²	增加或减少占1980年比/%
土地利用类型	1980年	1990年	2000年	2010年	2015年	2015年比1980年增加或减少/万km²	增加或减少占1980年比/%
林地	10.2240	10.1910	10.2090	10.4630	10.5290	0.3054	2.99
沙漠及未利用地	5.9933	5.9657	5.9248	6.0306	6.8204	0.8271	13.80
城乡工矿居民用地	1.3410	1.3556	1.4918	1.6596	2.0204	0.6794	50.66
水域	2.1487	2.0099	1.9652	2.0200	1.3432	-0.8055	-37.49
草地	38.7160	38.7900	38.5210	38.3900	37.7290	-0.9875	-2.55
耕地	21.0490	21.1600	21.3600	20.9100	21.0300	-0.0190	-0.09

分区	土地利用综合动态度
分区	1980-1990年	1990-2000年	2000-2010年		2010-2015年
I龙羊峡以上	2.20	1.91	2.65	63.29
II龙羊峡—兰州	0.36	1.29	0.96	27.84
III兰州—河口镇	1.78	2.03	2.56	8.77
IV内流区	1.46	1.92	4.02	18.02
V河口镇—龙门	1.13	2.50	3.87	24.49
VI龙门—三门峡	4.09	3.02	1.62	12.83
Ⅶ三门峡—花园口	13.64	8.63	5.30	10.87
Ⅷ花园口以下	4.04	7.11	4.15	24.37

分区	土地利用程度综合指数变化				2015年综合指数
分区	1980-1990年	1990-2000年	2000-2010年	2010-2015年	2015年综合指数
Ι龙羊峡以上	0.12	0.00	-0.47	-3.90	186.29
Ⅱ龙羊峡—兰州	-0.15	0.49	-0.16	-1.40	210.80
Ⅲ兰州—河口镇	0.52	0.78	0.44	1.78	219.60
Ⅳ内流区	-0.36	-0.03	-1.23	0.76	178.77
Ⅴ河口镇—龙门	0.45	0.89	-1.12	1.74	226.83
Ⅵ龙门—三门峡	0.18	0.65	-0.24	0.66	250.77
Ⅶ三门峡—花园口	-0.12	1.31	-0.12	0.37	249.19
Ⅷ花园口以下	0.83	3.04	0.66	-1.76	291.80
